Volkswagen New Beetle. Manual - part 1414

Fig. 183: Scan Tool Display - A/C System Signals (1 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 184: Scan Tool Display - A/C System Signals (2 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -3- buttons to select Function 03: "Output Diagnostic Test Mode".



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Display will appear as shown:

Fig. 185: Scan Tool Display - A/C System Signals (3 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -Q- button to enter input.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Display will appear as shown:

Fig. 186: Scan Tool Display - A/C System Signals (4 Of 6)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press --> button.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
