Toyota Sienna (2019 year). Manual - part 12

SIENNA_OM_OM08025U_(U)

Inside rear view mirror

The height of the rear view mirror can be adjusted to suit your driving
posture.
Adjust the height of the rear view
mirror by moving it up and down.



Manual anti-glare inside rear view mirror

Reflected light from the headlights of vehicles behind can be reduced
by operating the lever.

Normal position
Anti-glare position

The rear view mirror’s position can be adjusted to enable suffi-
cient confirmation of the rear view.

Adjusting the height of rear view mirror

Anti-glare function

180

SIENNA_OM_OM08025U_(U)



Auto anti-glare inside rear view mirror

Responding to the level of brightness of the headlights of vehicles
behind, the reflected light is automatically reduced.
Changing automatic anti-glare
function mode
On/off

When  the  automatic  anti-glare
function is in on mode, the indica-
tor illuminates.
The  function  will  set  to  on  mode
each  time  the  engine  switch  is
turned  to  “ON”  position  (vehicles
without  a  smart  key  system)  or
IGNITION ON mode (vehicles with
a smart key system).
Pressing the button turns the function to off mode. (The indicator also turns
off.)

To prevent sensor error (vehicles with auto anti-glare inside rear view
mirror)

Indicator

To ensure that the sensors operate prop-
erly, do not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident,
resulting in death or serious injury.

181

SIENNA_OM_OM08025U_(U)

Outside rear view mirrors

To select a mirror to adjust, turn
the switch.

Left
Right

To adjust the mirror, move the
switch.

Up
Right
Down
Left



Manual type

Push the mirror back in the direc-
tion of the vehicle’s rear.

Adjustment procedure

Folding and extending the mirrors

182

SIENNA_OM_OM08025U_(U)



Power type

Press the switch.

Folding
Extending

When the mirror select switch is in the L or R position, the outside rear
view mirrors will automatically angle downwards when the vehicle is
reversing in order to give a better view of the ground.
To disable this function, move the mirror select switch to the neutral
position (between L and R).

Linked mirror function when reversing (if equipped)

183

SIENNA_OM_OM08025U_(U)

Mirror angle can be adjusted when



Vehicles without a smart key system

The engine switch is in the “ACC” or “ON” position.



Vehicles with a smart key system

The engine switch is in ACCESSORY or IGNITION ON mode.

When the mirrors are fogged up (vehicles with outside rear view mirror
defoggers)
The outside rear view mirrors can be cleared using the mirror defoggers. Turn
on the rear window defogger to turn on the outside rear view mirror defog-
gers. (

P. 336)

Automatic adjustment of the mirror angle (vehicles with driving position
memory)
A desired mirror face angle can be entered to memory and recalled automati-
cally by the driving position memory. (

P. 169)

Auto anti-glare function (vehicles with auto anti-glare inside rear view
mirror)
When the anti-glare inside rear view mirror is set to automatic mode, the out-
side rear view mirrors will activate in conjunction with the anti-glare inside
rear view mirror to reduce reflected light. (

P. 179)

WARNING

When driving the vehicle
Observe the following precautions while driving.
Failing to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.

Do not adjust the mirrors while driving.

Do not drive with the mirrors folded.

Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.

When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.

When the mirror defoggers are operating (vehicles with outside rear
view mirror defoggers)
Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.

184

SIENNA_OM_OM08025U_(U)

Power windows

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:

Closing
One-touch closing

Opening
One-touch opening

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.

Press the switch down to lock the
passenger window switches.

Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.

Opening and closing procedures

Window lock switch

SIENNA_OM_OM08025U_(U)

185

The power windows can be operated when
The engine switch is in the “ON” position (vehicles without a smart key sys-
tem) or IGNITION ON mode (vehicles with a smart key system).

Operating the power windows after turning the engine off



Vehicles without a smart key system

The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to the “ACC” or “LOCK” position. They can-
not, however, be operated once either front door is opened.



Vehicles with a smart key system

The power windows can be operated for approximately 45 seconds even
after the engine switch is turned to ACCESSORY mode or turned off. They
cannot, however, be operated once either front door is opened.

Jam protection function
If an object becomes caught between the window and the window frame, win-
dow travel is stopped and the window is opened slightly.

When the power window does not close normally
If the jam protection function is operating abnormally and a window cannot be
closed, perform the following operations using the power window switch on
the relevant door.

After stopping the vehicle, the window can be closed by holding the power
window switch in the one-touch closing position while the engine switch is
turned to the “ON” position (vehicles without a smart key system) or IGNI-
TION ON mode (vehicles with a smart key system).

If the window still cannot be closed even by carrying out the operation
explained above, initialize the function by performing the following proce-
dure.

Hold the power window switch in the one-touch closing position. Continue
holding the switch for 4 seconds or more after the window has closed.
Hold  the  power  window switch  in  the one-touch  opening position. Con-
tinue  holding  the  switch  for  1  second  or  more  after  the  window  has
opened completely.
Hold  the  power  window  switch  in  the  one-touch  closing  position  once
again. Continue holding the switch for 1 second or more after the window
has closed.

If you release the switch while the window is moving, start again from the
beginning. If the window continues to close but then re-open slightly even
after performing the above procedure correctly, have the vehicle inspected by
your Toyota dealer.

186

SIENNA_OM_OM08025U_(U)

WARNING

Observe the following precautions.
Failing to do so may result in death or serious injury.

Closing the windows

The driver is responsible for all the power window operations, including the
operation for the passengers. In order to prevent accidental operation,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts caught in
the power window. Also, when riding with a child, it is recommended to use
the window lock switch. (

P. 184)

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

When exiting the vehicle, turn the engine switch to the “LOCK” position
(vehicles without a smart key system) or off (vehicles with a smart key sys-
tem), carry the key and exit the vehicle along with the child. There may be
accidental operation, due to mischief, etc., that may possibly lead to an
accident.

Jam protection function

Never use any part of your body to intentionally activate the jam protection
function.

The jam protection function may not work if something gets caught just
before the window fully closes.

The jam protection function is disabled if the switch is pulled and held
during one-touch closing operation.

187

SIENNA_OM_OM08025U_(U)

Quarter windows



Manual type

Pull the handle and swing the win-
dow fully out to open.



Power type

Opening
Closing

Both the left and right quarter win-
dows move.

The quarter windows can be opened to bring in fresh outside air
for additional ventilation.

Opening and closing procedures

188

SIENNA_OM_OM08025U_(U)

The windows can be operated when (power type)
The engine switch is in the “ON” position (vehicles without a smart key sys-
tem) or IGNITION ON mode (vehicles with a smart key system).

Operating the windows after turning the engine off (power type)



Vehicles without a smart key system

The power type windows can be operated for approximately 45 seconds even
after the engine switch is turned to the “ACC” or “LOCK” position. They can-
not, however, be operated once either front door is opened.



Vehicles with a smart key system

The power type windows can be operated for approximately 45 seconds even
after the engine switch is turned to ACCESSORY mode or turned off. They
cannot, however, be operated once either front door is opened.

WARNING

Closing the windows
Observe the following precautions.
Failing to do so may result in death or serious injury.

Check to make sure that all passengers do not have any part of their body
in a position where it could be caught when a window is being operated.

Power type: Do not allow children to operate the quarter windows.

189

SIENNA_OM_OM08025U_(U)

Moon roof



Front moon roof

Opens the moon roof

The moon roof will stop at the tilt up position once.
To tilt down, press the opposite side of the switch.
Press the switch again to open.

Closes the moon roof

: Lightly press either of the roof switches to stop the moon roof partway.

Rear moon roof (if equipped)

Opens the moon roof

The moon roof stops just before
it is opened fully. Press the
switch again to open fully.

Closes the moon roof

: Lightly press either of the roof

switches to stop the moon roof
partway.



: If equipped

Use the overhead switches to open and close the moon roof.

Opening and closing



Vehicles without a rear moon
roof



Vehicles with a rear moon roof

190

SIENNA_OM_OM08025U_(U)

Press the switch to disable the
rear moon roof operation from the
rear seat.

Pressing the switch again will
enable the operation again.

The moon roof can be operated when
The engine switch is in the “ON” position (vehicles without a smart key sys-
tem) or IGNITION ON mode (vehicles with a smart key system).

Operating the moon roof after turning the engine off



Vehicles without a smart key system

The moon roof can be operated for approximately 45 seconds after the
engine switch is turned to the “ACC” or “LOCK” position. It cannot, however,
be operated once either front door is opened.



Vehicles with a smart key system

The moon roof can be operated for approximately 45 seconds after the
engine switch is turned to ACCESSORY mode or turned off. It cannot, how-
ever, be operated once either front door is opened.

Jam protection function
If an object is detected between the moon roof and the frame while the moon
roof is closing, travel is stopped and the moon roof opens slightly.

Sunshade
The sunshade can be opened and closed manually. However, both front and
rear sunshades open automatically when the moon roof is opened.

When the moon roof does not close normally

Stop the vehicle.
Press and hold the close switch.

The moon roof will start moving after pausing for about 10 seconds. Con-
tinue to hold the switch.
Release the button when the moon roof stops moving.
Within 4 seconds, press and hold the close switch again. Continue to hold
the switch as the moon roof opens and closes.
Release the close switch when the moon roof completely stops.

: If the switch is released at the incorrect time, the procedure will have to be

performed again from the beginning.

Canceling the rear moon roof operation (vehicles with the rear
moon roof)

SIENNA_OM_OM08025U_(U)

191

WARNING

Observe the following precautions.
Failing to do so may cause death or serious injury.

Opening the moon roof

Do not allow any passengers to put their hands or heads outside the vehi-
cle while it is moving.

Do not sit on top of the moon roof.

Closing the moon roof

The driver is responsible for moon roof opening and closing operations.
In order to prevent accidental operation, especially by a child, do not let a
child operate the moon roof. It is possible for children and other passen-
gers to have body parts caught in the moon roof. Also, when riding with a
child, it is recommended to use

for vehicles with a rear moon roof.

(

P. 190)

Check to make sure that all passengers do not have any part of their bod-
ies in a position where it could be caught when the moon roof is being
operated.

Jam protection function

Never use any part of your body intentionally to activate the jam protection
function.

The jam protection function may not work if something gets caught just
before the moon roof fully closes.

192

SIENNA_OM_OM08025U_(U)
