Fig. 143: Scan Tool Display - Checking Cruise Control System (3 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Press buttons -0-, -0- and -6- to select "Display group 6".

z

Press -Q- button to enter input.

z

Observe display in Display zone 4.

Specification: 0

Fig. 144: Scan Tool Display - Checking Cruise Control System (4 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

If 255 is displayed in zone 4:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 145: Scan Tool Display - Checking Cruise Control System (5 Of 5)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Activate Cruise Control System. See CRUISE CONTROL SYSTEM, ACTIVATING AND
DEACTIVATING .

Vehicles with automatic transmission only

z

Take a test drive where vehicle reaches at least 30 km/h (approx. 19 mph) one time.

z

Switch OFF engine and leave selector lever in position 2, 3 or D.

z

Apply hand brake.

NOTE:

z

For vehicles with automatic transmissions; cruise control switch Voltage
supply first becomes available when the vehicle exceeds a speed of 30
km/h (approx. 19 mph) with the Range selector lever in position 2, 3 or D.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Check specification Display zone 3.

Fig. 146: Scan Tool Display - Checking Cruise Control System (Automatic Transmission) (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Checking requirements

z

Voltage supply is also available during idle as long as a driving Range
other than 1 or R is selected.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle
