The bended end points always from synchronizer body (direction of arrow).

INPUT SHAFT, ADJUSTING

(Determining input shaft adjustment shim)

Special tools and equipment

z

VW 387 Universal dial gauge bracket

z

VW 385/17 End measuring plate

z

VW510 Press piece

z

VW 447 i Thrust plate

z

VW 407 Press tool

z

V.A.G 1331 Torque wrench

z

Measuring dial gauge



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Fig. 101: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

It is necessary to readjust the input shaft when the following components are replaced:



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



z

Transmission housing

z

Clutch housing

z

Input shaft

z

4th gear wheel

or the

z

Tapered roller bearings

Adjustment overview. See Adjustment overview

z

Press tapered roller bearing outer race without shim into transmission housing onto stop, using VW 510.

Fig. 102: Installing Tapered Roller Bearing Outer Race



2003 Volkswagen New Beetle GLS

1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Install input shaft in clutch housing and assemble transmission housing. Tighten hex head bolts to 25 N.m
and then turn an additional 90°.

z

Install dial indicator in clutch housing (large tapered roller bearing in transmission housing).

z

Before taking any measurements, rotate input shaft to allow bearings to settle. Set dial gauge to "O" with
1 mm preload.

Fig. 103: Installing Dial Indicator In Clutch Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

This preparation is to be repeated for each subsequent measurement,
otherwise the gauge will not return to the starting position.
