Installing

Install in reverse order of removal.

TRIM UNDER STEERING COLUMN, REMOVING

z

Pry off cover caps -1- and remove screws -2-.

z

Remove switch mounting -3- from retainer.

Fig. 40: Removing Switch Mounting From Retainer
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release rear of cover -1- from instrument panel and pull out.

Fig. 41: Removing Rear Of Cover From Instrument Panel (Left Side)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolts/screws -2-.

z

Turn rotary part -1- of lighting switch to position 0.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 42: Turning Rotary Part Of Lighting Switch To Position 0
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press rotary part inward -arrow A- and then to the right -arrow B-.

z

Pull switch out of instrument panel -arrow- -C- and disconnect electrical connections.

z

Unclip head light range control switch -2- and disconnect connector.

z

Remove screw -arrow- (hidden under a cover cap) from glove box -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 43: Removing Screw From Glove Box
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove the 4 screws -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



z

Unclip trim -2- upward and remove from instrument panel.

Installing

Install in reverse order of removal.

Fig. 44: Installing Trim Screws
Courtesy of VOLKSWAGEN OF AMERICA, INC.

EYEGLASS COMPARTMENT, REMOVING AND INSTALLING

Eyeglass compartment above windshield (on roof liner - Sedan only)

z

Open eyeglass compartment and unclip cover 2- -arrow-.
