Screw new securing bolt into scotch block until injector unit can still be turned lightly.

z

Align injector unit at right angles to bearing pedestals of camshaft.

z

Use a vernier gauge (measuring range at least 400 mm) and check dimension "a" from cylinder head
outer edge to round surface of injector unit. See Fig. 13 and DIMENSION "A" FROM CYLINDER
HEAD OUTER EDGE TO ROUND SURFACE OF INJECTOR UNIT .

DIMENSION "A" FROM CYLINDER HEAD OUTER EDGE TO ROUND SURFACE OF
INJECTOR UNIT

Fig. 13: Checking Dimension "a" From Cylinder Head Outer Edge To Round Surface Of Injector
Unit
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Align injector unit again, if necessary, and tighten securing bolt as follows:

z

Tighten securing bolt to 12 N.m plus an additional 270° (3/4 turn). Turning further can be done in several
stages.

z

Position rocker shaft and tighten new securing bolts as follows:

Cylinder

Dimension "a"

1

333.0 +/-0.8 mm

2

245.0 +/-0.8 mm

3

153.6 +/-0.8 mm

4

65.6 +/-0.8 mm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 14: Positioning Rocker Shaft And Tightening New Securing Bolts
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten inner bolts -2- first and then outer screws -1- hand-tight. Then in same sequence to:

20 N.m and 90°(1/4 turn further).

z

Install a dial gauge on injector unit adjustment screw as shown in Fig. 15 .

Fig. 15: Installing Dial Gauge On Injector Unit Adjustment Screw
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Turn crankshaft in engine direction of rotation, until rocker lever roller is positioned on actuating cam
point.

Roller side (arrow -A-) is at highest point

Dial gauge (arrow -B-) is at lowest point

z

Remove dial gauge.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



z

Install adjustment screw into rocker lever until a considerable resistance can be felt (injector element is
onto limit stop).

z

Turn adjustment screw back from top around 225°.

z

Hold adjustment screw in this position and tighten lock nut to 30 N.m.

Fig. 16: Holding Adjustment Screw In Position And Tightening Lock Nut
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Position injector unit connector and install cylinder head cover and toothed belt guard, upper part. See
CYLINDER HEAD, REMOVING AND INSTALLING .

ENGINE CONTROL MODULE

ENGINE CONTROL MODULE, REMOVING AND INSTALLING

z

Before removing engine control module check control module identification and thereby previous control
module coding, See ENGINE CONTROL MODULE (DTC) MEMORY, READING AND
ERASING .

Removing

z

Switch ignition off.

z

Remove inner cover on left hand side of plenum chamber.

See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING .

z

Carefully press off retaining tab (arrow).



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW



Fig. 17: Pressing Off Engine Control Module Retaining Tab
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Unlock engine control module connector and remove.

Installing

z

Install new control module and press to left.

z

Connect connector and lock in position.

z

Check previous coding and code new control module, See COMPONENTS, ADAPTING .

ENGINE CONTROL MODULE (DTC) MEMORY, READING AND ERASING

Special tools and equipment

z

VAS 5051 Vehicle Diagnosis, Testing and Information System



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Diesel Fuel Injection - New Beetle, 1.9L 4-Cyl. - BEW
