z

Disconnect electrical connection to turn signal housing.

z

Remove screw -1- and swing turn signal housing -2- out of mounting.

Fig. 68: Removing Screw And Swing Turn Signal Housing
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

Install in reverse order of removal.

FRONT TURN SIGNAL BULB, REPLACING

Removing

z

Remove front turn signal. See FRONT TURN SIGNAL AND SIDE MARKER LIGHTS (TURBO S
MODELS ONLY) .

z

Turn bulb holder and pull out from housing as follows:



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Lights, Switches - Exterior - New Beetle



Left light: turn bulb holder counterclockwise

Right light: turn bulb holder clockwise.

z

Remove bulb from bulb holder.

Fig. 69: Removing Front Turn Signal Bulb From Holder
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Install in reverse order of removal.

CAUTION: Do not touch the glass portion of the bulb with bare hands. The moisture

and/or grease from fingers that evaporates on the bulb during operation,
can cause the glass to cloud over.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Lights, Switches - Exterior - New Beetle



FRONT SIDE MARKER LIGHTS, REMOVING AND INSTALLING

Removing

z

Remove front inner fender liner

See WHEEL HOUSING LINER .

z

Carefully press retainer clip in direction of -arrow-.

Fig. 70: Removing Front Side Marker Light Retainer Clip
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Disconnect electrical connection.

Installing

z

Reconnect electrical connection.

NOTE:

When installing, ensure bulb holder engages fully in housing, and turn in
opposite direction of removal.

CAUTION:

z

Switch off all electrical consumers.

z

Switch ignition off and remove ignition key.



2003 Volkswagen New Beetle GLS

1998-2004 ACCESSORIES & EQUIPMENT Lights, Switches - Exterior - New Beetle



z

Insert side marker light into bumper and click in place, make sure locating boss is seated correctly in
cutout -arrow-

Fig. 71: Inserting Side Marker Light Into Bumper
Courtesy of VOLKSWAGEN OF AMERICA, INC.

FRONT SIDE MARKER LIGHT BULB, REPLACING

CAUTION:

z

Switch off all electrical consumers.

z

Switch ignition off and remove ignition key.
