Fig. 127: Checking 2nd Gear Synchro-Ring Inner Ring For Wear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press inner ring onto 2nd gear wheel cone and measure gap "a" with a feeler gauge.

2ND GEAR SYNCHRO INNER RING GAP DIMENSIONS WEAR LIMIT

Installation position synchro-ring (inner-ring)

Gap "a"

New dimension

Wear limit

2nd gear

0.75 ... 1.25 mm

0.3 mm



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 128: Identifying Installation Position Synchro-Ring (Inner-Ring)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The lugs (arrow -1-) locate in the recesses (arrow -2-) in the synchro-ring -B-.

Installation position 2nd gear wheel



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 129: Identifying Installation Position 2nd Gear Wheel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The higher shoulder -A- faces to 1st gear -B-. The recesses in the shoulder (arrows) locate with the lugs of the
outer-ring (arrow. See Installation position outer-ring )

Pressing on needle roller bearing sleeve for 3rd gear



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 130: Pressing On Needle Roller Bearing Sleeve For 3rd Gear
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Disassembling and assembling 3rd and 4th gear locking collar and synchro-hub
