z

Clamp hose on power steering pump with hose clamp 3094.

Fig. 28: Clamping Hose On Power Steering Pump With Hose Clamp 3094
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove insulation tray.

z

Place drip tray underneath.

z

Remove front wheels.

z

Remove outer tie rod hex nut. See TIE ROD, REMOVING AND INSTALLING , item 17

z

Press outer tie rod end off steering arm.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 29: Removing Outer Tie Rod End From Steering Arm
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



A. Ball joint puller (commercial type) e.g. Kukko 128/2

z

Disconnect hoses from steering gear and seal with plastic bag and adhesive tape.

z

Seal power steering gear threaded holes with plastic sealing plugs -1- and -2-.

Fig. 30: Identifying Plastic Sealing Plugs
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Remove hex bolts -1- and -2-.



2003 Volkswagen New Beetle GLS

1998-2004 STEERING Steering - New Beetle



Fig. 31: Removing Hex Bolts From Pendulum Support
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with TDI engine
