2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 48: Identifying Special Tools And Equipment (3 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Oil seal and sleeve are driven out in one piece:

z

T10148 Press piece



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 49: Identifying T10148 Press Piece
Courtesy of VOLKSWAGEN OF AMERICA, INC.

1. Transmission housing

z

If replaced: Adjust input shaft and differential. See Adjustment overview

2. Needle roller bearing

z

For output shaft

z

Removing. See Driving out needle roller bearing

z

Installing and securing. See Driving needle roller bearing in onto stop

3. Oil filler plug, 30 N.m

z

Without magnet

4. Shim

z

For input shaft

z

Adjustment overview. See Adjustment overview

5. Outer race/tapered roller bearing

z

For output shaft

z

Removing and installing. See Output shaft, disassembling and assembling

z

If replaced: Adjust output shaft. See Output shaft, adjusting

6. Outer race/tapered roller bearing

z

For input shaft

z

Removing and installing. See Output shaft, disassembling and assembling

z

If replaced: Adjust input shaft. See Output shaft, adjusting

7. Shim

z

For input shaft

z

Adjustment overview. See Adjustment overview

8. Outer race/tapered roller bearing

z

For input shaft

z

Removing and installing. See Pressing out tapered roller bearing outer race

z

If replaced: Adjust input shaft. See Input shaft, adjusting

9. Needle bearing

z

Removing and installing. See Pulling needle roller bearing out of clutch housing

10. Dowel sleeve

z

(Qty. 2)

11. Starter bushing

z

Not installed in all transmissions

z

Pulling out. See Pulling out starter bushing .

NOTE:

The following list refers to items in Fig. 50 .
