27

Filling station information

R

Filling station information

FILLING STATION
INFORMATION

Fuel type

Unleaded 91 Octane

Fuel filling

Press the fuel filler flap release, located
on the driver’s knee bolster switchpack
below the facia.  See FUEL FILLER FLAP
(page 193).

The filler flap is located on the right-hand
side of the vehicle.

When refuelling, ensure that the fuel
nozzle rests on the bottom of the filler
neck.

Refit the fuel filler cap by twisting the filler
cap clockwise until it clicks. Close the
flap, which automatically locks shut.

Incorrect replacement of the fuel filler cap
may result in the check engine warning
indicator (Malfunction Indicator Lamp
MIL) illuminating.

CAUTIONS

This vehicle is not suitable for use
with fuels containing more than 10
per cent ethanol. Do not use E85

fuels (85 per cent ethanol content).

Equipment necessary for the use of
fuels containing more than 10 per
cent ethanol is not fitted to this

vehicle.

If E85 fuels are used, serious
engine and fuel system damage will
occur.

JAG0051L

AVE FUEL

A

MPG

E93454

28

Filling station information

L

Hood release

Pull the release lever located below the
facia on the left-hand side of the vehicle.
See OPENING AND CLOSING THE
HOOD (page 206).

Underhood top-up

Recommended engine oil.

Castrol 5W-30 to Jaguar specification
WSS M2C913 - B.  See ENGINE OIL
CHECK (page 208).

Windshield and headlamp washer
Reservoir.

 See WASHER FLUID CHECK
(page 213).

Coolant system

50% water 50% antifreeze.  See ENGINE
COOLANT CHECK (page 209).

Ultra high performance tires

E92076

CAUTION

Ultra high performance tires.

This vehicle is equipped with an

Ultra High Performance (UHP) tire and
wheel combination designed to give
maximum dry road performance with
consideration for aquaplaning
resistance. UHP tires have performance
enhancing soft rubber tread compound.
If driven aggressively they may suffer
rapid tread wear and a shorter life than
can be expected from other tyre types.
This wheel and tire combination is more
susceptible to damage from road
hazards.

Do not use this combination for driving
on snow or ice. High perfromance tires
must be replaced with winter tires when
weather conditions dictate.

CAUTION

Tires with an all season icon have a
level of winter performance and
need not be replaced.

29

Filling station information

R

Tire pressures

Tire pressure label USA only

The recommended tire pressures for all
normal operating conditions, are shown
on a label fixed to the pillar behind the
driver’s door.

Tire pressure label Canada and Mexico
only

The recommended tire pressures for all
normal operating conditions, are shown
on a label fixed to the end of the driver’s
door.

For your convenience you may wish to
record the tyre pressures in the boxes
provided below. If you are unsure of the
correct pressures, please contact your
Jaguar Dealer.

WARNING

When using tires other than those
recommended by Jaguar, do not
exceed the speed capacity

recommended by the manufacturer.

E93455

E92077

FRONT

Normal Driving

Laden/High Speed

REAR

Normal Driving

Laden/High Speed

Spare Wheel

30

Filling station information

L

Tire pressure monitoring system

The Tire Pressure Monitoring System
(TPMS) monitors the pressures of the
tires, providing a warning of low tire
pressure. See TIRE PRESSURE
MONITORING SYSTEM (TPMS)
(page 238).

If a warning appears one, or more, of your
tires are significantly under-inflated. You
should stop and check your tire
pressures as soon as possible. They
should be inflated to the recommended
pressure. If warnings appear repeatedly,
the cause must be investigated and
rectified.

Check pressures when the tires are cold.
Deflating a warm tire to the
recommended cold inflation pressure,
will result in dangerous under-inflation.

AVE FUEL

A

MPG

CHECK TIRE PRESSURE

E93456
