z

Connect hand vacuum pump V.A.G 1390 to vacuum tester V.A.G 1368 (connection -B-).

z

Connect vacuum hose (to actuator) to vacuum tester V.A.G 1368 (connection -A-).

Fig. 60: Connecting Vacuum Hose To Vacuum Tester V.A.G 1368
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Set vacuum tester to -A/B- position.

z

Operate V.A.G 1390 several times. Create a vacuum of maximum 500 millibar.

z

Vacuum must not drop

If the vacuum drops:

z

Replace intake manifold upper part. See INTAKE MANIFOLD UPPER PART, DISASSEMBLING
AND ASSEMBLING .

Checking vacuum actuator in intake manifold lower part for leaks

z

Pull vacuum hose to variable intake manifold actuator (arrow), off intake manifold tuning valve -1-.

z

Connect hand vacuum pump V.A.G 1390 to vacuum tester V.A.G 1368 (connection -B-).

manifold and is therefore not visible from the outside.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 61: Disconnecting Intake Manifold Tuning Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect vacuum hose (to actuator) to vacuum tester V.A.G 1368 (connection -A-).

Fig. 62: Connecting Vacuum Hose (To Actuator) To Vacuum Tester V.A.G 1368
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Set vacuum tester to -A/B- position.

z

Operate V.A.G 1390 several times. Create a vacuum of maximum 500 millibar.

z

Vacuum must not drop

If the vacuum drops:

z

Replace intake manifold lower part. See INTAKE MANIFOLD LOWER PART, DISASSEMBLING
AND ASSEMBLING .

If the vacuum does not drop at either of the vacuum actuators:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Check change-over mechanics in intake manifold for freedom of movement.

z

Remove intake manifold upper part.

z

Repeat leak tests on both vacuum actuators. Check that change-over flaps move.

If fault is detected:

z

Replace intake manifold upper part or intake manifold lower part.

ENGINE CONTROL MODULE

ENGINE CONTROL MODULE, REPLACING

Work sequence

z

Print out control module identification and thereby previous control module coding. See ENGINE
CONTROL MODULE FAULT MEMORY, INTERROGATING AND ERASING .

Removing

z

Switch off ignition.

z

Remove inner cover on left side of plenum chamber:

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Carefully press off retaining tab (arrow).

Fig. 63: Pressing Off Retaining Tab And Disconnecting Connector From Control Module
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Replace the control module if the control module version displayed does not
correspond to the vehicle. For the latest engine control module part number:
See Parts catalog



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



z

Release and disconnect connector from control module.

Installing

z

Install new control module and press it to left.

z

Install control module connector and lock.

z

If fault memory has been erased or engine control module was disconnected from permanent positive,
adapt respective components to engine control module, and generate readiness code again. See
COMPONENTS AND FUNCTIONS, ADAPTING .

z

Adapt control module to electronic immobilizer and throttle valve control module. Adapt for cruise
control system function if necessary. See COMPONENTS AND FUNCTIONS, ADAPTING .

Vehicles with automatic transmission

z

Adapt transmission to learn kick-down point. See COMPONENTS AND FUNCTIONS, ADAPTING .

z

Adapt control module for automatic transmission. See COMPONENTS AND FUNCTIONS,
ADAPTING .

Continued for all vehicles

z

Interrogate fault memory of new engine control module and erase fault memory if necessary. See
ENGINE CONTROL MODULE FAULT MEMORY, INTERROGATING AND ERASING .

z

Road test vehicle and interrogate all fault memories:

See Diagnostic tester VAS 5051; Guided fault finding; Vehicle system test

Observe the valid safety precautions when performing a road test. See SAFETY PRECAUTIONS .

During the road test the following operating conditions must be fulfilled:

z

Coolant temperature must exceed 80 °C.

z

When the temperature is reached, the operating conditions

Idling

Part throttle

Enrichment

Wide open throttle

Overrun

must be attained several times.
