Subaru Legacy (2005 year). Service manual - part 21
PI-5
PRE-DELIVERY INSPECTION
Pre-delivery Inspection
2) Completely close the driver’s door, and then
check the smooth movement with operating door
lock knob from lock to unlock several times. Set the
door lock knob (A) to lock position. Then pull the in-
ner remote (B) to ensure that doors will not open.
For other doors, place the door lock knob (A) to lock
position and then pull the inner remote (B) to en-
sure that doors will not open.
3) Close all the doors, and then press the lock on
power door lock switch at driver’s side. Check that
all doors including rear gate are locked.
4) Press the driver’s side power door lock switch to
unlock side. Check that all doors including rear
gate are unlocked.
5) Insert the key to ignition switch, and open the
driver’s side door. Press lock on power door lock.
Check that the door is not locked.
6. CHECK DOUBLE LOCK OPERATION
1) Fully open all the windows.
2) Remove the key.
3) Lock all the doors using the door key cylinder or
keyless transmitter.
4) Verify that all the doors including rear gate are
not unlocked when pressing power door lock switch
to unlock side.
5) Verify that the door is not opened when operat-
ing door lock knob to unlock position and pulling in-
ner remote. Perform the same check for other
doors.
6) Check that all the doors are unlocked when door
is unlocked using door key cylinder or keyless
transmitter, or ignition switch is turned to ON.
7. CHECK OPERATION OF CHILD SAFETY
LOCK SYSTEM
1) Set the child safety lock on both rear doors to the
lock position.
2) Close the rear doors completely.
3) Check that the lock levers of the rear doors are in
the unlock position. Then, pull inner remote of rear
doors to ensure that doors will not open.
4) Pull the outer handles to ensure that doors will
open.
(A) Door lock knob
(B) Inner remote
(A)
(B)
PI-00192
PI-00193
PI-00194
(A) Lock
(B) Unlock
PI-00164
(A)
(B)
