Fig. 2: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Battery voltage must be at least 11.5 Volts.

z

All electrical consumers such as, for example, lights and rear window defroster must be switched off.

z

Parking brake must be engaged or else daylight driving lights will be switched on.

z

For vehicles with automatic transmission, selector lever must be in position -P- or -N-.

z

If vehicle is equipped with an A/C system, it must be switched off.

z

Ground (GND) connections between engine and chassis must be OK.

z

Ignition switched off.

Work procedure

Connect diagnostic tester (VAS 5052) using (VAS 5052/3) diagnostic cable as follows:

z

Connect diagnostic cable connector to Data Link Connector (DLC) -arrow-.

NOTE:

Fuse holder is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



Fig. 3: Locating Data Link Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Depending on the desired diagnostic mode, it is necessary to:switch on ignition or start engine and let it
run at idle. See Selectable diagnostic modes under address word 33 - OBD .

Test box, connecting for wiring test

Recommended special tools and equipment:

Vehicles with 80-pin control module

z

VAG1598/22 test box

NOTE:

z

Respective operation of the diagnostic tester:

z

If no display appears on diagnostic tester, check voltage supply at
Diagnostic Link Connector (DLC).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



Fig. 4: Identifying VAG1598/22 Test Box
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with 121-pin control module

z

VAG1598/31 test box

Fig. 5: Identifying VAG1598/31 Test Box
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirement

z

Ignition switched off.

Work procedure

z

Remove inner cover of plenum chamber, left side:

z

Then disengage connector from control module and disconnect.

Vehicles with 80-pin control module

z

Connect VAG1598/22 test box at control module wiring harness.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



Fig. 6: Connecting VAG1598/22 Test Box At Control Module Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Vehicles with 121-pin control module

z

Connect VAG1598/31 test box at control module wiring harness. The control module for Diesel -Direct
fuel injection system is not connected during this.

Fig. 7: Connecting VAG1598/31 Test Box At Control Module Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Continuation for all vehicles

When harness connectors are disconnected from the control module for Diesel-Direct fuel injection system or
the battery is disconnected, all adaptation values in the control module are erased. DTC memory content will
remain intact however. If the engine is started after this, rough, uneven idle can result. In this case, the readiness
code must be generated again. See READINESS CODE, GENERATING .

Malfunction Indicator Lamp (MIL) in instrument cluster
