Fig. 10: Measuring Resistance Between Wastegate Bypass Regulator Valve Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Specified value: 25...35 ohm

If specified value is not obtained:

z

Replace Wastegate Bypass Regulator Valve -N75-

z

Vehicles with engine code APH, see item 17 ,

z

Vehicles with engine code AWP, AWV, see item 22 .

z

Erase DTC memory of Engine Control Module (ECM), see DIAGNOSTIC MODE 4: RESET/ERASE



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



DIAGNOSTIC DATA .

z

Generate readiness code, see READINESS CODE, GENERATING .

Charge air pressure sensor, checking

Recommended special tools and equipment e.g.:

z

VAG1526 multimeter or VAG1715 multimeter

z

VAG1594 connector test kit

z

Wiring diagram

Checking voltage supply and wiring to control module

z

Disconnect 4-pin connector -2- from Charge Air Pressure Sensor -G31- (-1-).

Fig. 11: Disconnecting 4-Pin Connector From Charge Air Pressure Sensor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Use adapter cables from (VAG1594) to connect multimeter to terminals 1 + 3 of connector for voltage
measurement.

z

Switch ignition on.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



Specified value: at least 4.5 V

z

Switch ignition off.

If there is no voltage:

z

Connect test box to control module wiring harness, see CONNECT TEST BOX FOR WIRING TEST .

Fig. 12: Measuring Voltage Between Charge Air Pressure Sensor Harness Connector Terminals 1
And 3
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check for open circuits in wires between test box and connector according to wiring diagram.

Terminal 1+socket 108

Terminal 3 + socket 98

Terminal 4 + socket 101



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Turbocharger, G - Charger, 1.8L Generic Scan Tool - New Beetle



Wire resistance: max. 1.5 ohm

Fig. 13: Identifying Charge Air Pressure Sensor Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wires for short circuit to each other.

If no malfunctions are found in the wires and there was voltage between terminals 1 + 3:

z

Check function, see CHECKING FUNCTION

If no malfunctions are found in wires and there was no voltage between terminals 1 + 3:

z

Replace Motronic Engine Control Module (ECM) -J220-, see REPLACING ENGINE CONTROL
