Fig. 81: Identifying 10-Pin -G81- Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Measure Fuel Temperature sensor resistance between terminals 4 + 7.

Specification chart:

Scale A shows resistance values for temperature range 0 to 50 °C and scale B the values for temperature range
50 to 100 °C.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 82: Fuel Temperature Sensor Resistance Versus Temperature Range Graph
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Examples:



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

30 °C corresponds to a resistance between 1500 and 2000 ohm

z

80 °C corresponds to a resistance between 275 and 375 ohm

If specification not obtained:

z

Replace Diesel injection pump. See DIESEL INJECTION PUMP, REMOVING AND
INSTALLING .

z

Display the Readiness code. See READINESS CODE, DISPLAYING .

If DTC memory was erased:

z

Set the readiness code. See READINESS CODE, SETTING .

If specification obtained:

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 83: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and harness connector using Wiring diagram.

Fig. 84: Identifying 10-Pin Harness Connector Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Up to MY 1999

z

Terminal 7 + socket 53

z

Terminal 4 + socket 76

From MY 2000

z

Terminal 7 + socket 111
