291

Satellite radio

R

The display indicates that the user is
currently listening to Ch042 (Channel 42
Hot Jamz on SR1).

The Song Seek pop-up (Song Seek
Interrupt) is giving the user the choice to
listen instead, to a Favourites (Guns &
Roses) which is currently playing on
Channel 021.

Activating song seek

To activate Song Seek, select Settings
and then select Song Seek.

When the feature is active, pressing the
PDT button on the Settings display
screen, will present the user with the
Satellite Information display pop-up
where the current favourite songs can be
viewed and edited.

When the feature is not active, the user
cannot add to or edit the favourite songs
list. However, the PDT information can
still be seen by selecting the PDT button.

Editing song seek favourites list

Note: Editing of the favourites list cannot
be carried out while the vehicle is in
motion.

To edit the list of songs in Song Seek,
select Edit Favourites on the SAT
Information pop-up.

If Song Seek is not active, then both Add
to Favourites and Edit Favourites will
be inoperative.

If Edit Favourites is selected, then the
following screen will be displayed.

Delete All is highlighted and if selected,
all songs in the Song Seek favourites list
will be deleted.

AM/FM

Sat Radio

CD

Guns & Roses

 SR1   Ch042 Hot Jamz

R&B/ Urban

Settings

Audio

12 : 34 pm

E94019

Guns & Roses
The Rock.....
Switch to Channel 021?

SongSeek Interrupt

No

Yes

AM/FM

Sat Radio

CD

Octane

I-90

1053

Bridge

Pulse

Nation

Guns & Roses

Sat Options

 SR1   CH022 Octane

Rock Hits

Settings

Audio

12 : 34 pm

E94020

AM/FM

Sat Radio

CD

Guns & Roses

 SR1   Ch021 Octane

Rock

Settings

Audio

12 : 34 pm

E94021

Guns & Roses

The Rock

SAT Information

Add to Favorites

Edit Favorites

 SR1   Ch021 Octane

Audio

Pink Floyd           Breathe

Beatles                 Revolver

Guns & Roses       Paradise City

Beatles                 Eleanor Rigby

The Who               My Generation

Delete All

12 : 34 pm

Delete

E94022

Satellite radio

292

L

Should only one song at a time be
required to be deleted, select the
particular song on the list.

Select Delete to delete that song only.
Repeat the procedure for each song to be
deleted.

In all cases the user will be asked to
confirm that the song or songs should be
deleted.

Adding a song to the favourites list

To add a song to the Song Seek
favourites list, the following is necessary:
• The song should be currently playing.
• The user must select the PDT button;

a right-hand facing arrow situated at
the lower right hand side of the
screens.

The following screen will provide the
details of the song and give the user the
choice to add it to the favourites list.

If the user adds the song to the favourites
list, confirmation is as follows:

Favourites list is full

If the favourites list is full, the SAT
Information pop-up will indicate Entry
List is full. Delete Entry?

One or more songs must be deleted
before another song can be entered.

All songs may be deleted if desired.

 SR1   Ch021 Octane

Audio

Delete All

12 : 34 pm

Delete

E94023

Pink Floyd           Breathe

Beatles                 Revolver

Guns & Roses       Paradise City

Beatles                 Eleanor Rigby

The Who               My Generation

AM/FM

Sat Radio

CD

Guns & Roses

 SR1   Ch021 Octane

Rock

Settings

Audio

12 : 34 pm

E94024

Guns & Roses

The Rock

SAT Information

Add to Favorites

Edit Favorites

AM/FM

Sat Radio

CD

Guns & Roses

 SR1   Ch040 Wax

Pop

Settings

Audio

12 : 34 pm

E94025

Entry Added

SAT Information

293

Satellite radio

R

To be able to put the Guns & Roses
example into the song seek favourites
list, first Edit Favourites in order to make
space.

MENU FUNCTIONS

The Sat Options button on the satellite
radio screen provides four other menu
features plus a SAT information screen.

Select Sat Options to view the available
options.

The options are:
• Category Lists.
• Direct Channel.
• Parental Lock.
• Channel Skip.
• SAT Information.

Category lists

The above screen shows that Category
Lists has already been selected and that
the Pop category has also been selected.

The following screen shows some of the
various channels that play music within
the Pop category.

Once a channel within the Pop Category
(or any other category) has been
selected, the radio will re-tune to that
channel and the display will return to the
Sat Radio Home screen, but with the new
channel information displayed.

AM/FM

Sat Radio

CD

Guns & Roses

 SR1   Ch101 Vista

Pop

Settings

Audio

12 : 34 pm

E94026

Guns & Roses

The Rock

SAT Information

Add to Favorites

Edit Favorites

Entry List is full. Delete Entry

i

AM/FM

Sat Radio

CD

Octane

Wax

CNBC

Strobe

The Pulse

---

Culture Club

Sat Options

 SR1   Ch021 Octane

Rock

Settings

Audio

12 : 34 pm

E94027



 SR1   Ch021 Octane

Audio

Category Lists

Direct Channel

Parental Lock

Channel Skip

SAT Information

Settings

All Channels

Pop

Rock

R&B / Urban

Dance

12 : 34 pm

E94028

AM/FM

Sat Radio

CD

Octane

Wax

CNBC

Strobe

The Pulse

---

Bill Withers - Lovely Day

Sat Options

 SR1   Ch040 Wax

Pop

Settings

Audio

12 : 34 pm

E94029

Satellite radio

294

L

The new channel is Ch040 Wax, whereas
the previous channel was Ch021 Octane.

Browse PDT

The Browse feature allows the user to
scan all available PDT (Programme
Descriptive Text) within a given category
without changing the current satellite
channel.

The Browse feature will update the PDT
information as programme information
changes within the SIRIUS broadcast.

This view can be maintained while
listening to the audio on the current
satellite channel. The user can scroll
across all available channels using the up
and down arrows to view broadcasted
PDT information. At any time a new
channel can be selected and the screen
will return to the normal satellite view.

Direct channel entry

This option allows the user to input the
channel number directly.

Select Sat Options on the satellite radio
Home screen.

Select Direct Channel on the Sat
Options screen, and a numerical keypad
will be displayed. The user is asked to
enter a channel number.

Channel number 105 has been entered.

A short press on the C (Clear) button will
delete one digit at a time.

Select OK when the desired channel
number has been entered correctly.

If an invalid channel number has been
entered, this will be displayed on the
screen.

 SR1   Ch021 Octane

Audio

040 Wax

041 Sirius Hits

042 Slow Jamz

043 The Express

044 The Vault

Browse PDT

12 : 34 pm

E94030

 SR1   Ch021 Octane

Audio

001

004

005

002

003

12 : 34 pm

E94031

Pink Floyd             Breathe

Beatles                 Revolver

Guns & Roses       Paradise City

Beatles                 Eleanor Rigby

The Who               My Generation

Audio

SR1

Ch021 Octane

Enter Channel Number

Category Lists

C

OK

Direct Channel

Parental Lock

Channel Skip

Sat Information

12 : 26 pm

2

3

6

4

7

8

9

E94032

1

0

5

Audio

SR1

Ch021 Octane

105

Category Lists

C

OK

Direct Channel

Parental Lock

Channel Skip

Sat Information

12 : 26 pm

1

2

3

6

5

4

7

8

9

0

E94033
