3-4. Adjusting the steering wheel and mirrors

■

Recommended mirror angle when towing a trailer (vehicles with extend-
ing mirrors)

■

Mirror operating conditions (power-adjustable type)
The engine switch is in the “ACC” or “ON” position.

■

When the mirrors are fogged up (vehicles with outside rear view mirror
defoggers)
Turn on the mirror defoggers to defog the mirrors. (

P. 414, 421)

■

Automatic adjustment of the mirror angle (vehicles with driving position
memory)
A desired mirror face angle can be entered to memory and recalled automati-
cally by the driving position memory. (

P. 128)

■

Auto anti-glare function (if equipped)
When the anti-glare inside rear view mirror is set to automatic mode, the out-
side rear view mirrors will activate in conjunction with the anti-glare inside
rear view mirror to reduce reflected light. (

P. 140)

Power adjust the upper part of the mir-
ror until an appropriate view is obtained.
It is recommended that the outer 2/3 of
the  upper  mirror  be  filled  with  images
other than the vehicle and trailer.
Manually  adjust  the  lower  part  of  the
mirror  until  an  appropriate  view  of  the
towed  object  is  obtained.  It  is  recom-
mended that the outer 2/3 of the lower
mirror  be  filled  with  images  other  than
the trailer.

146

WARNING

■

Important points while driving
Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.

■

When a mirror is moving (power-adjustable type)
To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.

■

When the mirror defoggers are operating (vehicles with outside rear
view mirror defoggers)
Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.

147

Opera

Power windows

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:



Type A

Closing
Opening
One-touch opening

(driver’s

window only)

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.



Type B

Closing
One-touch closing

(front seat

windows)
Opening
One-touch opening

(front seat

windows)

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.

Press the switch down to lock the
passenger window switches.

Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.

Opening and closing procedures

Window lock switch

148

■

The power windows can be operated when
The engine switch is in the “ON” position.

■

Operating the power windows after turning the engine off
The power windows can be operated for approximately 43 seconds after the
engine switch is turned to the “ACC” or “LOCK” position. They cannot, how-
ever, be operated once either front door is opened.

■

Jam protection function (type B only)
If an object becomes caught between the window and the window frame, win-
dow travel is stopped and the window is opened slightly.

■

When the power window does not close normally (type B only)
If the jam protection function is operating abnormally and a window cannot be
closed, perform the following operations using the power window switch on
the relevant door.

●

After stopping the vehicle, the window can be closed by holding the power
window switch in the one-touch closing position while the engine switch is
turned to the “ON” position.

●

If the window still cannot be closed even by carrying out the operation as
explained above, initialize the function by performing the following proce-
dure.

Hold the power window switch in the one-touch closing position. Continue
holding the switch for a further 6 seconds after the window has closed.
Hold  the  power  window switch  in  the one-touch  opening position. Con-
tinue  holding  the  switch  for  a  further  2  seconds  after  the  window  has
opened completely.
Hold  the  power  window  switch  in  the  one-touch  closing  position  once
again. Continue holding the switch for a further 2 seconds after the win-
dow has closed.

If you release the switch while the window is moving, start again from the
beginning.
If the window continues to close but then re-open slightly even after perform-
ing the above procedure correctly, have the vehicle inspected by your Toyota
dealer.

149

Opera

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

Closing the windows

●

The driver is responsible for all the power window operations, including the
operation for the passengers. In order to prevent accidental operation,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts caught in
the power window. Also, when riding with a child, it is recommended to use
the window lock switch. (

P. 147)

●

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.

■

Jam protection function (type B only)

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The jam protection function may not work if something gets caught just
before the window fully closes.

150

Back window



Open/close

Push the lock release lever and
slide the back window.

■

Closing the back window
Make sure that the back window is securely closed after closing it.



: If equipped

Opening and closing

WARNING

■

Caution while driving
Keep the back window closed.
This not only keeps personal belongings from being thrown out, but also
prevents exhaust gases from entering the vehicle.

151

Opera

Power back window





Double Cab models

Opening
Closing



: If equipped

Opening and closing

152



CrewMax models

Opening
Closing

■

The power back window can be operated when
The engine switch is in the “ON” position.

■

Operating the power back windows after turning the engine off
The power back windows can be operated for approximately 43 seconds after
the engine switch is turned to the “ACC” or “LOCK” position. They cannot,
however, be operated once either front door is opened.

153

Opera

WARNING

■

Closing the back window
Observe the following precautions.
Failure to do so may result in death or serious injury.

●

The driver is responsible for all the power back window operations, includ-
ing the operation for the passengers. In order to prevent accidental opera-
tion, especially by a child, do not let a child operate the power back
window. It is possible for children and other passengers to have body parts
caught in the power back window.

●

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

●

■

Caution while driving
Keep the back window closed.
This not only keeps personal belongings from being thrown out, but also
prevents exhaust gases from entering the vehicle.

154

Moon roof



Opens the moon roof

Closes the moon roof

: Lightly press either way of the

moon roof switch to stop the moon
roof partway.

Tilts the moon roof up

Tilts the moon roof down

: Lightly press either way of the

moon roof switch to stop the moon
roof partway.

■

The moon roof can be operated when
The engine switch in the “ON” position.

■

Operating the moon roof after turning the engine off
The moon roof can be operated for approximately 43 seconds after the
engine switch is turned to the “ACC” or “LOCK” position. It cannot, however,
be operated once either front door is opened.

■

Jam protection function
If an object is detected between the moon roof and the frame while the moon
roof is closing or tilting down, travel is stopped and the moon roof opens
slightly.



: If equipped

Use the overhead switches to open and close the moon roof and
tilt it up and down.

Opening and closing

Tilting up and down

155

Opera

■

Sunshade
The sunshade can be opened and closed manually. However, the sunshade
will open automatically when the moon roof is opened.

■

Door lock linked moon roof operation
The moon roof can be opened and closed using the key. (

P. 114)

■

When the moon roof does not close normally
Perform the following procedure:

●

If the moon roof closes but then re-opens slightly

Stop the vehicle.
Press and hold the “ ▼ ” (sliding close) switch.

The moon roof will close, reopen and pause for approximately 10 sec-
onds.

Then it will close again, tilt up and pause for approximately 1 sec-

ond. Finally, it will tilt down, open and close.
Check to make sure that the moon roof is completely closed and then
release the switch.

●

If the moon roof tilts down but then tilts back up

Stop the vehicle.
Press and hold the “UP” (tilt up) switch

until the moon roof moves into

the tilt up position and stops.
Release the “UP” (tilt up) switch once and then press and hold the “UP”
(tilt up) switch again.

The moon roof will pause for approximately 10 seconds in the tilt up posi-
tion.

Then it will adjust slightly and pause for approximately 1 second.

Finally, it will tilt down, open and close.
Check to make sure that the moon roof is completely closed and then
release the switch.

: If the switch is released at the incorrect time, the procedure will have to

be performed again from the beginning.

: If the switch is released after the above mentioned 10 seconds pause,

automatic operation will be disabled. In that case, press and hold the “ ▼ ”
(sliding close) or “UP” (tilt up) switch, and the moon roof will tilt up and
pause for approximately 1 second. Then it will tilt down, open and close.
Check to make sure that the moon roof is completely closed and then
release the switch.

If the moon roof does not fully close even after performing the above proce-
dure correctly, have the vehicle inspected by your Toyota dealer.

156

■

Moon roof open reminder function
The buzzer sounds and a message is shown on the multi-information display
in the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the moon roof open.

■

When the battery is disconnected
The moon roof must be initialized in order to ensure proper operation.

Push and hold the switch toward the “UP” (tilt up) side or “ ▼ ” (sliding
close) side.
After the moon roof will tilt up and down, release the switch.
To ensure the initialization is complete, make sure automatic opening and
closing functions work properly.

■

Customization that can be configured at Toyota dealer
Settings (e.g. linked door lock operation) can be changed.
(Customizable features:

P. 623)

157

Opera

WARNING

Observe the following precautions.
Failure to do so may cause death or serious injury.

■

Opening the moon roof

●

Do not allow any passengers to put their hands or heads outside the vehi-
cle while it is moving.

●

Do not sit on top of the moon roof.

■

Closing the moon roof

●

The driver is responsible for moon roof opening and closing operations. In
order to prevent accidental operation, especially by a child, do not let a
child operate the moon roof. It is possible for children and other passen-
gers to have body parts caught in the moon roof.

●

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when the moon roof is being oper-
ated.

●

When using the key and operating the moon roof, operate the moon roof
after checking to make sure that there is no possibility of any passenger
having any of their body parts caught in the moon roof. Also, do not let a
child operate moon roof by the key. It is possible for children and other
passengers to get caught in the moon roof.

●

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The jam protection function may not work if something gets caught just
before the moon roof fully closes.

158
