2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 134: Scan Tool Display - Replacing Engine Control Module (2 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Press -0- and -6- buttons to select Function 06: "End output"

z

Press -Q- button to enter input.

Display will appear as shown:

Fig. 135: Scan Tool Display - Replacing Engine Control Module (3 Of 3)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Switch OFF ignition.

z

Remove inner covers on plenum.

See INTERIOR TRIM .

z

Carefully pry off retainer bar with screwdriver (arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 136: Prying Off ECM Retainer Bar With Screwdriver
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Release harness connector from Engine Control Module (ECM) and pull off.
