z

Activation via AIR pump relay -J299-

z

Checking function. See SECONDARY AIR INJECTION PUMP MOTOR, CHECKING

7. 10 N.m

8. Retainer

z

For secondary air injection pump motor

z

Fastened to intake manifold

9. Connector

z

2-pin

10. 25 N.m

11. Intake manifold lower part

12. To union on exhaust manifold

13. 40 N.m

14. Connecting pipe

15. Nuts/bolts, 60 N.m

16. Warm air collector plate

z

With mounting for combination valve

17. Seal

z

Replace

Fig. 13: Exploded View Of Secondary Air Injection (AIR) Pump Motor (Engine Code AEG)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Engine codes: BDC, BGD

1. Combination valve

NOTE:

The following list refers to items in Fig. 14 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



z

Checking. See COMBINATION VALVE, CHECKING

z

To replace, remove warm air collector plate

z

Removing and installing. See COMBINATION VALVE, REMOVING AND INSTALLING

2. O-ring

z

Replace

3. Pressure hose

z

Check if seated securely

z

Press together at front to release

4. Intake hose

z

For secondary air injection pump

z

Check if seated securely

z

Press together at front to release

5. To air cleaner

6. Secondary Air Injection (AIR) pump motor -V101-

z

Activation via AIR pump relay -J299-. See Secondary Air Injection (AIR) pump relay -J299-

z

Checking function. See SECONDARY AIR INJECTION PUMP MOTOR, CHECKING

7. Connector

z

2-pin

8. 10 N.m

9. 25 N.m

10. 15 N.m

11. Retainer

z

For secondary air injection pump motor

z

Secured to intake manifold

12. Intake manifold lower part

13. 10 N.m

14. To union on exhaust manifold

15. 40 N.m

16. Connecting pipe

17. Nuts/bolts, 60 N.m

18. Warm air collector plate

z

With intake manifold support

z

With mounting for combination valve

19. Seal

z

Replace



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



Fig. 14: Exploded View Of Secondary Air Injection (AIR) Pump Motor (Engine Codes BDC And BGD)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Secondary Air Injection (AIR) pump relay -J299-

Fig. 15: Identifying Secondary Air Injection (AIR) Pump Relay
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Location: in protective housing for relays in engine compartment (pushed into cable guide next to brake master
cylinder).

Distinguishing features: Control number 100

NOTE:

z

The relay locations may differ depending on the level of vehicle
equipment. For the latest control numbers and installation locations:

See appropriate WIRING DIAGRAMS articles.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Exhaust System, Emission Controls - 2.0L New Beetle (AEG, AVH, AZG, BDC, BEV & BGD)



COMBINATION VALVE, CHECKING

Checking combination valve with vacuum connection, up to Model Year 1999, 05.99

Checking combination valve without vacuum connection, from Model Year 2000, 06.99. See CHECKING
COMBINATION VALVE WITHOUT VACUUM CONNECTION, FROM MODEL YEAR 2000, 06.99

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

V.A.G 1390 Hand vacuum pump

Fig. 16: Identifying V.A.G 1390 Hand Vacuum Pump
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Requirements

z

No fault stored in fault memory. See ENGINE CONTROL MODULE FAULT MEMORY,
INTERROGATION AND ERASING .

z

Perform final control diagnosis. See COMPONENTS AND FUNCTIONS, ADAPTING .

z

Vacuum lines and hose connections free of leaks.

z

Vacuum lines not blocked/kinked.

Work sequence

z

Remove engine cover.

z

Pull vacuum hose -1- off at Secondary Air Injection (AIR) solenoid valve -N112- -2-.

z

Disconnect the battery Ground strap first if tools are required to pull relays
or control modules out of the relay plate.

z

Before disconnecting the battery Ground strap obtain the code for radios
with anti-theft coding.
