Volkswagen New Beetle. Manual - part 1416

Fig. 193: Scan Tool Display - A/C System Signal To ECM (4 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Switch ON A/C by pressing "Auto" button and selecting lowest temperature.

z

A/C compressor must run.

z

Observe display in Display zone 3.

If specification not obtained:

z

Specified Value: 1 X 1 (A/C system signal)

Fig. 194: Scan Tool Display - A/C System Signal To ECM (5 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 195: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between following Test Box socket and A/C system using Wiring diagram.

Up to MY 1999

Socket 48

From MY 2000

Socket 34

z

Wire resistance: 1.5 ohm maximum

CAN-Bus, checking

1. Engine Control Module (ECM)

2. ABS control module

3. Transmission Control Module (TCM)

z

Only vehicles with automatic transmission

4. Airbag control module

5. Instrument cluster

6. CAN-Bus

NOTE:

The following list refers to Fig. 196 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 196: Identifying CAN-Bus Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Function

The Engine Control Module (ECM) (item -1-) communicates with the ABS control module (item -2-), the
Transmission Control Module (item -3-), the airbag control module (item -4-) and the instrument cluster (item -
5-) via a CAN-Bus (item -6-).

Function, continued

At least two control modules capable of CAN - Bus are connected by two wires (CAN-High and CAN-Low,
twisted together) and exchange information (messages). Missing information on the CAN-Bus will be
recognized as a malfunction by the ECM as well as by other CAN-Bus control modules.

All control modules have 120 W terminal resistors which make sure that the CAN-Bus can function without
fault.

Special tools and equipment

z

Multimeter (Fluke 83 or equivalent)

z

VW 1594 adapter set

z

Wiring diagram

z

VAG1598/21 Test box

Test conditions

z

Malfunction has been recognized by CAN-Bus OBD

z

ABS control module coded to CAN-Bus operation

Test sequence

z

Connect VAG1598/21 test box -1- to ABS control module wiring harness -2-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 197: Connecting VAG1598/21 Test Box To ABS Control Module Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check terminal resistor in Engine Control Module (ECM) by performing resistance measurement
between test box sockets 10 + 11.

z

Specified value: 115 to 135 W

If the resistance value is outside the specified range:

z

Replace Engine Control Module (ECM). See Engine Control Module (ECM), replacing .

If the resistance value is within the specified range:

z

Check CAN-Bus wiring using wiring diagram.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
