See PLENUM CHAMBER INNER COVER, REMOVING AND INSTALLING

z

Disconnect fuel supply and return lines at fuel filter.

z

Remove fuel filter with bracket

z

Disconnect all coolant, vacuum and breather hoses from engine.

z

Disconnect all wiring connections from transmission, Generator and starter and move to one side.

z

Loosely unscrew coolant reservoir and place to side.

z

Remove toothed belt guard upper section.

z

Remove valve cover.

z

Remove brake booster vacuum pump.

z

Unscrew turbocharger oil return line to cylinder block.

z

Unscrew oil supply line at turbocharger

z

Remove injection lines.

z

Remove return line from injector jets/injection pump.

z

Remove glowplug harness connector.

z

Install engine support bracket 10-222A with 10-222 A/1 legs.

Fig. 73: Installing Engine Support Bracket
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Loosely unscrew subassembly (engine side) from upper engine bracket (arrows).

z

Remove engine mount and engine bracket.

z

Lift engine again slightly using spindle -B-.

NOTE:

Always remove injection lines as a set. Use 3035 offset tubing wrench to
loosen/tighten the injection lines.

NOTE:

Both lifting eyes are located on the cylinder head, therefore an additional



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Attach T 10014 bracket to cylinder block using threaded hole in water pump area (as illustrated).

Fig. 74: Attaching T 10014 Bracket To Cylinder Block
Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Lift engine slightly using second spindle -A- until spindle -B- is relieved.

z

Remove spindle -B-.

z

Position engine at TDC with camshaft sprocket loosened and toothed belt removed from camshaft
sprocket. See TOOTHED BELTS, REMOVING, INSTALLING, TENSIONING

z

Remove tension roller and camshaft sprocket.

bracket must be attached to the block to support the engine.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



z

Unscrew upper bolt of belt guard, rear.

z

Loosen socket head bolts in sequence given, then remove bolts completely.

Fig. 75: Loosening Head Bolts In Sequence



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Courtesy of VOLKSWAGEN OF AMERICA, INC.

z

Carefully lift off cylinder head.

Installing

z

Turn crankshaft to TDC mark before installing cylinder head.

z

Turn crankshaft against engine direction of rotation until all pistons are approximately equally spaced
below TDC.

z

To centralize: screw guide pins from 3070/9 into outer threaded holes on intake side.

NOTE:

z

Always replace cylinder head bolts.

z

Make sure that there isn't any oil or coolant in the cylinder head bolt
hollows (in the cylinder head).

z

Only remove the new cylinder head gasket from its packing immediately
before installing.

z

When repairing, carefully remove any gasket remains from the cylinder
head and cylinder block. Ensure that no long grooves or scratches are
created. When using abrasive paper do not use a grade coarser than 100
(e.g. 80).

z

Carefully remove any emery or abrasive remains.

z

Handle the new gasket with extreme care. Damaging will lead to leaks.
