283

Compact disc player

R

To load the CD player

Single CD - player empty:

Load a CD into the loading slot. A CD
loading message is displayed on the
touch-screen.

Single CD - player partially loaded:

From the CD player touch-screen, select
an empty slot 2, 1 indicates the current
playing CD, 3 indicates loaded slots. A
message indicates to insert the CD into
the empty slot. Load a CD into the slot.

More than one CD:

Press the LOAD button and insert each
CD into an CD slot as requested by the
displayed message. A pop-up message
on the screen will indicate which slot is
being selected until the unit is fully
loaded.

When the CD player has been loaded, CD
operation is via the CD touch-screen.

EJECTING COMPACT DISCS

To unload the CD player

Press the eject button. A short press
ejects a single CD, a long press ejects
each loaded CD in turn.

E92465

CD

Tr

Settings

A u d i o

/

CD

1

2

3

4

5

6

00:00

12 : 26 pm

Mix

Repeat

AM FM

1

E92466

1

2

3

E92467

E92470

Compact disc player

284

L

COMPACT DISC SELECTION

CD Touch-screen display and
operation

When a CD has been selected (arrowed),
the upper display indicates which disc is
being loaded and will commence playing
when loading has been completed.

COMPACT DISC PLAYBACK

Repeat:
• Short press: Rpt Tr: Will repeat the

playing of the track continuously until
repeat is cancelled by pressing again.

• Long press: Rpt CD: Will repeat the

playing of the whole CD continuously
until repeat is cancelled by pressing
again.

DPLII

or 3CH

Surround mode - Dolby Pro

Logic II selected or 3-channel.

CD

Tr

Settings

A u d i o

/

CD

1

2

3

4

5

6

12 : 26 pm

Mix

Repeat

AM FM

3CH

Loading CD 1

E93965

Tr

3CH

Loading CD 1

CD

Tr

Settings

A u d i o

/

CD

1

2

3

4

5

6

12 : 26 pm

Mix

Repeat

AM FM

3CH

12

03 47

Mix CD

E93968

Rpt Tr

Rpt CD

285

Compact disc player

R

TRACK SELECTION

Seek down and seek up buttons:
• Short press: Seeks down to previous

track or up to next track.

• Long press: Press the seek down to

play rapidly back through one or more
tracks (review). Press the seek up to
play rapidly forward through one or
more tracks (cue). Normal playback
will resume when either button is
released.

Tr 12 - Track number display of the track
being played.

03:47 - Track elapsed time play.

COMPACT DISC PAUSE

II - Pause button; Will pause the playing
track until pressed again. To resume the
CD, press again.

COMPACT DISC DISPLAY
OPTIONS

Settings

When selected, displays the available CD
system setting facilities similar to the
audio system.  See AUDIO CONTROL
(page 273).

CD

Tr

Settings

A u d i o

/

CD

1

2

3

4

5

6

12 : 26 pm

Mix

Repeat

AM FM

3CH

12

03 47

E93969

03 47

Tr 12

CD

Tr

Settings

A u d i o

/

CD

1

2

3

4

5

6

12 : 26 pm

Mix

Repeat

AM FM

TP

TA

3CH

12

03 47

Mix CD

E93970

CD

Tr

Settings

A u d i o

/

CD

1

2

3

4

5

6

12 : 26 pm

Mix

Repeat

AM FM

TP

TA

3CH

12

03 47

Mix CD

E93971

Compact disc player

286

L

Options: CD text can be selected in the
CD mode.  See AUDIO CONTROL
(page 273).

The CD text display is similar to the
Radio text, but displays text that has
been recorded onto the CD (not all CDs
have CD text).

SHUFFLE/RANDOM

Mix CD: Short press: The track order of
play from the current CD is randomly
selected by the CD player, (on MP3 CDs
a short press will mix the tracks from the
current folder).

Mix all: Long press: The CD order of play
is randomly selected, by the CD player,
from all the loaded CDs, (on MP3 CDs a
long press will mix the tracks from all the
folders of the current MP3 disc).

Note: If the volume is turned down to
zero, the CD is automatically paused. Play
is resumed when the volume is increased.

MP3 FILE PLAYBACK

Some pre-recorded and personally
recorded discs, can contain additional
information on the disc, e.g. CD titles,
track titles and the artists name (ID 3
Tags).

Additional buttons allow you to select
folders and tracks and display various
items of information about the
recordings. Typically, MP3 discs have the
potential to hold a great deal more music
than a conventional CD because each
track can be compressed to a higher
degree during recording.

If you record your own music, each
session must be properly closed, but the
whole disc does not have to be finalised.

Note: A mixture of CDs and MP3 discs
can be loaded into the CD player
together.

Note: The CD player is not guaranteed to
play every disc available because of
variations in the quality of discs.

A u d i o

Sound

Options

PTY

S e t t i n g s

On

On

Off

CD text

Off

Traffic

14 : 26 pm

E93972

CD

Tr

Settings

A u d i o

/

CD

1

2

3

4

5

6

12 : 26 pm

Mix

Repeat

AM FM

TP

TA

3CH

12

03 47

Mix CD

E93975

Mix CD

Mix all
