DTC

DTC text

Corrective action

P3211

Exhaust-bank1-

sensor1, Heater

return connection

z

Check oxygen sensor heater for oxygen sensors before Three Way

Catalytic Converter (TWC), see OXYGEN SENSOR HEATER

FOR OXYGEN SENSOR BEFORE THREE WAY

CATALYTIC CONVERTER (TWC), CHECKING

z

Check Oxygen Sensor (O2S) and oxygen sensor control before Three

Way Catalytic Converter (TWC), see CHECK OXYGEN SENSOR

AND OXYGEN SENSOR REGULATION BEFORE

CATALYTIC CONVERTER



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE On-Board Diagnostic (OBD), 1.8L Generic Scan Tool - New Beetle



1998-2004 ENGINE PERFORMANCE

Generic Scan Tool, 1.9L ALH & BEW- New Beetle

GENERIC SCAN TOOL

GENERAL INFORMATION FOR ON BOARD DIAGNOSTIC (OBD)

Characteristics of On Board Diagnostic (OBD)

The control module for Diesel-Direct fuel injection system is equipped with a DTC memory.

If malfunctions occur at the emission relevant systems or components, they are stored in DTC memory with a
description of the malfunction type.

The control module for Diesel-Direct fuel injection system differentiates between different DTCs after
evaluating the information. See DIAGNOSTIC TROUBLE CODE (DTC) TABLES: .

The stored malfunctions can be checked with a standard diagnostic tester. See DIAGNOSTIC MODE 3:
CHECK DTC MEMORY .

When harness connectors are disconnected from the control module for Diesel-Direct fuel injection system or
the battery is disconnected, all adaptation values in the control module are erased. DTC memory content will
remain intact however. If the engine is started after this, rough, uneven idle can result. In this case, the readiness
code must be generated again. See READINESS CODE, GENERATING .

The following work steps must be performed in the described sequence after the malfunction(s) have been
repaired:

1. - Check DTC memory. See DIAGNOSTIC MODE 3: CHECK DTC MEMORY .

2. - Erase DTC memory. See DIAGNOSTIC MODE 4: RESET/ERASE DIAGNOSTIC DATA .

3. - For completion, generate readiness code. See READINESS CODE, GENERATING .

On Board Diagnostic (OBD), technical data

Control module identification

The control module version is displayed by selecting "Diagnostic mode 9: Vehicle information" under address
word 33. See DIAGNOSTIC MODE 9: VEHICLE INFORMATION .

Equipment of control module for Diesel-Direct fuel injection system

Equipment Of Control Module Identification

Engine Code

ALH model year up to

04.99

ALH Model year from

05.99 and up

System identification

EDC (Electronic Diesel

EDC (Electronic Diesel



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle





2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



Selectable diagnostic modes under address word 33 - OBD

Diagnostic Modes Under Address Word 33

Control)

Control)

Equipment of control module for Diesel-Direct
fuel injection system

80

121

Emissions limiting values according to

Tier 1

(1)

Tier 1

(1)

On Board Diagnostic (OBD)

OBD II

OBD II

DTC memory

Permanent memory

(2)

Permanent memory

(2)

Memory for adaptation values

Temporary memory

(3)

Temporary memory

(3)

Intake manifold change-over

No

No

Camshaft adjustment

No

No

Boost pressure regulation

Yes

Yes

Exhaust Gas Recirculation (EGR)

Yes

Yes

(1)

Tier 1 = Non-Low Emission Vehicles (emission values max. 0.25 g/mi HC)

(2)

Independent of voltage supply.

(3)

Values are erased when voltage supply is interrupted.

NOTE:

The conditions required for selecting the desired diagnostic mode are listed in
the following table:

Diagnostic mode

Requirement:

Selectable diagnostic modes under address word 33-
OBD

z

engine

off

z

Ignition

switched

on

z

Engine

running

at idle

z

Vehicle

in drive

mode

Mode
1:

Check measured

values

See DIAGNOSTIC MODE

1: CHECK MEASURED

VALUES .

Yes

Yes

Yes

Mode
2:

Check operating

conditions

See DIAGNOSTIC MODE

2: CHECK OPERATING

CONDITIONS .

Yes

Yes

Yes

Mode
3:

Check DTC

Memory

See DIAGNOSTIC MODE

3: CHECK DTC

MEMORY .

Yes

(1)

Yes

Yes

Mode
4:

Reset/erase

diagnostic data

See DIAGNOSTIC MODE

4: RESET/ERASE

DIAGNOSTIC DATA .

Yes

Yes

Yes

Mode
6:

Check test results

of components

See DIAGNOSTIC MODE

6: CHECK TEST

Yes

(2)

Yes

(2)

Yes

(2)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle



Diagnostic Tester, connecting

Recommended special tools and equipment:

z

VAS 5052 Vehicle Diagnostic and Information System with

Fig. 1: Identifying Special Tool VAS 5052
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAS 5052/3 diagnostic cable

Requirements

z

The respective fuses of Diesel-Direct fuel injection system must be OK.

that are not

continuously

monitored

RESULTS OF

COMPONENTS THAT

ARE NOT

CONTINUOUSLY

MONITORED .

Mode
7:

Check test results

of components

that are

continuously

monitored

See DIAGNOSTIC MODE

7: CHECK TEST

RESULTS OF

COMPONENTS THAT

ARE CONTINUOUSLY

MONITORED .

Yes

(1)

Yes

Yes

Mode
9:

Vehicle

information

See DIAGNOSTIC MODE

9: VEHICLE

INFORMATION .

Yes

Yes

Yes

(1)

Perform only with ignition switched on when engine does not start (operate starter beforehand for at
least 6 seconds).

(2)

Test-ID 10 and Test-ID 12 can only be performed with engine at standstill and ignition switched on.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Generic Scan Tool, 1.9L ALH & BEW- New Beetle
