Fig. 16: Removing Gearshift Boot From Center Console - From 02.01 To 04.03
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Only if required for further work, remove clamp -2- and remove gearshift along with boot.

See SELECTOR MECHANISM ON TRANSMISSION SIDE, AS OF 06.99 .

z

Pull cover - 8 - off and separate cigarette lighter - 7 - connection.

z

Pull cover - 9 - off and separate power socket - 10 - connection.

z

Remove insert - 12 -.

z

Unclip cover caps - 3 -and remove screws - 2 -.

z

Remove screws - 4 - and - 13-.

z

Lift rear of center console -1-, pull to rear and remove upward over the gearshift.

Fig. 17: Exploded View Of Center Console - From 02.01 To 04.03
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Installing clamp:



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Installing

Install in reverse order of removal.

Fig. 18: Exploded View Of Center Console - From 02.01 To 04.03
Courtesy of VOLKSWAGEN OF AMERICA, INC.

REAR ASHTRAY FROM CENTER CONSOLE FROM 02.01 TO 04.03, REMOVING AND
INSTALLING

Removing

z

To remove ashtray -1-, turn item to the left and take off upward.

NOTE:

After reconnecting battery, ensure the vehicle equipment (radio, clock, electric
windows) is checked as per Workshop manual and/or Owner's manual.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Fig. 19: Ashtray - From 02.01 To 04.03
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Installation is reverse of removal.

DRINK HOLDER FROM 02.01, REMOVING AND INSTALLING

Removing

z

Slide drink holder -1- to right onto limit stop and then unhook base plate -2- (together with drink holder -
1-) from center console -arrow-.

Fig. 20: Sliding Drink Holder To Right Onto Limit Stop - From 02.01
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Interior Equipment - New Beetle



Installation is reverse of removal.

CENTER CONSOLE FROM 05.03 IN SEDAN AND FROM BEGINNING OF PRODUCTION IN
CONVERTIBLE, ASSEMBLY OVERVIEW

1. Center console

2. Bolt/screw

z

Qty. 2

3. Cover cap

z

Qty. 2

4. Bolt/screw

z

Qty. 2

5. Drink holder

z

with ashtray - 6 -

z

Removing, see DRINK HOLDER FROM 02.01, REMOVING AND INSTALLING

6. Ashtray

z

Inserted into drink holder - 5 -

7. Cigarette lighter

8. Cover

9. Cover

10. Gearshift cover retaining plate

11. Stowage tray

12. Cover

13. Bolt/screw

z

Qty. 4

14. Armrest latch

15. Bolt/screw

16. Handbrake lever guide

17. Bolt/screw

z

Qty. 3

18. Armrest padding

19. Cover

20. Armrest

21. Cover

22. Bolt/screw

z

Qty. 2

NOTE:

The following list refers to items in Fig. 21 .
