When working on the fuel supply/injection system, pay careful attention to the following "6 rules":

z

Thoroughly clean all unions and the adjacent areas before disconnecting.

z

Place removed parts on a clean surface and cover over but do NOT use fluffy cloths (lint contamination)!

z

Carefully cover opened components or seal over, if the repair cannot be carried out immediately.

z

Only install clean components:

Only unpack replacement parts immediately prior to installation.

Do not use parts that have been stored loose e.g. in tool boxes.

z

When the system is open:

Do not work with compressed air if it can be avoided.

Do not move the vehicle unless absolutely necessary.

z

Make sure that no Diesel fuel runs onto the coolant hoses. Clean contaminated hoses immediately.
Always replace affected hoses.

Diesel injection system, component locations overview

Components A, B and C are not shown on the illustration.

A. Brake vacuum vent valve switch for cruise control/diesel fuel injection -F47- and Brake light switch

-F63-

z

Together in one housing in footwell on brake pedal

B. Throttle Position (TP) Sensor - G79-

z

in footwell on throttle pedal

See THROTTLE POSITION SENSOR, CHECKING .

z

In case of malfunction it is displayed as Throttle Position sensor -G69-

C. Clutch vacuum vent valve switch -F36-

z

in footwell on clutch pedal

1. EGR valve

2. Change-over valve for intake manifold flap -N239-

3. Needle Lift Sensor -G80-

4. EGR vacuum regulator solenoid valve -N18-

5. Diesel Direct Fuel Injection (DFI) Engine Control Module (ECM) -J248-

NOTE:

The following list refers to Fig. 1 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

with Barometric Pressure (BARO) sensor -F96-

z

tighten nut for ground wire (located forward of ECM) to 9 +/- 1 Nm (80 +/- 9 in. lb)

6. Wastegate bypass regulator valve -N75-

7. Mass Air Flow (MAF) Sensor -G70-

8. Engine Coolant Temperature (ECT) Sensor -G62-

9. Engine speed (RPM) sensor -G28-

10. Harness connector

z

for Needle lift sensor -G80-

11. Harness connector

z

for Engine Speed sensor -G28-

z

for Cold Start injector -N108-

12. Harness connector

z

for Fuel temperature sensor -G81-

z

for Quantity adjuster -N146-

z

for Modulating piston displacement sensor -G149-

z

for Fuel shut-off valve -N109-

13. Cold start injector -N108-

14. Fuel shut-off valve -N109-

15. Injection pump Quantity adjuster -N146-

z

with Fuel temperature sensor

z

with Quantity adjuster -N146-

z

with Modulating piston displacement sensor -G149-

16. Manifold Absolute Pressure (MAP) sensor -G71- and Intake Air Temperature (IAT) sensor -G72-

Fig. 1: Identifying Diesel Injection System Component Locations (1.9L ALH)



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

Diesel injection pump, servicing

z

Observe Rules of cleanliness. See RULES FOR CLEANLINESS .

z

Removing and installing Diesel injection pump. See DIESEL INJECTION PUMP, REMOVING AND
INSTALLING .

z

Dynamically checking and adjusting Diesel injection pump. See START OF INJECTION,
DYNAMICALLY CHECKING AND ADJUSTING .

1. 20 Nm (15 ft lb) + 1/4 turn (90 °) further

{

Always replace

2. Injection pump sprocket

z

Removing. See DIESEL INJECTION PUMP, REMOVING AND INSTALLING .

3. Nut

z

for hub

4. Union

z

25 Nm (18 ft lb)

z

for supply line

z

from fuel filter

5. Diesel injection pump

z

with Quantity adjuster (metering)

z

with Quantity adjuster -N146-

z

with Modulating piston displacement sensor -G149-

z

with Fuel temperature sensor

6. Fuel shut off valve

z

40 Nm (30 ft lb)

7. Union

z

for return line

8. Return line

z

to control valve/fuel filter

9. 25 Nm (18 ft lb)

10. Fuel injector lines

NOTE:

The following list refers to Fig. 2 .

CAUTION: Do not loosen nut or basic setting of pump may change. This cannot

be reset using normal workshop equipment.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Diesel Fuel Injection, 1.9L ALH - New Beetle



z

25 Nm (18 ft lb)

„

Remove with 3035

„

Always remove fuel line cluster as an assembly

„

Do not bend, kink or alter shape

11. Union

z

45 Nm (33 ft lb)

z

with pressure valve

12. 25 Nm (18 ft lb)

13. 3rd cylinder Fuel injector

z

includes Needle lift sensor -G80-

z

Removing and installing. See FUEL INJECTORS, REMOVING AND INSTALLING .

z

Servicing. See FUEL INJECTORS, SERVICING .

14. 20 Nm (15 ft lb)

15. Retainer

16. Mounting

17. Heat shield

{

Always replace

18. 10 Nm (7 ft lb)

19. Cold Start injector -N108-

z

Checking. See FUNCTION 03: OUTPUT DIAGNOSTIC TEST MODE, PERFORMING .

20. Strainer

21. O-ring

{

Always replace

22. 25 Nm (18 ft lb)

23. Timing cover

{

Replace O-ring if leaking. See DIESEL INJECTION PUMP TIMING COVER O-RING,
REPLACING .

24. Sleeve

z

with nut

25. Assembly bracket

z

Removing and installing. See ENGINE, DISASSEMBLING AND ASSEMBLING .

26. 25 Nm (18 ft lb)
