Toyota Prius Plug-in Hybrid (2017 year). Manual - part 18

4-2. Opening, closing and locking the doors

289

4

PRIUS PHV_OM_OM47A89E_(EE)

290

4-2. Opening, closing and locking the doors

PRIUS PHV_OM_OM47A89E_(EE)

4-2. Opening, closing and locking the doors

291

4

PRIUS PHV_OM_OM47A89E_(EE)

292

4-2. Opening, closing and locking the doors

PRIUS PHV_OM_OM47A89E_(EE)

4-2. Opening, closing and locking the doors

293

4

PRIUS PHV_OM_OM47A89E_(EE)

294

4-2. Opening, closing and locking the doors

PRIUS PHV_OM_OM47A89E_(EE)

4-2. Opening, closing and locking the doors

295

WARNING

■ Caution regarding interference with electronic devices

●People with implantable cardiac pacemakers, cardiac resynchronization

therapy-pacemakers or implantable cardioverter defibrillators should keep

away from the smart entry & start system antennas. (P. 279)

The radio waves may affect the operation of such devices. If necessary,

the entry function can be disabled. Ask any authorized Toyota dealer or

repairer, or another duly qualified and equipped professional for details,

such as the frequency of radio waves and timing of the emitted radio

waves. Then, consult your doctor to see if you should disable the entry

function.

●Users of any electrical medical device other than implantable cardiac

pacemakers, cardiac resynchronization therapy-pacemakers or implanta-

ble cardioverter defibrillators should consult the manufacturer of the

device for information about its operation under the influence of radio

waves.

Radio waves could have unexpected effects on the operation of such

4

medical devices.

Ask any authorized Toyota dealer or repairer, or another duly qualified and

equipped professional for details on disabling the entry function.

PRIUS PHV_OM_OM47A89E_(EE)

296

4-3. Adjusting the seats

Front seats

Adjustment procedure

1

Seat position adjustment lever

2

Seatback angle adjustment

lever

3

Vertical height adjustment lever

(for driver’s side)

Lumbar support adjustment

4

switch (for driver’s side)

■ When adjusting the seat

Take care when adjusting the seat so that the head restraint does not touch

the ceiling.

WARNING

■ When adjusting the seat position

● Take care when adjusting the seat position to ensure that other passen-

gers are not injured by the moving seat.

●Do not put your hands under the seat or near the moving parts to avoid

injury.

Fingers or hands may become jammed in the seat mechanism.

■ Seat adjustment

● To reduce the risk of sliding under the lap belt during a collision, do not

recline the seat more than necessary.

If the seat is too reclined, the lap belt may slide past the hips and apply

restraint forces directly to the abdomen, or your neck may contact the

shoulder belt, increasing the risk of death or serious injury in the event of

an accident.

Adjustments should not be made while driving as the seat may unexpect-

edly move and cause the driver to lose control of the vehicle.

●After adjusting the seat, make sure that the seat is locked in position.

PRIUS PHV_OM_OM47A89E_(EE)

4-3. Adjusting the seats

297

Rear seats

The seatbacks can be folded down.

Before folding down the seatbacks

Park the vehicle in a safe place.

1

Apply the parking brake firmly and shift the shift position to P. (P. 334)

2

Adjust the position of the front seat and the angle of the seatback.

(P. 296)

Depending on the position of the front seat, if the seatback is folded back-

ward, it may interfere with the operation of the rear seat.

3

Lower the head restraint of the rear seat. (P. 299)

4

Close the lid of rear seat auxiliary box if it is opened. (P. 529)

4

This step is not necessary when operating the left side seat only.

Folding down the seatbacks

Pull the seatback lock release

lever and fold the seatback down.

Returning the rear seatbacks

To avoid trapping the seat belt

between the seat and the inside of

the vehicle, pass the seat belt

inside the seat belt guide and then

return the seatback securely to

the locked position.

Seat belt guide

PRIUS PHV_OM_OM47A89E_(EE)

298

4-3. Adjusting the seats

WARNING

■ When folding the seatbacks down

Observe the following precautions. Failure to do so may result in death or

serious injury.

●Do not fold the seatbacks down while driving.

●Stop the vehicle on level ground, apply the parking brake firmly and shift

the shift position to P.

●Do not allow anyone to sit on a folded seatback or in the luggage compart-

ment while driving.

●Do not allow children to enter the luggage compartment.

●Do not operate the rear seat if it is occupied.

● Be careful not to get feet or hands caught in the moving parts or joints of

the seats during operation.

●Do not allow children to operate the seat.

■ After returning the seatback to the upright position

Observe the following precautions. Failure to do so may result in death or

serious injury.

● Make sure that the seatback is securely

locked in position by lightly pushing it

back and forth.

If the seatbacks is not securely locked,

the red marking will be visible on the

seatback lock release lever. Make sure

that the red marking is not visible.

●Check that the seat belts are not twisted or caught in the seatback.

PRIUS PHV_OM_OM47A89E_(EE)

4-3. Adjusting the seats

299

Head restraints

Head restraints are provided for all seats.

Front seats

1

Up

Pull the head restraints up.

2

Down

Push the head restraint down while

pressing the lock release button.

Lock release button

4

Rear seats

1

Up

Pull the head restraints up.

2

Down

Push the head restraint down while

pressing the lock release button.

Lock release button

PRIUS PHV_OM_OM47A89E_(EE)

300

4-3. Adjusting the seats

■ Removing the head restraints

Pull the head restraint up while pressing

the lock release button.

Lock release button

■ Installing the head restraints

Align the head restraint with the installa-

tion holes and push it down to the lock

position.

Press and hold the lock release button

when lowering the head restraint.

Lock release button

■ Adjusting the height of the head restraints (front seats)

Make sure that the head restraints are

adjusted so that the center of the head

restraint is closest to the top of your ears.

■ Adjusting the rear seat head restraint

Always raise the head restraint one level from the stowed position when

using.

PRIUS PHV_OM_OM47A89E_(EE)

302

4-4. Adjusting the steering wheel and mirrors

Steering wheel

Adjustment procedure

Hold the steering wheel and

1

push the lever down.

IO44PH004

Adjust to the ideal position by

2

moving the steering wheel hori-

zontally and vertically.

After adjustment, pull the lever up

to secure the steering wheel.

IO44PH005

Horn

To sound the horn, press on or

close to the

mark.

■ After adjusting the steering wheel

Make sure that the steering wheel is securely locked.

The horn may not sound if the steering wheel is not securely locked.

PRIUS PHV_OM_OM47A89E_(EE)

304

4-4. Adjusting the steering wheel and mirrors

Inside rear view mirror

The rear view mirror’s position can be adjusted to enable suffi-

cient confirmation of the rear view.

Anti-glare function

Responding to the level of brightness of the headlights of vehicles

behind, the reflected light is automatically reduced.

Changing automatic anti-glare

function mode

On/off

When the automatic anti-glare

function is in ON mode, the indica-

tor illuminates.

The function will set to ON mode

each time the power switch is

Indicator

turned to ON mode.

Pressing the button turns the func-

tion to OFF mode. (The indicator

also turns off.)

■ To prevent sensor error

To ensure that the sensors operate prop-

erly, do not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.

Doing so may lead to mishandling of the vehicle and cause an accident,

resulting in death or serious injury.

PRIUS PHV_OM_OM47A89E_(EE)

4-4. Adjusting the steering wheel and mirrors

305

Outside rear view mirrors

Adjustment procedure

1

To select a mirror to adjust, turn

the switch.

1

Left

2

Right

2

To adjust the mirror, operate the

switch.

1

Up

4

2

Right

3

Down

4

Left

Folding and extending the mirrors

1

Folds the mirrors

2

Extends the mirrors

Putting the outside rear view mirror

folding switch in the neutral posi-

tion sets the mirrors to automatic

mode.

Automatic mode allows the folding

or extending of the mirrors to be

linked to locking/unlocking of the

doors.

PRIUS PHV_OM_OM47A89E_(EE)
