Fig. 54: Installing Drive Plate With Shim
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Tighten bolts to 60 N.m and 90° (1/4turn) further (turning further can be done in several stages).

CRANKSHAFT, REMOVING AND INSTALLING

Engine codes AEG, AVH, AZG, BEV

NOTE:

z

Before removing the crankshaft, prepare a suitable place to set it to
ensure that the sensor wheel (item -8-) is free and does not get damaged.

z

When stripping and assembling the engine it should be secured to the
engine frame with engine and transmission bracket VW 540 and
supplementary set VW 540/1B.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



1. Oil pump

z

With pressure relief valve of 12 bar

z

Before installing, check that both dowel sleeves for centralizing oil pump/cylinder block are
installed

z

Removing and installing. See LUBRICATION SYSTEM COMPONENTS, REMOVING AND
INSTALLING

2. 15 N.m

3. Chain sprocket

z

For oil pump drive

4. Bearing shells 1,2, 3, 4 and 5

z

Classification for ordering spare parts. See Fig. 57

z

For bearing cap without oil groove

z

For cylinder block with oil groove

z

Do not interchange used bearing shells (mark)

5. 65 N.m + 90° (1/4 turn) further

z

Replace

z

Threaded along complete length (screw)

z

Tighten to 65 N.m when measuring crankshaft radial clearance

6. Bearing cap

z

Bearing cap 1: Poly V-belt pulley end

z

Bearing cap 3 with recesses for thrust washers

z

Bearing shell retaining lugs (cylinder block/bearing cap) must be on same side

7. Bearing shell 3

z

See item - 4 -

z

Do not interchange used bearing shells (mark)

8. Sensor wheel

z

Replace

z

For Engine speed (RPM) sensor -G28-

z

Can only be installed in one position. Holes are offset

9. 10 N.m + 1/4 turn (90°) further

z

Replace

10. Thrust washer

z

For bearing 3 bearing cap

z

Production version (1-part), upper thrust washers discontinued, item -12-

z

Observe method of securing

z

Lettering faces mounting bracket

NOTE:

The following list refers to items in Fig. 55 .



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



11. Crankshaft

z

Axial clearance, new: 0.07 ... 0.23 mm; Wear limit: 0.30 mm

z

Check radial clearance with Plastigage, new: 0.01 ... 0.04 mm; Wear limit: 0.15 mm

z

Do not rotate crankshaft when checking radial clearance

z

Crankshaft dimensions. See CRANKSHAFT DIMENSIONS

12. Thrust washer

z

For cylinder block, bearing 3

z

Spare part version (2-part), lower thrust washers are only semicircular

z

Lettering faces mounting bracket

Fig. 55: Exploded View Of Crankshaft Assembly (Engine Codes AEG, AVH, AZG, BEV)
Courtesy of VOLKSWAGEN OF AMERICA, INC.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - New Beetle, 2.0L 4-Cyl. - AEG, AVH, AZG, BDC, BEV, BGD



Engine codes BDC, BGD

1. Chain sprocket

2. Bearing shells 1,2, 3, 4 and 5

z

Classification for ordering spare parts. See Fig. 57

z

For bearing cap without oil groove

z

For cylinder block with oil groove

z

Do not interchange used bearing shells (mark)

3. 65 N.m + 90° (1/4 turn) further

z

Replace

z

Threaded along complete length (screw)

z

Tighten to 65 N.m when measuring crankshaft radial clearance

4. Bearing cap

z

Bearing cap 1: Ribbed belt pulley end

z

Bearing cap 3 with recesses for thrust washers

z

Bearing shell retaining lugs (cylinder block/bearing cap) must be on same side

5. Bearing shell 3

z

See Step 2

z

Do not interchange used bearing shells (mark)

6. Sensor wheel

z

Replace

z

For Engine speed (RPM) sensor -G28-

z

Can only be installed in one position. Holes are offset

7. 10 N.m + 1/4 turn (90°) further

z

Replace

8. Thrust washer

z

For bearing 3 bearing cap

z

Observe adjustment

z

Lettering faces mounting bracket

9. Crankshaft

z

Axial clearance, new: 0.07...0.23 mm; Wear limit: 0.30 mm

z

Check radial clearance with Plastigage, new: 0.01...0.04 mm, Wear limit: 0.07 mm

z

Do not rotate crankshaft when checking radial clearance

NOTE:

The balancer shaft gear assembly must be adjusted. See OIL PUMP WITH
BALANCER SHAFT GEAR ASSEMBLY, REMOVING AND INSTALLING .

NOTE:
