11. Lifting eye

12. Cylinder head bolt

z

Replace

z

Note sequence when loosening and tightening. See CYLINDER HEAD, REMOVING AND
INSTALLING

13. Oil deflector

14. Valve cover

z

With vulcanized seal

z

Replace complete if damaged or leaking

15. Seal

z

Replace if damaged

16. Cap

z

Replace seal if damaged

17. Breather pipe

18. Retaining clip

19. Pressure regulating valve

z

For Positive Crankcase Ventilation valve

20. Gasket

z

Replace if damaged

21. 5 N.m (44 in. lb)

22. Fuel injector lines

z

25 N.m (18 ft lb)

z

Remove using 3035 offset tubing wrench

z

Always remove fuel line cluster as an assembly

z

Do not bend, kink or alter shape

23. Exhauster

z

For brake booster

24. Gasket

z

Always replace

25. Fuel injector

z

Removing and installing:

See FUEL INJECTORS, REMOVING AND INSTALLING

CAUTION: The valve cover seal is an integral part of the valve cover. Replace

the valve cover only if it is damaged or leaking.



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



26. Glow plug

z

15 N.m (11 ft lb)

z

Checking:

See GLOW PLUGS -Q6-, CHECKING

27. Cylinder head gasket

z

Replace

z

Note marking. See Cylinder head gasket, identification

z

If replaced; also replace entire engine coolant



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 67: Exploded View Of Cylinder Head Components
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Cylinder head distortion, checking



2003 Volkswagen New Beetle GLS

1998-2004 ENGINE Engine Mechanical - 1.9L 4-Cyl. - ALH, New Beetle



Fig. 68: Checking Cylinder Head Distortion
Courtesy of VOLKSWAGEN OF AMERICA, INC.

Max. permissible distortion: 0.1 mm
