Fig. 97: Identifying 5th Gear Synchronizer 1. Springs for lock pieces 2. Locking collar With 3 recesses (arrows A) for the locking pieces (item 4) 3. Synchro-hub 4. Locking pieces Installation position: The thin extension (arrow B) faces the pointed teeth of the locking collar (item -2-) Assembling 5th gear locking collar/synchro-hub
2003 Volkswagen New Beetle GLS 1998-2004 TRANSMISSION 5 Spd. Manual Transmission 02J - New Beetle
|
