1-2. Opening, closing and locking the doors and trunk

■ When the vehicle is not driven for extended periods

● To prevent theft of the vehicle, do not leave the electronic key within 6 ft.

(2 m) of the vehicle.

● The smart key system can be deactivated in advance. (P. 487)

■ Alarm

Using the smart key system to lock the doors will set the alarm system.

(P. 82)

■ To operate the system properly

● Make sure to carry the electronic key when operating the system. Do not

get the electronic key too close to the vehicle when operating the system

from the outside of the vehicle.

Depending on the position and holding condition of the electronic key, the

key may not be detected correctly and the system may not operate prop-

erly. (The alarm may go off accidentally, or the door lock prevention func-

tion may not operate.)

● Do not leave the electronic key inside the trunk.

The key confinement prevention function may not operate, depending on

the location of the key (close to a spare tire, the inside edge of the trunk),

conditions (inside a metal bag, close to metallic objects) and the radio

waves in the surrounding area. (P. 48)

■ If the smart key system does not operate properly

● Locking and unlocking the doors, unlocking the trunk: Use the mechani-

cal key. (P. 440)

● Starting the engine:P. 441

1-2. Opening, closing and locking the doors and trunk

■ Electronic key battery depletion

● The standard battery life is 1 to 2 years.

● If the battery charge becomes low, a buzzer will sound in the cabin and a

message will be displayed on the multi-information display when the

engine is stopped. (P. 413)

● As the electronic key always receives radio waves, the battery will

become depleted even if the electronic key is not used. The following

symptoms indicate that the electronic key battery may be depleted.

Replace the battery when necessary. (P. 363)

• The smart key system or the wireless remote control does not operate.

• The detection area becomes smaller.

• The LED indicator on the key surface does not turn on.

● To avoid serious deterioration, do not leave the electronic key close to

any of the following electrical appliances that produce a magnetic field:

• TVs

• Personal computers

• Cellular phones, cordless phones and battery chargers

• Recharging cellular phones or cordless phones

• Induction cookers

• Table lamps

■ When the electronic key battery is fully depleted

P. 363

■ If the smart key system has been deactivated in a customized setting

● Locking and unlocking the doors, unlocking the trunk: Use the wireless

remote control or mechanical key. (P. 38, 440)

● Starting the engine and changing

“ENGINE START STOP” switch

modes: P. 441

● Stopping the engine: P. 443

■ Customization that can be configured at Toyota dealer

Settings (e.g. smart key system) can be changed.

(Customizable features: P. 487)

1-2. Opening, closing and locking the doors and trunk

■ Certification for smart key system

For vehicles sold in the U.S.A.

FCC ID: HYQ23AAE

FCC ID: HYQ14AHP

FCC ID: Y8PSSPLF03

NOTE:

This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful interfer-

ence, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

FCC WARNING:

Changes or modifications not expressly approved by the party responsible

for compliance could void the user's authority to operate the equipment.

For vehicles sold in Canada

NOTE:

This device complies with Industry Canada’s licence-exempt RSSs. Opera-

tion is subject to the following two conditions: (1) This device may not cause

interference; and (2) This device must accept any interference, including

interference that may cause undesired operation of the device.

NOTE:

Le présent appareil est conforme aux CNR d’Industrie Canada applicables

aux appareils radio exempts de licence. L’exploitation est autorisée aux

deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage;

(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

1-2. Opening, closing and locking the doors and trunk

WARNING

■ Caution regarding interference with electronic devices

● People with implantable cardiac pacemakers, cardiac resynchronization

therapy-pacemakers or implantable cardioverter defibrillators should main-

tain a reasonable distance between themselves and the smart key system

antennas. (P. 27)

The radio waves may affect the operation of such devices. If necessary,

the entry function can be disabled. Ask your Toyota dealer for details, such

as the frequency of radio waves and timing of the emitted radio waves.

Then, consult your doctor to see if you should disable the entry function.

● User of any electrical medical device other than implantable cardiac pace-

makers, cardiac resynchronization therapy-pacemakers or implantable

cardioverter defibrillators should consult the manufacturer of the device for

information about its operation under the influence of radio waves.

Radio waves could have unexpected effects on the operation of such

medical devices.

Ask your Toyota dealer for details for disabling the entry function.

1-2. Opening, closing and locking the doors and trunk

Wireless remote control

The wireless remote control can be used to lock and unlock the vehi-

cle.

Vehicles without

a smart key system

Locks both side doors

Check that the door is securely

locked.

Unlocks both side doors

Sounds the alarm

(press and hold)

Pressing the button unlocks

the driver’s door. Pressing the

button again within 3 seconds

unlocks the other doors.

Unlocks the trunk

(press and hold)

Vehicles with a smart key system

Locks both side doors

Check that the door is securely

locked.

Unlocks both side doors

Pressing the button unlocks

the driver’s door. Pressing the

button again within 3 seconds

unlocks the other doors.

Unlocks the trunk

(press and hold)

Sounds the alarm

(press and hold)

1-2. Opening, closing and locking the doors and trunk

■ Operation signals

Doors: A buzzer sounds and the emergency flashers flash to indicate that

the doors have been locked/unlocked. (Locked: once; Unlocked:

twice)

Trunk:

A buzzer sounds to indicate that the trunk has been unlocked.

■ Door lock buzzer (vehicles with a smart key system)

If an attempt to lock the doors is made when a door is not fully closed, a

buzzer sounds continuously. Fully close the door to stop the buzzer, and lock

the vehicle once more.

■ Panic mode

Vehicles without a smart key system

When

is pressed for longer than

about one second, an alarm will sound

intermittently and the vehicle lights will

flash to deter any person from trying to

break into or damage your vehicle.

To stop the alarm, press any button on

the wireless remote control.

Vehicles with a smart key system

When

is pressed for longer than

about one second, an alarm will sound

intermittently and the vehicle lights will

flash to deter any person from trying to

break into or damage your vehicle.

To stop the alarm, press any button on

the electronic key.

1-2. Opening, closing and locking the doors and trunk

■ Vehicle finder function

Vehicles without a smart key system

When the function is set, a buzzer

(sounds once) and the emergency flash-

ers (flash 3 times) are used to inform the

driver of the vehicle’s location.

Press

3 times within 5 seconds

while within a circumference of approxi-

mately 30 ft. (10 m) from of the vehicle.

However, if the interval between the 3

presses is short, the system may not be

activated. This setting must be custom-

ized at your Toyota dealer.

Vehicles with a smart key system

When the function is set, a buzzer

(sounds once) and the emergency flash-

ers (flash 3 times) are used to inform the

driver of the vehicle’s location.

Press

3 times within 5 seconds

while within a circumference of approxi-

mately 30 ft. (10 m) from of the vehicle.

However, if the interval between the 3

presses is short, the system may not be

activated. This setting must be custom-

ized at your Toyota dealer.

1-2. Opening, closing and locking the doors and trunk

■ Security feature

If a door is not opened within approximately 60 seconds after the vehicle is

unlocked, the security feature automatically locks the vehicle again.

■ Alarm (vehicles with a smart key system)

Using the wireless remote control to lock the doors will set the alarm system.

(P. 82)

■ Conditions affecting operation

Vehicles without a smart key system

The wireless remote control function may not operate normally in the follow-

ing situations:

● When the wireless key battery is depleted

● Near a TV tower, electric power plant, gas station, radio station, large dis-

play, airport or other facility that generates strong radio waves or electri-

cal noise

● When carrying a portable radio, cellular phone or other wireless commu-

nication devices

● When the wireless key is in contact with, or is covered by a metallic

object

● When other wireless key (that emit radio waves) is being used nearby

● If window tint with a metallic content or metallic objects are attached to

the rear window

Vehicles with a smart key system

P. 31

■ If the wireless remote control does not operate properly (vehicles with

a smart key system)

Locking and unlocking the doors, unlocking the trunk: Use the mechanical

key. (P. 440)

■ Key battery depletion

Vehicles without a smart key system

If the wireless remote control function does not operate, the battery may be

depleted. Replace the battery when necessary. (P. 363)

Vehicles with a smart key system

P. 35

1-2. Opening, closing and locking the doors and trunk

■ When the electronic key battery is fully depleted

P. 363

■ Confirmation of the registered key number (vehicles with a smart key

system)

The number of keys already registered to the vehicle can be confirmed. Ask

your Toyota dealer for details.

■ Customization that can be configured at your Toyota dealer

Settings (e.g. wireless remote control system) can be changed.

(Customizable features P. 487)

■ Certification for wireless remote control

For vehicles sold in the U.S.A.

FCC ID: HYQ23AAC

FCC ID: HYQ12BEL

NOTE:

This device complies with part 15 of the FCC Rules. Operation is subject to

the following two conditions: (1) This device may not cause harmful interfer-

ence, and (2) this device must accept any interference received, including

interference that may cause undesired operation.

FCC WARNING:

Changes or modifications not expressly approved by the party responsible

for compliance could void the user's authority to operate the equipment.

For vehicles sold in Canada

NOTE:

This device complies with Industry Canada’s licence-exempt RSSs. Opera-

tion is subject to the following two conditions: (1) This device may not cause

interference; and (2) This device must accept any interference, including

interference that may cause undesired operation of the device.

NOTE:

Le présent appareil est conforme aux CNR d’Industrie Canada applicables

aux appareils radio exempts de licence. L’exploitation est autorisée aux

deux conditions suivantes: (1) l’appareil ne doit pas produire de brouillage;

(2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,

même si le brouillage est susceptible d’en compromettre le fonctionnement.

1-2. Opening, closing and locking the doors and trunk

Doors

The vehicle can be locked and unlocked using the entry function,

wireless remote control, key or door lock switch.

■ Entry function (vehicles with a smart key system)

P. 26

■ Wireless remote control

P. 38

■ Key

Turning the key operates the doors as follows:

Vehicles without a smart key system

Locks driver’s side door

Unlocks driver’s side door

Vehicles with a smart key system

The doors can also be locked and unlocked with the mechanical

key. (P. 440)

■ Door lock switch

Locks both side doors

Unlocks both side doors

1-2. Opening, closing and locking the doors and trunk

■ Inside lock button

Locks the door

Unlocks the door

Locking the doors from the outside without a key

STEP

Move the inside lock button to the lock position.

STEP

Close the door.

Vehicles with a smart key system

The door cannot be locked if the electronic key is left inside the vehi-

cle.

The key may not be detected correctly and the door may be locked.

1-2. Opening, closing and locking the doors and trunk

■ Window open/close function linked to door operation

In order to make opening and closing the doors easier, completely closed

windows are linked to door operations. Therefore, when a door is opened, its

window opens slightly. When a door is closed, its window closes completely.

However, if the battery has discharged or is disconnected, this function will

not operate. (P. 448)

■ If the smart key system has been deactivated in a customized setting

(vehicles with a smart key system)

Use the wireless remote control or mechanical key. (P. 38, 440)

WARNING

■ To prevent an accident

Observe the following precautions while driving the vehicle.

Failure to do so may result in a door opening and an occupant falling out,

resulting in death or serious injury.

● Always use a seat belt.

● Always lock both side doors.

● Ensure that both side doors are properly closed.

● Do not pull the inside handle of the doors while driving.

The doors may be opened and the passengers are thrown out of the vehi-

cle and it may result in serious injury or death.

1-2. Opening, closing and locking the doors and trunk

Trunk

The trunk can be opened using the key, trunk opener, entry function

or wireless remote control.

■ Opening the trunk from inside the vehicle

Press and hold the opener

switch to release the trunk lid.

■ Opening the trunk from outside the vehicle

Key (vehicles without a smart key system)

Turn the master key clockwise

to release the trunk lid.

Entry function (vehicles with a smart key system)

P. 27

Wireless remote control

P. 38

1-2. Opening, closing and locking the doors and trunk

Canceling the trunk opener feature

To protect luggage stored in the trunk against theft, do the following:

Turn the main switch in the trunk

off to disable the trunk opener.

Off

Vehicles without a smart key sys-

tem:

The trunk lid can only be opened

with the master key.

Vehicles with a smart key system:

The trunk lid can only be opened

with the mechanical key.

1-2. Opening, closing and locking the doors and trunk

■ Trunk light

The trunk light turns on when the trunk is opened.

■ Function to prevent the trunk being locked with the electronic key

inside (vehicles with a smart key system)

● When all doors are being locked, closing the trunk lid with the electronic

key left inside the trunk will sound an alarm.

In this case, the trunk lid can be opened using the entry function.

● Even when the spare electronic key is put in the trunk with all the doors

locked, the key confinement prevention function can be activated so the

trunk can be opened. In order to prevent theft, take all electronic keys

with you when leaving the vehicle.

● Even when the electronic key is put in the trunk with all the doors are

locked, the key may not be detected depending on the places and the

surrounding radio wave conditions. In this case, the key confinement pre-

vention function cannot be activated, causing the doors to lock when the

trunk is closed. Make sure to check where the key is before closing the

trunk.

● The key confinement prevention function cannot be activated if any one

of the doors is unlocked. In this case, open the trunk using the trunk

opener.

■ Internal trunk release lever

The trunk lid can be opened by pulling on

the glow-in-the-dark lever located on the

inside of the trunk lid.

The lever will continue to glow for some

time after the trunk lid is closed.

■ Using the mechanical key (vehicles with a smart key system)

The trunk can be also opened using the mechanical key. (P. 440)

■ Which key to the vehicle is to leave with a parking attendant after dis-

abling the trunk opener main switch

P. 23

1-2. Opening, closing and locking the doors and trunk

WARNING

■ Caution while driving

● Keep the trunk lid closed while driving.

If the trunk lid is left open, it may hit near-by objects while driving or lug-

gage in the trunk may be unexpectedly thrown out, causing an accident.

In addition, exhaust gases may enter the vehicle, causing death or a seri-

ous health hazard. Make sure to close the trunk lid before driving.

● Before driving the vehicle, make sure that the trunk lid is fully closed. If the

trunk lid is not fully closed, it may open unexpectedly while driving, caus-

ing an accident.

● Never let anyone sit in the trunk. In the event of sudden braking or a colli-

sion, they are susceptible to death or serious injury.

■ When children are in the vehicle

Observe the following precautions.

Failure to do so may result in death or serious injury.

● Do not allow children to play in the trunk.

If a child is accidentally locked in the trunk, they could suffer from heat

exhaustion, suffocation or other injuries.

● Do not allow a child to open or close the trunk lid.

Doing so may cause the trunk lid to operate unexpectedly, or cause the

child’s hands, head, or neck to be caught by the closing trunk lid.

1-2. Opening, closing and locking the doors and trunk

WARNING

■ Using the trunk

Observe the following precautions.

Failure to do so may cause parts of the body to be caught, resulting in seri-

ous injury.

● Remove any heavy loads, such as snow and ice, from the trunk lid before

opening it. Failure to do so may cause the trunk lid to suddenly shut again

after it is opened.

● When opening or closing the trunk lid, thoroughly check to make sure the

surrounding area is safe.

● If anyone is in the vicinity, make sure they are safe and let them know that

the trunk is about to open or close.

● Use caution when opening or closing the trunk lid in windy weather as it

may move abruptly in strong wind.

● The trunk lid may suddenly shut if it is

not opened fully. It is more difficult to

open or close the trunk lid on an

incline than on a level surface, so

beware of the trunk lid unexpectedly

opening or closing by itself. Make

sure that the trunk lid is fully open

and secure before using the trunk.

Toyota 86 (2018 year). Manual - part 3
