Volkswagen New Beetle. Manual - part 1286

3. 25 Nm

4. 30 Nm

5. 25 Nm

z

replace

6. Connection tube

7. Connecting piece, 35 Nm

8. 4-pin harness connector

z

Black

z

For Heated Oxygen Sensor (HO2S) 1 before Three Way Catalytic Converter (TWC) -G39- and
Oxygen Sensor (O2S) heater -Z19-

z

Component location: At right vehicle underside

z

Component location: At right vehicle underside

9. Heated Oxygen Sensor (HO2S) -G39- bank 1*, 50 Nm

z

Component location: in front catalytic converter

z

Only use "G 052 112 A3" to grease thread; do not let "G 052 112 A3" get onto slit of oxygen
sensor

z

Voltage supply of oxygen sensor heater via Fuel Pump (FP) Relay -J17-

z

Check oxygen sensor heater for Oxygen Sensor (O2S) before Three Way Catalytic Converter
(TWC). See OXYGEN SENSOR HEATER FOR OXYGEN SENSOR BEFORE THREE
WAY CATALYTIC CONVERTER (TWC), CHECKING .

z

Check Oxygen Sensor (O2S) and oxygen sensor control before Three Way Catalytic Converter
(TWC). See CHECK OXYGEN SENSOR AND OXYGEN SENSOR REGULATION
BEFORE CATALYTIC CONVERTER .

10. Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) -G130- bank 1*, 50 Nm

z

Component location: In rear catalytic converter

z

Only use "G 052 112 A3" to grease thread; do not let "G 052 112 A3" get onto slit of oxygen
sensor

z

Voltage supply of oxygen sensor heater via Fuel Pump (FP) Relay -J17-

z

Check oxygen sensor heater for Oxygen Sensor (O2S) behind Three Way Catalytic Converter
(TWC). See OXYGEN SENSOR HEATER FOR OXYGEN SENSOR BEHIND THREE
WAY CATALYTIC CONVERTER (TWC), CHECKING .

z

Check Oxygen Sensor (O2S) and oxygen sensor control behind Three Way Catalytic Converter
(TWC). See CHECK OXYGEN SENSOR AND OXYGEN SENSOR REGULATION
BEHIND CATALYTIC CONVERTER .

11. 4-pin harness connector

z

brown

z

For Heated Oxygen Sensor (HO2S) 2 behind Three Way Catalytic Converter (TWC) -G130- and
heater for lambda-probe 1 -Z29-

z

Component location: At right vehicle underside

12. to front muffler



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



z

See item 1 .

13. Front exhaust pipe with catalytic converter

z

Check catalytic converter. See CATALYTIC CONVERTER, CHECKING .

14. 40 Nm

z

replace

15. Bracket

16. Seal

z

replace

17. Exhaust manifold

18. Heat shield

Fig. 1: Identifying Exhaust Manifold, Front Exhaust Pipe With Three Way Catalytic Converter
And Attachments (Vehicles With Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Exhaust manifold, front exhaust pipe with Three Way Catalytic Converter (TWC) and attachments (vehicles with
engine code AVH, AZG, BDC)

1. Heat shield

2. Heated Oxygen Sensor (HO2S) -G39- bank 1*, 50 Nm

z

Component location: In exhaust manifold

z

Use "G5" to grease thread only; do not let "G5" get onto slits of oxygen sensor body

z

Voltage supply of oxygen sensor heater via Fuel Pump (FP) Relay - J17-

z

Check oxygen sensor heater for Oxygen Sensor (O2S) before Three Way Catalytic Converter
(TWC). See OXYGEN SENSOR HEATER FOR OXYGEN SENSOR BEFORE THREE
WAY CATALYTIC CONVERTER (TWC), CHECKING .

z

Check Oxygen Sensor (O2S) and oxygen sensor control before Three Way Catalytic Converter

NOTE:

The following list refers to Fig. 2 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



(TWC). See CHECK OXYGEN SENSOR AND OXYGEN SENSOR REGULATION
BEFORE CATALYTIC CONVERTER .

3. 10 Nm

4. 25 Nm

5. 25 Nm

z

replace

6. Connection tube

7. Connecting piece, 35 Nm

8. Exhaust manifold

9. Seal

z

replace

10. Front exhaust pipe with catalytic converter

z

Check catalytic converter. See CATALYTIC CONVERTER, CHECKING .

11. Oxygen Sensor (O2S) Behind Three Way Catalytic Converter (TWC) - G130- bank 1*, 50 Nm

z

Component location: In rear catalytic converter

z

Only use "G 052 112 A3" to grease thread; do not let "G 052 112 A3" get onto slit of oxygen
sensor

z

Voltage supply of oxygen sensor heater via Fuel Pump (FP) Relay - J17-

z

Check oxygen sensor heater for Oxygen Sensor (O2S) behind Three Way Catalytic Converter
(TWC). See OXYGEN SENSOR HEATER FOR OXYGEN SENSOR BEHIND THREE
WAY CATALYTIC CONVERTER (TWC), CHECKING .

z

Check Oxygen Sensor (O2S) and oxygen sensor control behind Three Way Catalytic Converter
(TWC). See CHECK OXYGEN SENSOR AND OXYGEN SENSOR REGULATION
BEHIND CATALYTIC CONVERTER .

12. 10 Nm

13. Heat shield

z

for catalytic converter

14. 10 Nm

15. Spring nut

16. Suspended mount

17. 25 Nm

18. 40 Nm

z

replace

19. Seal

z

replace



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE PERFORMANCE Exhaust System Emission Controls, 2.0L Generic Scan Tool - New Beetle



Fig. 2: Identifying Exhaust Manifold, Front Exhaust Pipe With Three Way Catalytic Converter And
Attachments (Vehicles With Engine Code AVH, AZG, BDC)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Mufflers with mounts

1. From Three Way Catalytic Converter (TWC)

2. Double clamp

z

replace

z

Note installed position. See Installation position of double clamp .

3. 25 Nm

4. Suspended mount

z

Note installed position. See Installation position of muffler suspension .

5. Front muffler

z

At factory, front and rear mufflers are installed as a single component. Replacement front and rear
mufflers are supplied separately, with replacement double clamp for connecting joint.

z

Install front muffler parallel. See Aligning front muffler parallel .

6. Separating point

z

Separation point at exhaust pipe. See Separation point at exhaust pipe .

7. Suspended mount

8. Bracket

9. Rear muffler

z

At factory, front and rear mufflers are installed as a single component. Replacement front and rear
mufflers are supplied separately, with replacement double clamp for connecting joint.

10. Suspended mount

z

With retainer ring

NOTE:

The following list refers to Fig. 3 .
