9-2. Customization
■ S-IPA (Simple Intelligent Parking Assist System)* (P. 456)
Default
Customized
Function
1
2
3
setting
setting
Near
Obstacle detection range
Standard
Slightly far
-
-
O
Far
Narrow
Back-in parking space
Standard
Slightly wide
-
-
O
Wide
Narrow
Parallel parking space
Standard
Slightly wide
-
-
O
Wide
*: If equipped
■ Automatic air conditioning system (P. 504)
Default
Customized
Function
1
2
3
setting
setting
A/C auto switching operation
On
Off
-
O
O
Switching between outside air
and recirculated air mode
On
Off
-
O
O
linked to A/C auto switch oper-
ation
PRIUS PHV_OM_OM47A89E_(EE)
9-2. Customization
715
■ Remote Air Conditioning System (P. 516)
Default
Customized
Function
1
2
3
setting
setting
Press once
Press twice
Operation using the “A/C” but-
Press and
ton on the wireless remote
hold for 0.8
Press and
-
-
O
hold for 2.4
control
seconds
seconds
Off
Press once
Press and
hold for 0.8
Stopping the operation using
seconds
the “A/C” button on the wire-
Press twice
-
-
O
less remote control
Press and
hold for 2.4
seconds
Off
■ Illumination (P. 522)
Default
Customized
Function
1
2
3
setting
setting
Off
Time elapsed before the inte-
15 seconds
7.5 seconds
-
O
O
rior lights turn off
30 seconds
Operation after the power
On
Off
-
-
O
switch is turned off
Operation when the doors are
On
Off
-
-
O
9
unlocked
Operation when you approach
the vehicle with the electronic
On
Off
-
-
O
key on your person
Footwell lighting
On
Off
-
-
O
Interior lights illumination con-
On
Off
-
-
O
trol
PRIUS PHV_OM_OM47A89E_(EE)
716
9-2. Customization
■ In the following situations, customize mode in which the settings can be
changed through the multi-information display will automatically be
turned off.
● The power switch is turned off.
●The vehicle begins to move while the customize mode screen is displayed.
WARNING
■ Cautions during customization
As the hybrid system needs to be operating during customization, ensure
that the vehicle is parked in a place with adequate ventilation. In a closed
area such as a garage, exhaust gases including harmful carbon monoxide
(CO) may collect and enter the vehicle. This may lead to death or a serious
health hazard.
NOTICE
■ During customization
To prevent 12-volt battery discharge, ensure that the hybrid system is oper-
ating while customizing features.
■ Charge settings
Charge schedule
Setting the charging timer: P. 166
Changing the upper limit of the charging cur-
Charge current
rent: P. 137
Setting “Traction Battery Heater” on/off:
Traction battery heater
P. 142
■ Maintenance system
Tire pressure warning
Initializing the tire pressure warning system:
system
P. 581
PRIUS PHV_OM_OM47A89E_(EE)
9-3. Initialization
717
Items to initialize
The following items must be initialized for normal system opera-
tion after such cases as the 12-volt battery being reconnected,
or maintenance being performed on the vehicle:
Item
When to initialize
Reference
Power window
• When functioning abnormally
P. 308
Intelligent Clearance Sonar
• After reconnecting or chang-
P. 453
(if equipped)
ing the 12-volt battery
S-IPA
(Simple Intelligent
• After reconnecting or chang-
Parking Assist System)
(if
P. 481
ing the 12-volt battery
equipped)
• When rotating the tires on
vehicles with differing front
and rear tire inflation pres-
Tire pressure warning sys-
sures
P. 581
tem
• When changing the tire infla-
tion pressure by changing
traveling speed or load
weight, etc.
9
PRIUS PHV_OM_OM47A89E_(EE)
718
9-3. Initialization
PRIUS PHV_OM_OM47A89E_(EE)
719
Index
What to do if...
(Troubleshooting)
720
Alphabetical index
724
For information regarding the equipment listed below, refer to
the “Navigation system Owner’s manual”.
• Navigation system
• Audio/video system
• Hands-free system (for cellular phone)
• Toyota parking assist monitor
PRIUS PHV_OM_OM47A89E_(EE)
720
What to do if... (Troubleshooting)
What to do if... (Troubleshooting)
If you have a problem, check the following before contacting any
authorized Toyota dealer or repairer, or another duly qualified
and equipped professional.
The doors cannot be locked, unlocked, opened or closed
You lose your keys
● If you lose your mechanical keys, new genuine mechanical keys can be
made by any authorized Toyota dealer or repairer, or another duly qualified
and equipped professional. (P. 265)
● If you lose your electronic keys, the risk of vehicle theft increases signifi-
cantly. Contact any authorized Toyota dealer or repairer, or another duly
qualified and equipped professional immediately. (P. 268)
The doors cannot be locked or unlocked
● Is the electronic key battery weak or depleted? (P. 616)
● Is the power switch in ON mode?
When locking the doors, turn the power switch off. (P. 329)
● Is the electronic key left inside the vehicle?
When locking the doors, make sure that you have the electronic key on
your person.
● The function may not operate properly due to the condition of the radio
wave. (P. 282)
The rear door cannot be opened
● Is the child-protector lock set?
The rear door cannot be opened from inside the vehicle when the lock is
set. Open the rear door from outside and then unlock the child-protector
lock. (P. 272)
PRIUS PHV_OM_OM47A89E_(EE)
What to do if... (Troubleshooting)
721
If you think something is wrong
The hybrid system does not start
● Did you press the power switch while firmly depressing the brake pedal?
(P. 327)
● Is the shift position in P? (P. 334)
● Is the electronic key anywhere detectable inside the vehicle? (P. 280)
● Is the electronic key battery weak or depleted?
In this case, the hybrid system can be started in a temporary way.
(P. 679)
● Is the 12-volt battery discharged? (P. 682)
The windows do not open or close by operating the power
window switches
● Is the window lock switch pressed?
The power windows except for the one at the driver’s seat cannot be oper-
ated if the window lock switch is pressed. (P. 307)
The power switch is turned off automatically
● The auto power off function will be operated if the vehicle is left in
ACCESSORY or ON mode (the hybrid system is not operating) for a
period of time. (P. 329)
PRIUS PHV_OM_OM47A89E_(EE)
722
What to do if... (Troubleshooting)
A warning buzzer sounds during driving
● The seat belt reminder light is flashing
Are the driver and all the passengers wearing the seat belts? (P. 647)
● The parking brake indicator is on
Is the parking brake released? (P. 340)
Depending on the situation, other types of warning buzzer may also sound.
(P. 641, 650)
An alarm is activated and the horn sounds
(vehicles with alarm)
● Did anyone inside the vehicle open a door during setting the alarm?
The sensor detects it and the alarm sounds. (P. 81)
To stop the alarm, turn the power switch to ON mode or start the hybrid sys-
tem.
A warning buzzer sounds when leaving the vehicle
● Is the electronic key left inside the vehicle?
Check the message on the multi-information display. (P. 650)
A warning light turns on or a warning message is displayed
● When a warning light turns on or a warning message is displayed, refer to
P. 641, 650.
PRIUS PHV_OM_OM47A89E_(EE)
What to do if... (Troubleshooting)
723
When a problem has occurred
If you have a flat tire
● Stop the vehicle in a safe place and repair the flat tire temporarily with the
emergency tire puncture repair kit. (P. 658)
The vehicle becomes stuck
● Try the procedure for when the vehicle becomes stuck in mud, dirt, or
snow. (P. 693)
PRIUS PHV_OM_OM47A89E_(EE)
724
Alphabetical index
