MODULE (ECM) .

Checking function

z

Connect test box to control module wiring harness, see CONNECT TEST BOX FOR WIRING TEST .

z

Re-connect connector at Charge Air Pressure Sensor -G31-.

z

Use adapter cables from VAG1594 to connect multimeter to sockets 101 (B+) + 108 (Ground -GND-) for
voltage measurement.

z

Start engine and measure voltage.

Specified value: 1.80 to 2.00 volts

z

Bring engine to RPM by depressing accelerator pedal suddenly.

Specified value: 2.00 to 3.00 volts

If specified values are not obtained:

z

Replace Charge Air Pressure Sensor -G31-, see item 3

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

z

Generate readiness code, see READINESS CODE, GENERATING .

Recirculating valve for turbocharger, checking

Valve opens between connection to intake manifold and connection to deceleration shut-off valve with no
voltage. Connection to vacuum reservoir is closed.

Test sequence

z

Switch ignition off.

z

Disconnect connector from Recirculating valve for turbocharger -N249-.

z

Measure resistance between terminals of valve.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



Fig. 14: Measuring Resistance Between Terminals Of Turbocharger Recirculating Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Specified value: 25...35 ohm

If specified value is not obtained:

z

Replace Recirculating valve for turbocharger -N249-:

z

Vehicles with engine code APH, see item 16

z

Vehicles with engine code AWP, AWV, see item 16

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

z

Generate readiness code, see READINESS CODE, GENERATING .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



If specified values are obtained:

z

Connect test box to control module wiring harness, see CONNECT TEST BOX FOR WIRING TEST .

z

Check wire between test box socket 105+2-pin connector terminal 2 for open circuit according to wiring
diagram.

Wire resistance: max. 1.5 ohm

z

Also check the wire for short circuit to B+ and Ground (GND).

If no malfunctions are found in wire:

z

Check wire between 2-pin connector terminal 1 and the Fuel Pump (FP) Relay -J17- for open circuit
according to wiring diagram.

Wire resistance: max. 1.5 ohm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



Fig. 15: Identifying 2-Pin Turbocharger Recirculating Valve Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

If no malfunctions are found in wires:

z

Replace Engine Control Module (ECM), see REPLACING ENGINE CONTROL MODULE (ECM) .

Vacuum diaphragm for wastegate bypass regulator valve, checking

Recommended special tools and equipment e.g.:

z

VAG1526 multimeter or VAG1715 multimeter
