11. 20 Nm

12. Tunnel bridge

13. 40 Nm

14. Washer

Fig. 3: Identifying Mufflers With Mounts Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installation position of double clamp

Fig. 4: Identifying Installation Position Of Double Clamp
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Work procedure

z

Position new double clamp as shown with approx. 5 mm distance to marking -A- and tighten it.
Tightening torque 40 Nm

z

Marking A (arrow 1) for vehicles with automatic transmission



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



z

Marking S (arrow 2) for vehicles with manual transmission

Installation position of muffler suspension

z

Angled side at foot of suspension (arrow) faces front of vehicle.

Fig. 5: Identifying Installation Position Of Muffler Suspension
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Separation point at exhaust pipe

Fig. 6: Identifying Separation Point At Exhaust Pipe
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Recommended special tools and equipment

z

Body saw, e.g. VAG1523

Work procedure

z

Separate exhaust pipe at right angle to separation point (arrow 2).

z

Position replacement double clamp -4- in installation position at the edge markings (arrows 1 and 3) as
shown when installing. Tightening torque 40 Nm



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



Aligning front muffler parallel

z

Mounting bolt at exhaust pipe must be parallel to tunnel bridge (dimension -x- same at left and right).

Fig. 7: Aligning Front Muffler Parallel
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Catalytic converter, checking

Function test

z

Select the measuring value "Test-ID 01: Catalytic converter" and check whether the specified values are
being reached. See DIAGNOSTIC MODE 6: CHECK TEST RESULTS OF COMPONENTS THAT
ARE NOT CONTINUOUSLY MONITORED .

z

End diagnosis and switch ignition off.

If the specified values are exceeded:

z

Replace the front exhaust pipe with catalytic converter:

z

Vehicles with engine code AEG. See item 13 .

z

Vehicles with engine code AVH, AZG, BDC. See item 10 .

Continuation for all vehicles

z

Erase DTC memory of Engine Control Module (ECM). See DIAGNOSTIC MODE 4: RESET/ERASE
DIAGNOSTIC DATA .

z

Generate readiness code. See READINESS CODE, GENERATING .

SECONDARY AIR INJECTION (AIR) SYSTEM

WARNING:

Observe the following for all installations, especially in engine



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



Function

Air is blown behind the exhaust valves by the Secondary Air Injection (AIR) system during a cold start.
Thereby, the emission gas is enriched with oxygen, initiating a secondary combustion and thereby shortening
the warm-up phase of the catalytic converter. Activation occurs from Motronic Engine Control Module (ECM) -
J220- via Secondary Air Injection (AIR) Pump Relay -J299- to combination valve.

Secondary Air Injection (AIR) system components, removing and installing:

z

Vehicles with engine code AEG, AVH, AZG. See PARTS OF SECONDARY AIR INJECTION (AIR)
SYSTEM, REMOVING AND INSTALLING (VEHICLES WITH ENGINE CODE AEG, AVH,
AZG) .

z

Vehicles with engine code BDC. See PARTS OF SECONDARY AIR INJECTION (AIR) SYSTEM,
REMOVING AND INSTALLING (VEHICLES WITH ENGINE CODE BDC) .

Check secondary air system for proper seal. See SECONDARY AIR INJECTION (AIR) SYSTEM,
CHECKING FOR PROPER SEAL .

Parts of Secondary Air Injection (AIR) system, removing and installing (Vehicles with engine code AEG, AVH, AZG)

1. Connector

z

only for vehicles with engine code AEG up to 05.99

z

black, 2-pin

z

for Secondary Air Injection (AIR) solenoid valve

z

before disconnecting, mark allocation to component

2. Secondary Air Injection (AIR) Solenoid Valve -N112-*

z

only for vehicles with engine code AEG up to 05.99

z

Checking. See SECONDARY AIR INJECTION (AIR) SOLENOID VALVE (VEHICLES
WITH ENGINE CODE AEG UP TO 05.99), CHECKING .

3. to fork of vacuum line for brake booster

z

only for vehicles with engine code AEG up to 05.99

compartment due to lack of room:

z

Route lines of all types (e.g. for fuel, hydraulic, EVAP canister
system, coolant and refrigerant, brake fluid, vacuum) and electrical
wiring so that the original path is followed.

z

Watch for sufficient clearance to all moving or hot components.

NOTE:

Components marked with * are tested via On Board Diagnostic (OBD). See
DIAGNOSTIC MODE 3: CHECK DTC MEMORY .

NOTE:

The following list refers to Fig. 8 .
