Fig. 133: Exploded View Of Lubrication System Components (Engine Codes BDC, BGD) 3. Cylinder block 4. Dipstick z Oil level must not exceed max. mark! z Markings. SeeFig. 136 5. Dipstick guide z Fastened to intake manifold z Pull off to extract oil 6. Guide tube 7. Oil spray jet z For piston cooling 8. Pressure relief valve, 27 N.m 9. Oil pump with balancer shaft gear assembly z With pressure relief valve of 12 bar z Removing and installing. See OIL PUMP WITH BALANCER SHAFT GEAR ASSEMBLY, z Disassembling and assembling. See Oil pump with balancer shaft gear assembly, disassembling 10. 15 N.m + 1/4 turn (90°) further z Observe different lengths of bolts. See , Fig. 137 11. 15 N.m 12. Sump z Clean sealing surface before installing z Insert with silicone sealant D 176 404 A2. See OIL SUMP, REMOVING AND INSTALLING z Removing and installing. See OIL SUMP, REMOVING AND INSTALLING 13. Seal z Replace z Cut open seals which have been rolled on 14. Oil drain plug, 30 N.m 15. Chain sprocket z Observe installed position 16. 20 N.m 17. Chain guard 18. Chain Part I (Engine code BEV)
2003 Volkswagen New Beetle GLS 1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD
|
