Volkswagen New Beetle. Manual - part 515

Fig. 26: Exploded View Of Center Console (From 05.03 in Sedan And From Beginning Of Production In
Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

REAR ASHTRAY FROM CENTER CONSOLE FROM 05.03 IN SEDAN AND FROM BEGINNING
OF PRODUCTION IN CONVERTIBLE, REMOVING AND INSTALLING

Removing

z

To remove, open ashtray -2- and remove ashtray insert. With non-smoker version, remove power socket -
1- and separate power socket connections -3-

z

Press ashtray in direction of arrow.

Installing

Install in reverse order of removal.

Fig. 27: Removing Power Socket And Separating Power Socket Connections (From 05.03 in Sedan And
From Beginning Of Production In Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

ARMREST PADDING FROM 05.03 IN SEDAN AND FROM BEGINNING OF PRODUCTION IN
CONVERTIBLE, REMOVING AND INSTALLING

Removing

z

Pry off cover -1- carefully using a screwdriver.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 28: Prying Off Cover (From 05.03 in Sedan And From Beginning Of Production In
Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press locking lugs -2- together and release from retaining plate -3- then pull armrest padding -1- off
upward -arrow-.

Installing

Install in reverse order of removal.

Fig. 29: Removing Armrest Padding (From 05.03 in Sedan And From Beginning Of Production In
Convertible)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

TRIM UNDER CENTER OF INSTRUMENT PANEL, REMOVING AND INSTALLING

Removing

z

Remove center console. See CENTER CONSOLE UP TO 01.01, REMOVING AND INSTALLING .



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



z

Remove screw -1-.

z

Remove clip -2-.

Fig. 30: Removing Clip From Trim Under Center Of Instrument Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screw -1-.

z

Pull trim -2- out to rear -arrow-.

Fig. 31: Removing Trim Under Center Of Instrument Panel Out To Rear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull connector off for power socket if installed.

Installing

Install in reverse order of removal.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



GLOVE BOX, REMOVING AND INSTALLING

Removing

z

Release rear of cover -1- from instrument panel -3- and pull off instrument panel to rear.

Fig. 32: Removing Rear Of Cover From Instrument Panel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove bolts/screws -2-.

z

Pry off cover caps -1- and remove screws -2-.

z

Remove switch mounting -3- from retainer.

Fig. 33: Removing Switch Mounting From Retainer
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove screws -arrows- (Qty. 6) (screws in the center of the vehicle are hidden under cover caps).



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle
