2. Hex nut

z

50 N.m (37 ft lb)

3. Clamp

z

Always replace

z

Tightening. See INSTALLING

4. Boot

z

Must not be twisted after adjusting tie

z

Remove steering gear to replace

5. Clamp

z

Always replace

z

Tightening. See INSTALLING

6. Inner tie rod

z

75 N.m (55 ft lb)

Modification:

Modified tie rods. See TIE RODS, MODIFIED

z

Removing and installing. See TIE ROD, REMOVING AND INSTALLING

z

Replacement parts are supplied preset

z

Vehicle alignment. See WHEEL ALIGNMENT PROCEDURES .

z

Different versions

z

Application see Parts catalog

7. Hex bolt

z

22 N.m (16 ft lb)

8. Gasket

z

Observe installing instructions! See INSTALLING .

9. Hydraulic hose

10. Banjo bolt

z

45 N.m (33 ft lb)

M 16 x 1.5

11. Banjo bolt

z

38 N.m (28 ft lb)

M 14x 1.5

12. Sealing rings

z

Always replace



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



13. Return line

14. Steering gear

z

Removing and installing. See POWER STEERING, SERVICING

15. Mounting bracket with rubber mounting

z

Replace if threads in welded nut are damaged

16. Heat shield

17. Self-locking hex nut

z

45 N.m (33 ft lb)

18. Hex nut

z

22 N.m (16 ft lb)

Fig. 35: Exploded View Of Power Steering Gear Assembly
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



TIE ROD, REMOVING AND INSTALLING

Special tools and equipment

z

VW 313 Support clamp

z

V.A.G 1275 Pliers

z

V.A.G 1332 Torque wrench

z

V.A.G 1332/5 Open jaw insert, 34 mm AF

z

T10108 Transmission bracket



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 36: Identifying Special Tools And Equipment
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

The tie rods can only be removed/installed with the steering gear removed.
