z

Remove transmission housing and pull tapered roller bearing outer race out from transmission housing.
See REMOVING .

z

Insert shims of correct thickness, thickest shim first.

The following shims are available:

SHIM THICKNESS AVAILABILITY - DIFFERENTIAL BEARING PRELOAD

If the size of shim required is larger than those listed in the table, insert two shims totalling the correct figure.

Varying tolerances make it possible by measuring the shims to obtain the exact shim thickness required.

z

Press outer race in again and tighten transmission housing securely.

+ Preload (constant figure)

0.40 mm

Thickness of shim =

1.10 mm

Size (mm)

Part No.

0.65

02A 409 210

0.70

02A 409 210 A

0.75

02A 409 210 B

0.80

02A 409 210 C

0.85

02A 409 210 D

0.90

02A 409 210 E

0.95

02A 409 210 F

1.00

02A 409 210 G

1.05

02A 409 210 H

1.10

02A 409 210 J

1.15

02A 409 210 K

1.20

02A 409 210 L

1.25

02A 409 210 M



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



1998-2004 TRANSMISSION

5 Spd. Manual Transmission 02J - New Beetle

GENERAL, TECHNICAL DATA

TRANSMISSION IDENTIFICATION

The 5-speed manual transmission 02J is installed in the New Beetle from 1998 in conjunction with 4-cylinder
engines.

Application. See CODE LETTERS, TRANSMISSION APPLICATION, RATIOS, CAPACITIES .

Location on transmission

Code letters and date of manufacture (arrow 1) manual transmission 02J (arrow 2)

Fig. 1: Locating Code Letters And Date Of Manufacture
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Manual transmission 02J (arrow -2-)



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 2: Locating Code Letters And Date Of Manufacture Manual Transmission 02J
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Code letters and date of manufacture of transmission



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 3: Identifying Code Letters And Date Of Manufacture Of Transmission
Courtesy of VOLKSWAGEN OF AMERICA, INC.

TRANSMISSION CODE LETTERS AND DATE SPECIFICATION

Additional data depends on manufacture.

Example:

DZQ

06

05

8

Explanatio n

Code letters

Day

Month

Year (1998) of manufacture

NOTE:

The transmission code letters are also shown on the vehicle identification
plates.
