Fig. 138: Scan Tool Display - Coding Engine Control Module (2 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Press -0- and -7- buttons to select Function 07: "Code control module".

z

Press -Q- button to enter input.

Display will appear as shown:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 139: Scan Tool Display - Coding Engine Control Module (3 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Enter appropriate code number for this vehicle. Coding tables. See Engine control module coding, m.y.
1998-1999 and Engine control module coding, from m.y. 2000 .

Engine control module coding, m.y. 1998-1999

TRANSMISSION CODING M.Y. 1998-1999 (EXCEPT ECM VERSION: 038 906 018 BD)

TRANSMISSION CODING M.Y. 1998-1999 (ONLY FOR ECM VERSION: 038 906 018 BD)

Engine control module coding, from m.y. 2000

Transmission Coding From M.Y. 2000

z

Press -Q- button to enter input.

Display will appear as shown (I.D. example only):

Transmission

ABS

Coding

Automatic

Yes

00001

Manual

Yes

00002

Automatic

No

00004

NOTE:

The following code is valid for ECM version: 038 906 018 BD.

Transmission

ABS

Coding

Manual

No

00002

Transmission

ABS

Coding

Automatic

Yes

00001

Manual

Yes

00002

Manual

No

00002

Automatic

No

00004
