z

Battery voltage must be at least 11.5 V

z

Camshaft Position (CMP) sensor must be OK, checking, see CAMSHAFT POSITION (CMP)
SENSOR -G40-, CHECKING

z

Engine speed sensor must be OK, checking, see ENGINE SPEED (RPM) SENSOR -G28-,
CHECKING

Test sequence

z

Disconnect 4-pin connector -1- off power output stage for ignition coils (arrow).

Fig. 9: Disconnecting Ignition Coil Power Output Stage 4-Pin Connector
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking voltage supply

z

Using multimeter and adapter cables from V.A.G 1594 measure supply voltage between contacts 1 + 2
and 1 + 4 of disconnected connector.

z

Switch on ignition.

Specification: Min. 11.5 V

z

Switch off ignition.

NOTE:

Ignition coils and final power output stages are one component and cannot be
replaced individually.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



Fig. 10: Identifying Ignition Coil Power Output Stage 4-Pin Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

If no voltage is present:

z

Check wire between 4 -pin connector contact 2 and relay plate for open circuit according to wiring
diagram.

Wire resistance: max. 1.5 ohm

Fig. 11: Identifying Ignition Coil Power Output Stage 4-Pin Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring between 4 -pin connector and Ground (GND) for open circuit according to wiring diagram.

z

Terminal 2 and Ground (GND)

z

Terminal 4 and Ground (GND)

Wire resistance: max. 1.5 ohm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



If there is no malfunction in the supply voltage:

z

Check activation, see CHECKING ACTIVATION .

Checking activation

z

Pull fuse No. 32 out of fuse holder.

Fig. 12: Identifying Fuses
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect diode test lamp V.A.G 1527 with adapter cables from V.A.G 1594 to contacts of disconnected
connector

Contacts 2 + 3

WARNING:

During the following test do not touch the connecting parts of the ignition
coils or test cables.

NOTE:

Removing fuse 32 interrupts the voltage supply to the injectors. Fuse
holder is located behind access panel at far left end of dash.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Ignition-Glow Plug System, 1.8L APH - New Beetle



Fig. 13: Identifying Ignition Coil Power Output Stage 4-Pin Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Operate starter and check ignition signal from engine control module.

LED must flicker

z

Switch off ignition.

When the LED flickers and the supply voltage is OK:

z

Replace relevant ignition coil with power output stage, see item 2 .

z

Check DTC memory, if necessary, repair any malfunctions and then erase DTC memory, see
DIAGNOSTIC TROUBLE CODE (DTC) MEMORY, CHECKING AND ERASING .

z

Read readiness code, see READINESS CODE, DISPLAYING . If DTC memory has been erased or
engine control module was disconnected from permanent positive, readiness code must be generated
again, see READINESS CODE, GENERATING .

If LED does not flicker:

z

Check wiring, see CHECKING WIRING .

Checking wiring

z

Remove inner plenum chamber cover, left:

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Connect test box V.A.G 1598/31 to control module wiring harness. Engine control module is not
connected by this action.

Fig. 14: Connecting Test Box V.A.G 1598/31
