Volkswagen New Beetle. Manual - part 1255

Fig. 17: Pulling Vacuum Hose From Secondary Air Injection (AIR) Solenoid Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Connect hand vacuum pump V.A.G 1390 to vacuum hose -1-.

z

Remove pressure hose at secondary air pump motor and blow in lightly (arrow).

z

Combination valve must be closed

z

Operate hand vacuum pump.

z

Combination valve must open

If the combination valve does not open:

z

Replace combination valve.

Checking combination valve without vacuum connection, from Model Year 2000, 06.99

Requirements

z

No fault stored in fault memory. See ENGINE CONTROL MODULE FAULT MEMORY,
INTERROGATION AND ERASING .

z

Perform final control diagnosis. See COMPONENTS AND FUNCTIONS, ADAPTING .

z

Hose unions must not leak

Work sequence

z

Remove engine cover.

z

Remove pressure hose (arrow) from secondary air injection pump motor.

NOTE:

Do not use compressed air during the following check!

NOTE:

Do not use compressed air during the following check!



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 18: Removing Pressure Hose From Secondary Air Injection Pump Motor
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Blow lightly into pressure hose to combination valve.

z

Combination valve must be closed.

z

Blow strongly into pressure hose to combination valve.

z

Combination valve must open.

When the combination valve does not open or is continuously open:

z

Replace combination valve.

COMBINATION VALVE, REMOVING AND INSTALLING

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G 1331 Torque wrench (5...50 N.m)

NOTE:

To release, press buttons together on hose coupling.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 19: Identifying V.A.G 1331 Torque Wrench
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VAS 5085 Step ladder

Fig. 20: Identifying VAS 5085 Step Ladder
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

From above:

z

Remove engine cover.

z

Remove intake manifold upper part. See INTAKE MANIFOLD UPPER PART, REMOVING AND
INSTALLING .

z

Pull pressure and vacuum hoses off combination valve.

z

Loosen screwed on connections on connection pipe and remove pipe.

NOTE:

Always replace seals, gaskets and O-rings.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



From below:

z

Remove middle insulation tray.

See NOISE INSULATION, ASSEMBLY OVERVIEW .

z

Disconnect connector for Heated Oxygen Sensor (HO2S) -G39-.

z

Remove right side inner constant velocity joint protective cover from engine if installed.

z

Unbolt connecting pipe on exhaust manifold.

z

Remove warm air collector plate with combination valve.

Fig. 21: Removing Warm Air Collector Plate With Combination Valve
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Guide a 5 mm hex bit from 3/8"drive socket set into holes -3- of warm air collector plate -1- and remove
bolts -4- for combination valve -2-.

z

Remove combination valve.

Installing

The rest of the assembly is basically in reverse order to the disassembly sequence.

SECONDARY AIR INJECTION PUMP MOTOR, CHECKING

Requirements

z

No fault stored in fault memory. See ENGINE CONTROL MODULE FAULT MEMORY,

NOTE:

z

Thoroughly clean contact surfaces between combination valve and warm
air collector plate.

z

Replace seal.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)
