Renault Captur (2018 year). Manual - part 1

1.2

The RENAULT card is used

for:

– locking/unlocking the doors and

tailgate (doors, tailgate) and the fuel

filler flap (see the following pages);

– switching on the vehicle lighting re-

motely (refer to the following pages);

– starting the engine; refer to the in-

formation on “Starting the engine” in

Section 2.

1  Unlocking the doors and tailgate.
2  Locking all doors and tailgate.
3  Switching on the lighting remotely.
4  Unlocking/locking the tailgate
5  Integrated key.

RENAULT CARD: general information

(1/3)

When the battery is flat, you can

still lock/unlock and start your ve-

hicle. Refer to the information on

“Locking/unlocking the doors” in

Section 1 and “Starting the engine”

in Section 2.

Battery life

Make sure that the correct battery type

is being used, and that the battery is

in good condition and inserted cor-

rectly. Its service life is approximately

two years: replace it when the mes-

sage «KEYCARD BATTERY LOW» ap-

pears on the instrument panel (refer to

Section 5 «RENAULT card: battery").

1.3

Integrated key 5

The integrated key is used to lock or

unlock the front left-hand door if the

RENAULT card does not work:
– when the RENAULT card battery is

drained, flat battery, etc.

– use of devices using the same fre-

quency as the card;

– vehicle located in a high electromag-

netic radiation zone.

Access to key 5
Press button 6 and pull on key 5 then

release the button.

Using the key
Please refer to the information on

“Locking and unlocking the opening el-

ements”.
Once you have accessed the vehicle

using the integrated key, replace it in

its housing in the RENAULT card,

then insert the RENAULT card into

the card reader to start the vehicle.

RENAULT CARD: general information

(2/3)

RENAULT card operating

range

This varies according to the surroun-

dings: when handling the RENAULT

card, it is important to make sure that

you do not lock or unlock the doors by

inadvertently pressing the buttons.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.4

RENAULT CARD: general information

(3/3)

Replacement: need for an

additional RENAULT Card
If you lose your RENAULT card or

require another, you can obtain one

from an authorised dealer.
If a RENAULT card is replaced, it

will be necessary to take the vehi-

cle and all of its RENAULT cards to

an approved Dealer to initialise the

system.
You may use up to four RENAULT

cards per vehicle.

Advice
Avoid leaving the card in hot, cold or

humid areas.
Do not keep the RENAULT card in

a place where it could be bent or

damaged accidentally, such as in a

back pocket of a garment.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.5

Unlocking/locking the

luggage compartment only

Press button 4 to unlock/lock the lug-

gage compartment.

RENAULT card not detected

alarm

If you open a door while the engine

is running and the card is not in the

reader, the message “Keycard not de-

tected” and a beep will warn you. The

warning disappears when the card is in-

serted in the reader again.

Distance lighting function

The vehicle lights come on for approxi-

mately 20 seconds when button 3 is

pressed. This can be used, for exam-

ple, to identify the vehicle from a dis-

tance when parked in a car park.

Note: pressing button 3 again switches

off the lighting.

Locking the doors and

luggage compartment

Press the locking button 2. The indi-

cator lights and hazard warning lights

flash twice to indicate that the doors

have locked. If a door or the luggage

compartment is open or not properly

shut, or if a RENAULT card is still in the

reader, the doors and luggage compart-

ment lock then quickly unlock and the

hazard warning lights and side repeat-

ers do not flash.

Unlocking the doors and

tailgate

Press button 1.

Unlocking is indicated by one flash of

the hazard warning lights and the indi-

cator lights.

REMOTE CONTROL RENAULT CARD: use

The card buttons are deactivated when the engine is running.

The flashing status of the hazard warning lights informs you of the vehicle status:

– one flash indicates that the vehicle is completely unlocked;

– two flashes indicate that the vehicle is completely locked.

If the vehicle has been unlocked

but neither the doors or tailgate are

open, it locks again automatically

after two minutes.

1.6

HANDS-FREE RENAULT CARD: use

(1/4)

Unlocking the vehicle

With the RENAULT card in zone 1 and

the vehicle locked, press button 3 on

handle 2 on one of the two front doors:

the vehicle will unlock.

Pressing button 4 also unlocks all the

doors and the tailgate.
Unlocking is indicated by one flash of

the hazard warning lights and the indi-

cator lights.
Note: The vehicle cannot be locked

again for three seconds after unlocking

by pressing button 3.

Use

On equipped vehicles, in addition to

the functions of the remote control

RENAULT card, it can be used to lock/

unlock without using the RENAULT

card, when it is in access zone 1.

Do not store the RENAULT card

anywhere it may come into con-

tact with other electronic equipment

(computer, PDA, phone, etc.) as this

could hinder its operation.

After unlocking the vehicle using

the RENAULT card, the “hands-

free” locking and unlocking is deac-

tivated.
To reactivate the hands-free mode:

restart the vehicle.

1.7

HANDS-FREE RENAULT CARD: use

(2/4)

The side indicator lights and hazard

warning lights flash twice and a beep

sounds to indicate that the doors have

locked.
The beep may be switched off. Please

contact an authorised dealer.
If a door or the tailgate is open or not

properly shut, or a card is in the pas-

senger compartment (or the card

reader) the vehicle will not lock. In

this situation, no beep sounds and the

hazard warning lights and side repeat-

ers do not flash.

Locking the vehicle

There are three ways to lock the vehi-

cle: remotely, using button 3, or using

the RENAULT card.

Remote locking
With the RENAULT card on you, and

doors and tailgate closed, move away

from the vehicle: it will lock automati-

cally once you have left zone 1.
Note: the distance at which the vehicle

locks depends on the surroundings.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

1.8

HANDS-FREE RENAULT CARD: use

(3/4)

Note: a RENAULT card must be within

the vehicle's access zone (zone 1) to

be able to lock the vehicle using the

button.
NB: the vehicle cannot be locked again

for three seconds after unlocking after

pressing button 3.

Locking using the RENAULT card
With the doors and luggage compart-

ment closed, press button 5: the vehi-

cle will lock.

The indicator lights and hazard warning

lights flash twice to indicate that the

doors have locked.

After locking/unlocking the vehicle

using the buttons on the RENAULT

card, “hands-free” locking and un-

locking is deactivated.
To reactivate the “hands-free” mode:

restart the vehicle.

Locking using button 3
With the doors and boot closed, press

button 3 on one of the front door han-

dles. The vehicle will lock. The indicator

lights and hazard warning lights flash

twice to indicate that the doors have

locked.
If a door or the tailgate is open or not

properly closed, the vehicle will quickly

lock/unlock.

Note: the maximum distance at which

the vehicle locks depends on the sur-

roundings.

1.9

HANDS-FREE RENAULT CARD: use

(4/4)

Special features
The vehicle will not lock if:
– a door or the tailgate is open or not

properly closed;

– a card is still in zone 6 (or in the card

reader) and no other card is in the

external detection zone.

Driver’s responsibility

when parking or stopping

the vehicle
Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.
They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.
Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.
RISK OF DEATH OR SERIOUS

INJURY.

“Hands-free” RENAULT card non-

detection alarm
With the engine running, if you open

and close a door and the card is no

longer within range 6, the message

“Keycard not detected” and a beep

warns you of this.
The warning disappears when the card

is again within range 6.

1.10

Never use deadlocking if

someone is still inside the

vehicle.

Vehicle with RENAULT card
Press button 2 twice in quick succes-

sion.

Vehicle with RENAULT “hands-free”

card
With the vehicle unlocked, you can

also press the button 3 on the driver’s

or passenger’s side door twice in quick

succession.
In both cases, locking is indicated by

the hazard warning lights flashing five

times.

If the vehicle is equipped with a dead-

locking function, this allows you to lock

the opening elements and to prevent

the doors from being unlocked using

the interior handles (for example, by

breaking the window and then trying to

open the door from the inside).

RENAULT CARD: deadlocking

After activating the deadlocking

function using button 2, “hands-

free” locking and unlocking are de-

activated.
To reactivate the “hands-free” mode:

restart the vehicle.

1.11

Opening from the inside

Pull handle 4.

Lights-on reminder buzzer

If you have switched off the ignition

and left the lights switched on, a re-

minder buzzer will sound when a door

is opened.

Opening the doors from the

outside

With the doors unlocked, pull handle 1.

Special feature of the RENAULT

“hands-free” card
With the doors locked, press button 2

on handle 1 of one of the two front

doors and pull towards you.

OPENING AND CLOSING THE DOORS

(1/2)

As a safety precaution,

the doors should only be

opened or closed when the

vehicle is stationary.

Card reminder buzzer

On opening the driver’s door, if the

card is still in the reader, the message

“PLEASE REMOVE KEYCARD” is dis-

played on the instrument panel accom-

panied by a warning beep.

Door/tailgate open buzzer

If an opening (door or boot) is left

open or closed badly, once the vehi-

cle reaches around 12 mph (20 km/h),

either the message “BOOT OPEN” or

“DOOR OPEN” (depending on which

opening) is displayed on the instrument

panel together with a beep.

1.12

Child safety

To make it impossible for the rear doors

to be opened from the inside, move

lever 5 on each door and check from

the inside that the doors are securely

locked.

OPENING AND CLOSING THE DOORS

(2/2)

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

They may pose a risk to themselves

or to others by starting the engine,

activating equipment such as the

electric windows or locking the

doors.

Also, in hot and/or sunny weather,

please remember that the tempera-

ture inside the passenger compart-

ment increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

1.13

Locking the doors manually

Turn screw 2 with the door open (using

the end of the key) and close the door.
This means that the doors are then

locked from the outside.
The doors may then only be opened

from the inside or by using the key in

the front left-hand door.

Using the key integrated in

the RENAULT card

Insert key 1 into the lock in the driver’s

door and lock or unlock.

Locking/Unlocking the doors

from the outside

This is done using the RENAULT Card;

see the “RENAULT Card” information in

Section 1.
In certain cases, the RENAULT card

may not work:
– if the RENAULT card battery is weak,

flat, etc.

– if equipment operating on the same

frequency as the card (mobile

phones, etc.) is used;

– vehicle located in a high electromag-

netic radiation zone.

It is then possible:
– to use the key integrated into the

card to unlock the front left-hand

door;

– to lock each of the doors manually;
– to use the interior door locking/un-

locking control (refer to the following

pages).

LOCKING, UNLOCKING THE DOORS

(1/2)

1.14

LOCKING, UNLOCKING THE DOORS

(2/2)

Door and tailgate status

indicator

With the ignition on, the warning light

integrated in switch 3 informs you of the

locking status of the opening elements:
– indicator light on, the doors and tail-

gate are locked,

– indicator light off, the doors and tail-

gate are unlocked.

When you lock the doors, the indicator

light remains lit and then goes out.

Locking the doors without

the RENAULT card

For example, in the event of a dis-

charged battery or the RENAULT card

temporarily not working, etc.
With the engine switched off and

an opening element (door or boot)

open, press and hold switch 3 for more

than five seconds.
When the door is closed, all the doors

and the tailgate will be locked.
Unlocking the vehicle from the outside

is only possible with the RENAULT card

in the vehicle's access zone or using

the key integrated in the RENAULT

card.

Interior locking/unlocking

door control

Switch 3 controls the doors, boot and,

depending on the vehicle, the fuel filler

flap simultaneously.
If a door or the tailgate is open or not

closed properly, the doors and tailgate

lock/unlock quickly.
If you need to transport objects with the

boot open, the other opening elements

can still be locked: with the engine

stopped, press switch 3 for more than

five seconds to lock the other opening

elements.

Driver’s responsibility
If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the

passenger compartment in the

event of an emergency.

Never leave your vehicle

with the RENAULT card

inside.

After locking/unlocking the vehicle

or the luggage compartment only

using the buttons on the RENAULT

card, remote locking and unlocking

in hands-free mode are deactivated.
To reactivate the “hands-free” mode:

restart the vehicle.

1.15

Operating principle

After the vehicle is started, the system

automatically locks the doors when

you are driving at approximately 6 mph

(10 km/h) and over.
The door can be unlocked:
– by pressing the button 1 to unlock

the doors;

– by opening a front door (vehicle sta-

tionary).

NB: if a door is opened or closed, it will

automatically lock again when the vehi-

cle reaches a speed of 6 mph (10 km/h).

Activating/deactivating the

function

With the engine running, press the

button 1 for approximately 5 seconds,

until you hear a warning beep.

Operating faults

If you experience an operating fault

(no automatic locking, the indicator

light incorporated in button 1 does not

light up when trying to lock the open-

ing elements, etc.), firstly check that the

opening elements are properly closed.

If they are properly closed, contact an

authorised dealer.

RENAULT ANTI-INTRUDER DEVICE (RAID)

Driver’s responsibility
If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the

passenger compartment in the

event of an emergency.

1.16

FRONT HEADRESTS

To raise the headrest

Pull the headrest upwards to the de-

sired height. Check that it is correctly

locked.

To lower the headrest

Press button 1 and guide the headrest

down to the desired height. Check that

it is correctly locked.

To raise the headrest

Raise the headrest to its highest po-

sition (tilt the seatback backwards if

necessary). Press button 1 and lift the

headrest to release it.

To refit the headrest

Insert the headrest rods into the holes

(tilt the seatback backwards if neces-

sary). Lower the headrest until it locks

and press button 1 to adjust to the de-

sired height. Check that each rod 2 on

the seatback is securely locked.

The headrest is important

for safety. Ensure that it is in

place and in the correct po-

sition: the top of the head-

rest should be as close as possible

to the top of the head and there must

be a minimal distance between the

head and the headrest A.

1.17

Heated seats

With the ignition on, press the switch 4

for the seat desired. The indicator light

in the switch lights up.

The system, which has a thermostat,

regulates the heating and deactivates it

if necessary.

To move the seat forwards or

backwards

Lift handle 1 to unlock. Release the

handle once the seat is in the correct

position and ensure that the seat is

locked.

To raise or lower the seat

base

Move lever 2 as many times as neces-

sary upwards or downwards.

FRONT SEATS (1/2)

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

Nothing should be placed on the

floor (area in front of driver) as such

objects may slide under the pedal

during braking manoeuvres, thus

obstructing its use.

To tilt the seatback

Turn the control knob 3 and tilt the seat-

back to the desired position.

We would advise you not

to recline the seatbacks too

far to ensure that the effec-

tiveness of the seat belts is

not reduced.

Content .. 1 2 ..
