Valve guides, replacing

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

3121 Drift

Fig. 125: Identifying 3121 Drift
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

3120 Reamer and cutting fluid

Fig. 126: Identifying 3120 Reamer & Cutting Fluid
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Clean and check cylinder head. Cylinder heads in which valve seats can no longer be reworked. Note
minimum dimension. See VALVE SEATS, REWORKING . Cylinder heads which have already been
machined to minimum dimension, should not have valve guides replaced. See Fig. 102 .

z

Press out worn valve guides with drift 3121 from camshaft side (repair version guides, with a shoulder,



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



from combustion chamber side).

Installing

z

Press in new guides, moistened with oil, from camshaft side onto shoulder in cold cylinder head using
drift 3121.

z

Ream valve guide using hand reamer 3120. Always use cutting fluid when doing this.

z

Reworking valve seats. See VALVE SEATS, REWORKING .

Valve stem seals, replacing

(with cylinder head installed)

Special tools, equipment, testers, measuring instruments and auxiliary items required

z

2036 Assembly device

z

3047A Puller

z

3122 B Spark plug wrench

z

3129 Installation tool

z

T10112 Installation tool

z

V.A.G 1331 Torque wrench (5..50 N.m)

Fig. 127: Identifying Special Tools (1 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

VW 541/1A Lever

NOTE:

When the shoulder on guide makes contact the pressure must not exceed
10kN (approx. 1.0 t) otherwise the shoulder may break off.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

VW 541/5 Press piece

z

VW 653/3 Pressure hose

Fig. 128: Identifying Special Tools (2 Of 2)
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Removing

z

Remove camshaft. See CAMSHAFT, REMOVING AND INSTALLING .

z

Take out hydraulic lifter and place down with running surface downward. Ensure hydraulic lifters are not
interchanged when doing this.

z

Disconnect spark plug connectors with tool T10112

z

Remove spark plugs with spark plug wrench 3122B.

z

Set piston of appropriate cylinder to "bottom dead centre (BDC)".

z

Mount assembly device 2036 and adjust mountings to height of studs.

Fig. 129: Mounting Assembly Device 2036, VW 653/3 & VW 541/1A
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



z

Screw pressure hose VW 653/3 into spark plug thread.

z

Connect pressure hose to compressed air supply of at least 6 bar.

z

Remove valve springs with assembly lever VW 541/1A and thrust piece VW 541/5.

z

Pull off valve stem seals with 3047A.

Fig. 130: Removing Valve Stem Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Installing

z

Place plastic sleeve -A- supplied on appropriate valve stem. This will prevent new valve stem seal -B-
being damaged.

Fig. 131: Installing Valve Stem Seal
Courtesy of VOLKSWAGEN OF AMERICA, INC.

NOTE:

Tight keepers can be loosened by tapping lightly on the lever.
