The ends -A- of the springs are bended from the transmission date indicated above.

The changed springs are installed on both sides.

Fig. 99: Installing Changed Springs
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

The changed springs can be installed in previous transmissions only with locking pieces, which are inner
hollow.

z

Inserting lock pieces (installation position: See 5th gear synchronizer ).

z

Installation position of the springs:

z

Insert springs offset by 120°.

z

The spring must secure with the angled end -A- in the hollow lock piece.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 100: Locating Installation Position Of Springs
Courtesy of VOLKSWAGEN OF AMERICA, INC.

The spring must be under the lug -B- from the locking piece.



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



The bended end points always from synchronizer body (direction of arrow).

INPUT SHAFT, ADJUSTING

(Determining input shaft adjustment shim)

Special tools and equipment

z

VW 387 Universal dial gauge bracket

z

VW 385/17 End measuring plate

z

VW510 Press piece

z

VW 447 i Thrust plate

z

VW 407 Press tool

z

V.A.G 1331 Torque wrench

z

Measuring dial gauge



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 101: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

It is necessary to readjust the input shaft when the following components are replaced:
