Peugeot 308 CC Dag (2010.5). Manual

INSTRUMENTS and CONTROLS

PETROL - DIESEL MANUAL OR AUTOMATIC GEARBOX
INSTRUMENT PANELS

Panel grouping together the vehicle
operation indication dials and warning
lamps.

  5.    Small screen.
  6.    Central screen.
  7.    Control button.

Starts a manual CHECK and recalls
the service information.

Resets the function to zero (trip dis-
tance recorder or service indicator).

8. Instrument panel lighting dimmer

Adjusts the brightness of the lighting
of the instruments and controls.

Dials

1. Rev counter.

Indicates the speed of rotation of the
engine (x 1 000 rpm).

2. Coolant temperature.

Indicates the temperature of the
engine coolant (° Celsius).

3. Fuel level.

Indicates the quantity of fuel remain-
ing in the tank.

4. Vehicle speed.

Indicates the current speed of the
moving vehicle (mph or km/h).

A. Trip distance recorder.

(miles or km)

B. Distance recorder.

(miles or km)

C. Engine oil level indicator,

service indicator.

(miles or km)

These  two  functions  are  displayed
when  the  ignition  is  switched  on,
then disappear after a few seconds.

Displays

For more information, refer to the
paragraph which relates to the but-
ton or function and its associated
display.

The following functions are displayed in
accordance with the selection.
-

Warning lamps/CHECK.

Tyre under-inﬂ ation detection.

Speed limiter/Cruise control.

Gear shift indicator.

Automatic gearbox.

Navigation - Guidance/Trip computer.

INSTRUMENTS and CONTROLS

PETROL - DIESEL MANUAL OR AUTOMATIC GEARBOX PEUGEOT
CONNECT MEDIA INSTRUMENT PANELS

Panel grouping together the vehicle
operation indication dials and warning
lamps.

  5.    Small screen.
  6.    Central screen.
  7.    Control button.

Starts a manual CHECK and recalls
the service information.

Resets the function to zero (trip dis-
tance recorder or service indicator).

8. Instrument panel lighting dimmer .

Adjusts the brightness of the lighting
of the instruments and controls.

Dials

1. Rev counter.

Indicates the speed of rotation of the
engine (x 1 000 rpm).

2. Coolant temperature.

Indicates the temperature of the
engine coolant (° Celsius).

3. Fuel level.

Indicates the quantity of fuel remain-
ing in the tank.

4. Vehicle speed.

Indicates the current speed of the
moving vehicle (mph or km/h).

A. Trip distance recorder.

(miles or km)

B. Distance recorder.

(miles or km)

C. Engine oil level indicator,

se rvice indicator.

(miles or km)

These  two  functions  are  displayed
when  the  ignition  is  switched  on,
then disappear after a few seconds.

Displays

For further information, refer to the
paragraph which relates to the but-
ton or function and its associated
display.

The following functions are displayed in
accordance with the selection.
-

Warning lamps/CHECK.

Tyre under-inﬂ ation detection.

Speed limiter/Cruise control.

Gear shift indicator.

Automatic gearbox.

Navigation - Guidance/Trip computer.

Vehicle parameters.

INSTRUMENTS and CONTROLS

* According to country.

Instrument panel navigator associated
with the Peugeot Connect Media

Main menu
 Press button 1 to open the main

menu and select one of the following
functions:

   -   "Vehicle parameters",
  -   "Choice of language",
  -   "Choice of units".

 Press button 2 or 3 to move on the

screen.

 Press button 1

again to conﬁ rm the

selection.

  Vehicle parameters
This  menu  allows  you  to  activate  or
deactivate  certain  driving  and  comfort
equipment:
   -

selective unlocking (refer to the

"Access" section),

guide-me-home and welcome light-

ing (refer to the "Visibility" section),

interior mood lighting (refer to the

"Visibility" section),

daytime running lamps (refer to the

"Visibility" section),

directional headlamps (refer to the

"Visibility" section),

rear parking sensors (refer to the

"Driving" section).

  Choice of language
This menu allows you to select the lan-
guage  used  by  the  screen:  Deutsch,
English,  Espanol,  Français,  Italiano,
Nederlands, Portugues, Türkçe * .

  Choice of units
This menu allows you to select the units:
temperature  (°Celsius  or  °Fahrenheit)
and  fuel  consumption  (mpg,  km/l  or
l/100 km).

This group of buttons permits:
-

when stationary

, conﬁ guration of

the vehicle's equipment and the
central screen settings (language,
units...),

while driving , scrolling through the
active functions (trip computer, navi-
gation...).

Controls
There are four buttons to control the in-
strument panel large screen:
1.

access the main menu, conﬁ rm the

selection,

  2.   move up through the menu,
  3.   move down through the menu,
  4.   return  to  the  previous  screen,  exit

from the menu.

The main menu and its associated
functions  can  only  be  accessed
when stationary, via buttons  1  to  4 .
A  message  appears  in  the  cen-
tral screen, above a certain speed
threshold,  indicating  that  the  main
menu cannot be displayed.
Trip computer information can only
be  displayed  while  driving,  using
buttons   2   and   3   (refer  to  the  "Trip
computer" section).

INSTRUMENTS and CONTROLS

The warning lamps may come on

continuously or ﬂ ash.
Certain  warning  lamps  may  come
on in two different modes. Only by
relating  the  type  of  lighting  to  the
operating status of the vehicle can
it  be  ascertained  whether  the  situ-
ation  is  normal  or  whether  a  fault
has occurred.

Indicator and warning lamps

Visual indicators informing the driver
that a system is in operation (operation
or deactivation indicator lamps) or of the
occurrence of a fault (warning lamp).

Associated warnings

The  switching  on  of  certain  warning
lamps  may  be  accompanied  by  an
audible  signal  and  a  message  on  the
multifunction screen.

Operation indicator lamps

If one of the following indicator lamps

comes on, this conﬁ rms that the corre-

sponding system has come into opera-
tion.

Left-hand direction indicator.

Parking brake applied.

Right-hand direction
indicator.

Main beam headlamps.

Dipped beam headlamps.

Diesel engine pre-heating.

Wait until this has gone out
before operating the starter.

Front foglamps.

Rear foglamp.

When the ignition is switched on

The  warning  lamps  come  on  for  a  few
seconds  when  the  vehicle's  ignition  is
switched on.
When the engine is started, these warning
lamps should switch off.
If  they  remain  on,  before  moving  off,
consult the warning lamp concerned.

Common operation indicator lamps

INSTRUMENTS and CONTROLS

Speciﬁ c operation indicator lamps

The  other  indicator  lamps  appear  on
the  large  screen,  located  in  the  centre
of the instrument panel.

Automatic locking.

If  this  is  displayed,  it  indicates
that  you  have  activated  auto-
matic  locking  of  the  doors  and
boot while driving.

Speed limiter.

If this is displayed, it indicates
that  you  have  activated  the
speed limiter mode.
If  this  is  displayed,  it  indi-
cates  that  you  can  set  the
speed limiter speed value to
be stored.

Cruise control.

If this is displayed, it indicates
that  you  have  activated  the
cruise control mode.
If  this  is  displayed  it  indi-
cates  that  you  can  set  the
cruise  control  speed  value
to be stored.

Automatic gearbox.

Automatic rain sensitive wipers.

  If  this  is  displayed,  it  indicates
that  you  have  activated  auto-
matic  rain  sensitive  windscreen
wipers.

Automatic illumination of
headlamps.

If this is displayed, it indicates
that you have activated automat-
ic illumination of headlamps.

This display indicates the gear
engaged in the automatic or
manual operation programme.

This  display  indicates  the  op-
erating  programme  selected
(automatic,  sport,  snow  or
manual).

This  display  indicates  the  posi-
tion  that  you  have  selected  on
the  gear  selection  gate  (P,  R,  N
or D).

INSTRUMENTS and CONTROLS

Deactivation warning lamps

If one of the following warning lamps

comes on, this conﬁ rms that the corre-

sponding system has been switched off
intentionally.

Passenger's airbag system
deactivation.

The passenger's airbag system
is put into service automatically
when the vehicle is started.

A speciﬁ c control switch, located on the

passenger's side of the dashboard, per-
mits deactivation of the system. This is

conﬁ rmed by continuous lighting of this

warning  lamp  on  the  instrument  panel
or  on  the  seat  belt  and  passenger's
front airbag warning lamps display.

Dynamic stability control
(ESP/ASR) deactivation

The ESP/ASR system is put
into service automatically when
the vehicle is started.

Common deactivation warning lamps

Speciﬁ c deactivation warning lamps

Automatic locking.

If  this  is  displayed,  it  indicates
that  you  have  deactivated  the
automatic  locking  of  the  doors
and boot while driving.

Automatic rain sensitive
windscreen wipers.

  If this is displayed, it indicates that
you  have  deactivated  automatic
rain sensitive windscreen wipers.

The other warning lamps appear on the
large screen, located in the centre of
the instrument panel.

Speed limiter.

If this is displayed, it indicates
that you have deactivated the
speed limiter.

Cruise control.

If this is displayed, it indicates
that you have deactivated the
cruise control.

Automatic illumination of
headlamps.

If this is displayed, it indicates
that you have deactivated auto-
matic illumination of headlamps.

A speciﬁ c button, located on

the dashboard, permits deac-
tivation of the system. This is

conﬁ rmed by continuous light-

ing of this warning lamp and of the indi-
cator lamp on the button.
From approximately 30 mph (50 km/h),
the system is reactivated automatically.

INSTRUMENTS and CONTROLS

When the engine is running or the ve-
hicle is moving, the lighting of one of the
following warning lamps indicates the
occurrence of a fault requiring action by
the driver.

Central alert.

Lighting is associated with
the display of another warn-
ing lamp:

punctured wheel,

braking,

power steering,

engine oil pressure,

coolant temperature,

requiring you to stop the vehicle as soon
as it is safe to do so.

Service.

If this comes on, it indicates the
occurrence of a problem in one
of the systems which does not

have a speciﬁ c warning lamp.

In order to identify it, see the message
in the multifunction screen.
It comes on temporarily for minor faults
which can be resolved by the driver.

Braking.

If this comes on, it indicates the
occurrence of a fault in one of
the braking systems:

- signiﬁ cant drop in the ﬂ uid level in

the system,

electronic brake force distribution
(EBFD) fault (the ABS warning lamp
comes on as well),

stop the vehicle immediately as soon as
it is safe to do so.
When the vehicle is moving, check that
the parking brake is fully released.

Any  fault  resulting  in  the  display
of a warning lamp must be investi-
gated  further  by  reading  the  asso-
ciated message in the multifunction
screen.
Should  you  encounter  any  prob-
lems,  do  not  hesitate  to  contact  a
PEUGEOT dealer.

Warning lamps

Anti-lock braking system
(ABS).

If this comes on, it indicates the
occurrence of a fault in the anti-
lock braking system.

However,  this  does  not  prevent  op-
eration  of  the  vehicle's  servo-assisted
braking.

Common warning lamps

Minor faults may be connected with:
-

opening the doors, boot and bonnet,

the remote control battery,

the engine oil level,

- the screenwash ﬂ uid level,
-

tyre pressures,

saturation of the particle emission

ﬁ lter (Diesel),

For  other  situations,  involving  ma-
jor  faults,  the  warning  lamp  comes  on
permanently;  such  faults  should  be
checked by a PEUGEOT dealer.

INSTRUMENTS and CONTROLS

Engine self-diagnostic
system.

If this comes on, it indicates the
occurrence of a fault in the en-
gine management system.

If it ﬂ ashes, it indicates the occurrence of

a fault in the emission control system.

Maximum coolant
temperature.

If this comes on, it indicates that
the temperature in the cooling

system is too high. Stop the vehicle as
soon as it is safe to do so.

Low fuel level.
When this ﬁ rst comes on, you

have approximately 6 litres of
fuel remaining in the tank.

Refuel as soon as possible to avoid run-
ning out of fuel.

Airbags.

  If this comes on, it indicates the
occurrence  of  a  fault  in  one  of
the  airbag,  roll-over  hoop  or
seat belt pretensioner systems.

Seat belt not fastened/
unfastened.

If this comes on, it indicates
that the driver and/or the front

passenger has not fastened or has un-
fastened their seat belt.
It also indicates that one or more rear
passengers have unfastened their seat
belt.

Water in Diesel * .

If this comes on, it indicates the
presence of water in the Diesel

ﬁ lter.

There is a risk of damage to the injec-
tion system on Diesel engines.

Door open.

A door or the boot is open:

Battery charge.

If this comes on, it indicates
the occurrence of a fault in the
battery charging circuit (dirty or

loose terminals, slack or cut alternator
belt...).

Engine oil pressure.

  If this comes on, it indicates the
occurrence of a fault in the en-
gine  lubrication  system.  Stop
the vehicle as soon as it is safe
to do so.

Speciﬁ c warning lamps

Dynamic stability control
(ESP/ASR).

The ESP/ASR system is put
into service automatically when
the vehicle is started.

Unless the system has been deactivated, if this
warning lamp and the indicator lamp on the
button come on continuously, this indicates the
occurrence of a fault in the ESP/ASR system.

* According to country.

if the speed is below 6 mph (10 km/h), this
warning lamp comes on continuously.

if  the  speed  is  higher  than  6  mph
(10 km/h),  this  warning  lamp  comes
on  continuously,  accompanied  by  an
audible signal.

Never  continue  to  drive  until  you
run  out  of  fuel,  this  could  damage
the  emission  control  and  injection
systems.

Foot on brake.

Press  the  brake  pedal  to  start
the  engine  with  the  automatic
gearbox.

Until sufﬁ cient fuel has been added, this

warning  lamp  comes  on  again  every  the
ignition is switched on, along with an au-
dible signal and an alert message. When
driving, this audible signal and the display
of the message are repeated with increas-
ing  frequency,  as  the  fuel  level  drops  to-
wards  "0" .
Capacity of the tank: approximately  60 litres .

INSTRUMENTS and CONTROLS

The display of certain warning
lamps may be accompanied by an
audible signal and a message in
the multifunction screen.

Speciﬁ c warning lamps

The other warning lamps appear on the
large  screen,  located  in  the  centre  of
the instrument panel.
Depending  on  the  seriousness  of  the
fault,  they  may  be  displayed  in  orange
or red.

Certain  warning  lamps  may  be
linked with those of the instrument
panel.
If  they  are  linked  with  the   STOP
warning  lamp,  stop  the  vehicle  as
soon as it is safe to do so.

Directional headlamps.
If this ﬂ ashes, it indicates the

occurrence of a fault in the di-
rectional headlamps system.

Engine oil pressure.

  If  this  is  displayed,  it  indicates
the  occurrence  of  a  fault  in  the
engine  lubrication  system.  Stop
the vehicle as soon as it is safe
to do so.

Service.

If this is displayed, it indicates the occur-
rence of a fault in one of the following:

Engine self- diagnostic
system.

If this is displayed, it indicates
the occurrence of a fault in the
engine management system.

Engine oil level.

If this is displayed, it indicates

an insufﬁ cient level of oil in the

engine. Stop the vehicle as
soon as it is safe to do so.

Coolant temperature.

  If  this  is  displayed,  it  indicates
that the temperature in the cool-
ing system is too high. Stop the
vehicle  as  soon  as  it  is  safe  to
do so.

Battery charge.

If this is displayed, it indicates
the occurrence of a fault in the
battery charging circuit (dirty or

loose terminals, slack or cut alternator
belt...).

the engine management system,

the emission control system.

INSTRUMENTS and CONTROLS

Airbags.

  If  this  is  displayed,  it  indicates
the occurrence of a fault in one
of  the  airbag,  roll-over  hoop
or  pretensioning  seat  belt  sys-
tems.

Braking.

If this is displayed, it indicates
the occurrence of a fault in one
of the braking systems:

- signiﬁ cant drop in the ﬂ uid level in

the system,

electronic brake force distribution
(EBFD) fault (the ABS warning lamp
comes on as well).

Stop the vehicle as soon as it is safe to
do so.
If the vehicle is moving, check that the
parking brake is fully released.

Anti-lock braking system
(ABS).

If this is displayed, it indicates
the occurrence of a fault in the
anti-lock braking system.

However,  this  does  not  prevent  op-
eration  of  the  vehicle's  servo-assisted
braking.

Dynamic stability control
(ESP/ASR).

The ESP/ASR system is put into
service automatically when the ve-
hicle is started.

Unless the system has been deactivated, if
this warning lamp and the indicator lamp on
the button come on, this indicates the occur-
rence of a fault in the ESP/ASR system.

Door open.

A door or the boot is open:

Ice warning.

  If  this  is  displayed,  it  indicates
that  there  is  risk  of  the  forma-
tion of ice on the road  below  a
temperature of 3 °C.

Drive carefully.

Parking brake.

If this is displayed, while the ve-
hicle is moving, it indicates that
the parking brake has not been
fully released.

Electronic immobiliser.

If this is displayed, it indicates
the occurrence of a fault in the
electronic engine immobiliser

system or that the remote control bat-

tery is ﬂ at.

Fuel level.
When this ﬁ rst comes on, you

have approximately 6 litres of
fuel left in the tank.

It is imperative that you refuel to avoid
running out of fuel.
Until sufﬁ cient fuel has been added, this

warning  lamp  comes  on  again  every
time  the  ignition  is  switched  on,  accom-
panied by an audible signal and an alert
message.  When  driving,  this  audible
signal  and  the  display  of  the  message
are repeated with increasing frequency
as the fuel level drops towards  "0" .
Capacity  of  the  tank:  approximately
60 litres .

Screenwash ﬂ uid level.
If this is displayed, following an
action on the wiper stalk, it indi-

cates that the ﬂ uid level is low.

Fill the screenwash/headlamp wash ﬂ u-

id reservoir when you next stop.

if the speed is below 6 mph (10 km/h),
this warning lamp is displayed in orange,

if  the  speed  is  higher  than  6  mph
(10 km/h),  this  warning  lamp  is  dis-
played in red.

Coolant level.

If this is displayed, it indicates

an insufﬁ cient level of coolant in

the system. Stop the vehicle as
soon as it is safe to do so.

Never  continue  to  drive  until  you
run  out  of  fuel,  this  could  damage
the  emission  control  and  injection
systems.

AUTO

PRND

INSTRUMENTS and CONTROLS

Water in Diesel * .

If this is displayed, it indicates
the presence of water in the

Diesel ﬁ lter.

There is a risk of damage to the injection
system on Diesel engines.

Automatic headlamp
adjustment.

If this is displayed, it indicates the
occurrence of a fault in the auto-
matic headlamp adjustment.

  Particle emission ﬁ lter (Diesel).
If  this  is  displayed,  linked  with
the service warning lamp, it in-
dicates  the  start  of  saturation

of the particle emission ﬁ lter or a low

Diesel additive reservoir level.
As soon as trafﬁ c conditions permit, re-

generate the ﬁ lter by driving at a speed

of  at  least  40  mph  (60  km/h)  until  the
service warning lamp is switched off.
If  the  service  warning  lamp  is  still  dis-
played, the additive level is low. Have it
topped up by a PEUGEOT dealer with-
out delay.

   Under-inﬂ ated tyre.
If  this  is  displayed,  it  indicates
low  pressure  in  one  or  more
wheels.

Check the tyre pressures as soon as
possible.

Punctured tyre.

  If  this  is  displayed,  it  indicates
that  one  or  more  wheels  are
punctured.  Stop  the  vehicle  as
soon as it is safe to do so.

Change the damaged wheel and have it
repaired by a PEUGEOT dealer.

Tyre under-inﬂ ation

detection.

If this is displayed, it indicates
the occurrence of a fault on one

of the sensors or in the tyre under-inﬂ a-

tion detection system.
It may also indicate the absence of a
sensor when the spare wheel, which

does not have a sensor, is ﬁ tted in place

of a punctured wheel.

Automatic lighting.

If this comes on, it indicates the
occurrence of a fault in the au-
tomatic lighting.

Use the other positions of the lighting
stalk to control the lighting manually.

Visual and/or audible
parking sensors.

If this comes on, in forward and/
or reverse gear, it indicates a fault
in the parking sensor system.

Automatic gearbox.

If this is displayed, it indicates
the occurrence of a fault in the
automatic gearbox. The gear-

box  will  then  operate  in  down-grade
mode, locked on 3rd gear.
It  may  also  be  displayed  if  a  door  is
opened.

Invalid value.

If  this  is  displayed,  it  indicates
the occurrence of a fault in the
programme  of  the  automatic
gearbox.

Position P or N.

If  this  is  displayed,  it  indicates
that  the  gear  lever  must  be
placed in position  P  or  N  in or-
der to start the engine.

* According to country.

Power steering.

  If  this  is  displayed,  it  indicates
the  occurrence  of  a  fault  in  the
power steering. Stop the vehicle
as soon as it is safe to do so.

INSTRUMENTS and CONTROLS

Coolant temperature indicator

With the engine running, when the needle
is:
-

in zone A , the temperature is
correct,

in  zone   B ,  the  temperature  is  too
high;  the  max  temperature  warning
lamp  1  and the central  STOP  warning
lamp come on, accompanied by an
audible signal and a message in the
multifunction screen.

You must stop as soon as it is safe
to do so.
Wait a few minutes before switching off
the engine.
Consult a PEUGEOT dealer.

After driving for a few minutes, the tem-
perature  and  pressure  in  the  cooling
system increase.
To top up the level:
      wait for the engine to cool,
     unscrew  the  cap  by  two  turns  to

allow the pressure to drop,

 when the pressure has dropped,

remove the cap,

 top up the level to the "MAX" mark.

INSTRUMENTS and CONTROLS

The level read will only be correct if
the vehicle is on level ground and
the engine has been off for more
than 15 minutes.

Engine oil level indicator

System which informs the driver whether
the engine oil level is correct or not.

This information is indicated for a few
seconds when the ignition is switched
on, after the service information.

Oil level correct

Lack of oil

Oil level indicator fault

Dipstick

This is indicated by the ﬂ ashing of

"OIL" , linked with the service warning
lamp, accompanied by an audible sig-
nal and a message on the multifunction
screen.
If the lack of oil is conﬁ rmed by a check

using the dipstick, it is essential that the
level is topped up to prevent damage to
the engine.

This is indicated by the ﬂ ashing of "OIL --" .

Consult a PEUGEOT dealer.

Refer to the "Checks" section to locate

the dipstick and the oil ﬁ ller cap on your

engine.

There are 2 marks on the
dipstick:
-

A = max; never exceed
this level (risk of dam-
age to the engine),

B = min; top up the level

via the oil ﬁ ller cap, us-

ing the grade of oil suit-
ed to your engine.

INSTRUMENTS and CONTROLS

Service indicator

System which informs the driver when the
next service is due, in accordance with
the manufacturer's servicing schedule.
The point at which the service is due is
calculated from the last indicator zero re-
set. It is determined by two parameters:
-

the distance travelled,

the time elapsed since the last
service.

Between 600 miles (1 000 km) and
1800 miles (3 000 km) remain before
the next service is due

For  5  seconds  after  the  ignition  is
switched  on,  the  spanner  symbolising
the  service  operations  comes  on.  The
distance recorder display line indicates
the  distance  remaining  before  the  next
service is due.
  Example:  1 700 miles (2 800 km) remain
before the next service is due.
For  5  seconds  after  the  ignition  is
switched on, the screen indicates:

5 seconds after the ignition is switched
on, the spanner goes off ; the distance
recorder resumes its normal operation.
The screen then indicates the total and
trip distances.

Less than 600 miles (1 000 km)
remain before the next service is due

Example: 400 miles (900 km) remain
before the next service is due.
For 5 seconds after the ignition is
switched on, the screen indicates:

5 seconds after the ignition is switched
on,  the  distance  recorder  resumes  its
normal  operation.   The  spanner  re-
mains  on   to  indicate  that  a  service
must be carried out soon.

More than 1 800 miles (3 000 km)
remain before the next service is
due

When the ignition is switched on, no ser-
vice information appears in the screen.

INSTRUMENTS and CONTROLS

Following this operation, if you wish
to disconnect the battery, lock the

vehicle and wait at least ﬁ ve minutes

for the zero reset to be registered.

Service indicator zero reset

After each service, the service indicator
must be reset to zero.
The procedure for resetting to zero is as
follows:
 switch off the ignition,
 press and hold the ".../000" button

on the right of the instrument panel,

 switch on the ignition; the distance

recorder display begins a count-
down,

 when the instrument panel central

screen indicates "=0" , release the
button; the spanner disappears from
the screen.

The  distance  remaining  may  be
weighted by the time factor, depend-
ing on the driver's driving habits.
Therefore,  the  spanner  may  also
come on if you have exceeded the
two year service interval.

Service overdue

For 5 seconds after the ignition is
switched on,

the spanner ﬂ ashes to

indicate that the service must be carried
out as soon as possible.
Example: the service is overdue by
180 miles (300 km).
For 5 seconds after the ignition is
switched on, the screen indicates:

5 seconds after the ignition is switched
on,  the  distance  recorder  resumes  its
normal  operation.   The  spanner  re-
mains   on .

Retrieving the service information

You can access the service information
at any time.
This  information  appears,  depending
on  version,  when  running  through  the
manual check procedure.
   

Brieﬂ y press the ".../000" button on

the right of the instrument panel.

The service information is displayed
for a few seconds on the instrument
panel central screen, then disap-
pears.

INSTRUMENTS and CONTROLS

Manual Check

This function allows you to check the sta-
tus of the vehicle (reminder of the alert

warnings and of the state of the conﬁ gu-

rable functions - "activated" or "deacti-
vated") and the service information.

 With the engine running, to start

a manual check, brieﬂ y press the

"CHECK/000" button on the instru-
ment panel.

If  no  faults  have  been  detected,
"CHECK  OK"   appears  in  the  instru-
ment panel central screen.
If a "minor" fault has been detected, the
warning lamp concerned then  "CHECK
OK"   appear  in  the  instrument  panel
central  screen.  Consult  a  PEUGEOT
dealer.
If a "major" fault has been detected, only
the  warning  lamps  concerned  appear
in  the  instrument  panel  central  screen.
Have it checked by a PEUGEOT dealer.

Distance recorders

The total and trip distances are displayed
for thirty seconds when the ignition is
switched off, when the driver's door is
opened and when the vehicle is locked
or unlocked.

Total distance recorder

Measures the total distance travelled by

the vehicle since its ﬁ rst registration.

 With the ignition on, press and hold

this button until zeros appear.

Trip distance recorder

Measures a distance travelled since it
was reset to zero by the driver.

Peugeot 308 CC Dag (2010.5). Manual - part 2
