Fig. 49: Fuse 28 (Fuel Pump) From Fuse Holder
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Pull off supply line -1- (black markings) and collect leaking fuel with a cloth.

Fig. 50: Disconnecting Fuel Supply Line (Engine Codes BEV, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect pressure gauge V.A.G 1318, as shown, with adapters 1318/9 and 1318/17.

NOTE:

Fuse holder is behind access panel at far left end of dash.

NOTE:

To do this slide safety ring -2- into the union -1-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 51: Connecting Pressure Gauge V.A.G 1318 With Adapters 1318/9 And 1318/17 (Engine Codes
BEV, BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Open shut-off tap on pressure gauge. Handle points in direction of flow.

z

Reinstall fuse 28 (fuel pump) in fuse holder.

z

Start engine and run at idling speed.

z

Measure fuel pressure.

z

Specification: Approx. 4.0 bar

If the specification is not obtained:

z

Switch off ignition.

z

Check whether fuel pump can build up and maintain pressure. See FUEL PUMP, CHECKING .

z

Check fuel pressure regulator. See CHECKING FUEL PRESSURE REGULATOR .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



If the specification is obtained:

z

Switch off ignition.

z

Check for leaks and holding pressure (compound system). Watch pressure drop on gauge.

z

After 10 minutes there must be a residual pressure of at least 2.0 bar

If the holding pressure drops below 2.0 bar:

z

Start engine and run at idling speed.

z

Switch ignition off after pressure has built-up. Simultaneously, close pressure gauge V.A.G 1318 cutoff
tap. Handle is across through-flow direction (arrow).

Fig. 52: Closing Pressure Gauge V.A.G 1318 Cut-Off Tap
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Observe pressure drop (engine side) on gauge.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Multiport Fuel Injection (MFI) - New Beetle, 2.0L (AEG, AVH, AZG, BDC, BEV & BGD)



If the pressure drops again:

z

Check line connections, O-rings on fuel manifold and injectors for leaks.

z

Check pressure gauge for leaks.

If the pressure does not drop:

z

Check non-return valve of fuel pump, checking fuel pump non-return valve. See FUEL PUMP,
CHECKING .

z

Check fuel pressure regulator. See CHECKING FUEL PRESSURE REGULATOR .

Checking fuel pressure regulator

Requirements

z

Non-return valve for fuel pump OK, Checking. See FUEL PUMP, CHECKING

z

Fuel supply line OK

Work sequence

z

Remove cover in front of fuse holder.

z

Remove fuse 28 (fuel pump) from fuse holder.

NOTE:

Place a cloth around the connections to be loosened before removing pressure
gauge.
