Intake manifold change-over flap must (after switching OFF ignition) close back and after approx. 3
seconds re-open.

If change-over does not occur, perform following checks:

z

Check intake manifold change-over flap mechanics for freedom of movement by manually operating the
rods by hand.

z

Check vacuum function of positioning actuator using VAG1390 hand vacuum pump.

z

Check vacuum lines for correct connection.

If mechanical components OK:

z

Check Intake Manifold Change-over Valve - N239-.

Test sequence

z

Disconnect -N239- harness connector.

z

Measure resistance between -N239- terminals.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Fig. 129: Measuring Resistance Between Change-Over Valve For Intake Manifold Flap -N239-
Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Specification: 25 to 45 ohm

If specification not obtained:

z

Replace Intake Manifold Change-over Valve -N239-.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



If specification obtained:

z

Switch Fluke 83 multimeter to 20 Volt range.

z

Connect multimeter between terminals 1 and 2 of ECM connector using jumper wires from VW 1594
Adapter kit.

Fig. 130: Identifying Change-Over Valve For Intake Manifold Flap -N239- Harness Connector
Terminals
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Start engine and let idle.

z

Specification: between 5 and 6 Volts

z

Switch OFF ignition.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

Voltage value must rise to 11 to 15 Volts (battery Voltage) and after approx. 3 seconds fall to 0 Volts.

If Voltage values do not change as described:

z

Connect VAG1598/22 (or 1598/31) Test Box to ECM wiring harness.

Fig. 131: Connecting VAG1598/22 (Or 1598/31) Test Box To ECM Wiring Harness
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Check wiring for open circuit between Test Box and connector using Wiring diagram.
