Features

HomeLink® Universal Transceiver

*

The HomeLink® Universal Transceiver can be programmed to operate up to three
remote controlled devices around your home, such as garage doors, lighting, or
home security systems.

Refer to the safety information that came with your garage door opener to test that
the safety features are functioning properly. If you do not have the safety
information, contact the manufacturer.

Before programming HomeLink, make sure that people and objects are out of the
way of the garage or gate to prevent potential injury or damage.

When programming a garage door opener, park just outside the garage door’s path.

■

Important Safety Precautions

1

HomeLink® Universal Transceiver

*

Before programming HomeLink to operate a garage
door opener, confirm that the opener has an external
entrapment protection system, such as an “electronic
eye,” or other safety and reverse stop features. If it
does not, HomeLink may not be able to operate it.

* Not available on all models

401

uu

HomeLink® Universal Transceiver

*

u

Training HomeLink

Continued

Features

Training HomeLink

If it is necessary to erase a previously entered
learned code:
• Press and hold the I and III HomeLink

buttons for about 10 seconds, until the
green indicator blinks. Release the buttons,
and proceed to step 1.

• If you are training the second or third

button, go directly to step 1.

The instructions on the next page should work for most gate or garage openers, but
may not work for all. For detailed instructions about your specific remote opener,
visit http://www.homelink.com or call (800) 355-3515.

Indicator

I HomeLink
Button

III HomeLink Button

uu

HomeLink® Universal Transceiver

*

u

Training HomeLink

402

Features

■

Programming a Button

1

Training HomeLink

Reprogramming a Button
If you want to retrain a programmed button for a
new device, you do not have to erase all button
memory. You can replace the existing memory code
using this procedure:

Erasing Button Memory
To erase programming from the buttons, press and hold
the two outside HomeLink buttons until the HomeLink
indicator changes from orange to rapidly flashing green.
This should take about 10 seconds. You should erase all
programming before selling the vehicle.

Operating
To operate, simple press and release the
programmed HomeLink button. Activation will now
occur for the trained device.

Questions
For questions or comments, visit
www.HomeLink.com, www.youtube.com/
HomeLinkGentex, or by calling the HomeLink Hotline
(North America only) at (800) 355-3515.

HomeLink® is a registered trademark of Gentex
Corporation.

2.

1. Press and hold the desired HomeLink button until

the HomeLink indicator begins to slowly flash
orange. This should take about 20 seconds.

Release the HomeLink button and position the
remote transmitter you wish to link 1 - 3 inches
(3 - 8 cm) from the HomeLink button you want to
program, then follow steps 3 - 6 under
“programming a button.”

Training
Complete

HomeLink LED is
continuously on green.

YES

YES

1. Position the remote transmitter you wish to link 1 to 3 inches (3 - 8 cm) from the

HomeLink® button you want to program.

3b. Canadian Garage Door Opener

A. Press and release the HomeLink
button. Press, hold and release the
button on the remote every 2 secs.
Does the HomeLink indicator (LED)
change from slowly flashing orange to
rapidly flashing or continuously on
green? The process should take less
than 60 seconds.

NO

2. Press and release the desired HomeLink button. Is the HomeLink indicator (LED) slowly

flashing orange?

NO

3a. Hold the button on the remote

transmitter. Does HomeLink indicator
(LED) change from slowly flashing
orange to rapidly flashing green or
continuously on green? The process
should take less than 60 seconds.

5. Press and hold the HomeLink button again.

HomeLink indicator rapidly flashes
green.

5a. The remote has a rolling code. Press the

“learn” button on the remote-controlled
device (e.g. garage door opener).

6. Press and hold the HomeLink button

again.
The remote-controlled device should
operate.

Training Complete

5b. Within 30 secs, press and hold the

programmed HomeLink button for 2
secs.

4. Press and hold the programmed HomeLink

button for about a second. Does the device
(garage door opener) work?

403

Continued

Features

Bluetooth® HandsFreeLink®

Bluetooth® HandsFreeLink® (HFL) allows you to place and receive phone calls using
your vehicle’s audio system, without handling your cell phone.

Using HFL

 (Pick-up) button: Press to go directly to the phone screen or to answer an

incoming call.

 (Hang-up/back) button: Press to end a call or to cancel a command.

 (Talk) button: Press to call a number with a stored voice tag.

 (Phone) button: Press to go directly to the phone screen.

Selector knob: Rotate

 to select an item on the screen, then press

.

■

HFL Buttons

1

Bluetooth® HandsFreeLink®

Place your phone where you can get good reception.

To use HFL, you need a Bluetooth-compatible cell
phone. For a list of compatible phones, pairing
procedures, and special feature capabilities:

•

U.S.: Visit automobiles.honda.com/handsfreelink/
or call 1-888-528 -7876.

•

Canada: For more information on smartphone
compatibility, call 1-888-528 -7876.

Voice control tips

•

Aim the vents away from the ceiling and close the
windows, as noise coming from them may interfere
with the microphone.

•

Press and release the

 button when you want to

call a number using a stored voice tag. Speak
clearly and naturally after a beep.

•

If the microphone picks up voices other than yours,
the command may be misinterpreted.

•

To change the volume level, use the audio system’s
volume knob or the remote audio controls on the
steering wheel.

State or local laws may prohibit the operation of
handheld electronic devices while operating a vehicle.

If you receive a call while using the audio system, the
system resumes its operation after ending the call.

Up to 20 speed dial entries can be stored. If there is
no entry in the system, Speed Dial is disabled.

2 Speed Dial P. 418

Up to 20 call histories can be stored. If there is no call
history, Call History is disabled.

Models with color audio

 (Talk) Button

Microphone

 (Hang-up/Back) Button

 (Pick-up) Button

Selector Knob

 (Phone) Button

uu

Bluetooth® HandsFreeLink®

u

Using HFL

404

Features

The audio/information screen notifies you
when there is an incoming call.

Certain manual functions are disabled or inoperable while the vehicle is in motion.
You cannot select a grayed-out option until the vehicle is stopped.

Only previously stored speed dial entries can be called using voice commands while
the vehicle is in motion.

2 Speed Dial P. 418

■

HFL Status Display

1

Bluetooth® HandsFreeLink®

Bluetooth® Wireless Technology
The Bluetooth® word mark and logos are registered
trademarks owned by Bluetooth SIG, Inc., and any
use of such marks by Honda Motor Co., Ltd., is under
license. Other trademarks and trade names are those
of their respective owners.

HFL Limitations
An incoming call on HFL will interrupt the audio
system when it is playing. It will resume when the call
is ended.

HFL Mode

Battery Level Status

Signal Strength

Bluetooth Indicator
Appears when your
phone is connected
to HFL.

Roam Status

Call Name

■

Limitations for Manual Operation

1

HFL Status Display

The information that appears on the audio/
information screen varies between phone models.

You can change the system language to English,
French, or Spanish.

2 Customized Features P. 370

405

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

HFL Menus

The power mode must be in ACCESSORY or ON to use HFL.

1

HFL Menus

To use HFL, you must first pair your Bluetooth-
compatible cell phone to the system while the vehicle
is parked.

Some functions are limited while driving. A message
appears on the screen when the vehicle is moving
and the operation is canceled.

 or

Display the last 20 outgoing calls.

Display the last 20 incoming calls.

Display the last 20 missed calls.

*1 : Appears only when a phone is connected to HFL.

Speed Dial

*1

Add New

Select a phone number from the call history to
store as a speed dial number.

Call History

Phonebook

Select a phone number from the phonebook to
store as a speed dial number.

Phone Number

Enter a phone number to store as a speed dial
number.

Dialed Calls

Received Calls

Missed Calls

Phonebook

*1

Dial

*1

Call History

*1

Display the phonebook of the paired phone.

Enter a phone number to dial.

(Existing entry list)

406

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

*1 : Appears only when a phone is connected to HFL.

Redial the last number dialed in the phone’s history.

Add New Device

Connect a Phone

Connect an Audio Device

Bluetooth Setup

Phone Setup

Redial

*1

Pair a phone to the system.

Connect a phone to the system.

Create a code for a paired phone.

Disconnect All Devices

Delete Device

Pass-Key

Disconnect a paired phone from the system.

Delete a previously paired phone.

Connect a Bluetooth® Audio device to the
system.

407

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

*1 : Appears only when a phone is connected to HFL.

Call History

Phonebook

Phone Number

Speed Dial

*1

Select a phone number from the phonebook
to store as a speed dial number.

Select a phone number from the call history
to store as a speed dial number.

Create a voice tag for a speed dial number.

Change Speed Dial

Delete Speed Dial

Store Voice Tag

Enter a phone number to store as a speed dial
number.

Delete a previously stored speed dial number.

Change Voice Tag

Delete Voice Tag

Change a previously stored speed dial
number.

Change a voice tag for a speed dial number.

Delete a voice tag for a speed dial number.

Add New

Existing entry list

408

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

Fixed

Mobile Phone

System Clear

Ringtone

Select the ring tone stored in the connected
cell phone.

Clear the system of all paired phones, phonebook entries,
and security codes.

Select the ring tone stored in HFL.

Auto Transfer

Set calls to automatically transfer from your phone to HFL
when you enter the vehicle.

Continued

409

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To pair a cell phone (No phone has
been paired to the system)

1. Press the

 button or the

 button.

2. Rotate

 to select Yes, then press

.

3. Make sure your phone is in search or

discoverable mode, then press

.

u

HFL automatically searches for a
Bluetooth® device.

4. When your phone appears on the list, select

it by pressing

.

u

If your phone doesn’t appear, select
Phone Not Found? and search for
Bluetooth® devices using your phone.
From your phone, select
HandsFreeLink.

5. The system gives you a pairing code on the

audio/information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by phone.

6. A notification appears on the screen if

pairing is successful.

■

Phone Setup

1

Phone Setup

Your Bluetooth-compatible phone must be paired to
HFL before you can make and receive hands-free
calls.

Phone Pairing Tips:

•

You cannot pair your phone while the vehicle is
moving.

•

Up to six phones can be paired.

•

Your phone’s battery may drain faster when it is
paired to HFL.

•

If your phone is not ready for pairing or not found
by the system within three minutes, the system will
time out and return to idle.

Once you have paired a phone, you can see it
displayed on the screen with one or two icons on the
right side.
These icons indicate the following:

: The phone can be used with HFL.
: The phone is compatible with Bluetooth® Audio.

410

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To pair a cell phone (when a phone has
already been paired to the system)

1. Press the

 button or the

 button.

u

If a prompt appears asking to connect to
a phone, select No and proceed with
step 2.

2. Rotate

to

select

Phone Setup, then

press .

3. Rotate

to

select

Bluetooth Setup,

then press

.

4. Rotate

to

select

Add New Device,

then press

.

u

The screen changes to device list.

411

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

5. Make sure your phone is in search or

discoverable mode, then press

.

u

HFL automatically searches for a
Bluetooth® device.

6. When your phone appears on the list, select

it by pressing

.

u

If your phone does not appear, select
Phone Not Found? and search for
Bluetooth® devices using your phone.
From your phone, select
HandsFreeLink.

7. The system gives you a pairing code on the

audio/information screen.

u

Confirm if the pairing code on the screen
and your phone match.
This may vary by a phone.

412

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To change the currently paired phone

1. Press the

 button or the

 button.

2. Rotate

to

select

Phone Setup, then

press .

3. Rotate

 to select Bluetooth Setup, then

press .

4. Rotate

to

select

Connect a Phone,

then press

.

u

The screen changes to a device list.

5. Rotate

 to select a desired device name,

then press

.

u

HFL disconnects the connected phone
and starts searching for another paired
phone.

413

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Continued

Features

■

To change the pairing code setting

1. Press the

 button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

3. Rotate

 to select Bluetooth Setup, then

press .

4. Rotate

 to select Pass-Key, then press

.

5. Input a new pairing code, then press

.

414

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

■

To delete a paired phone

1. Press the

 button or the

 button.

2. Rotate

to

select

Phone Setup, then

press .

3. Rotate

 to select Bluetooth Setup, then

press .

4. Rotate

to

select

Delete Device, then

press .

u

The screen changes to a device list.

5. Rotate

 to select a phone you want to

delete, then press

.

6. A confirmation message appears on the

screen. Rotate

 to select Yes, then press

.

Continued

415

uu

Bluetooth® HandsFreeLink®

u

HFL Menus

Features

You can change the ring tone setting.

1. Press the

 button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

3. Rotate

 to select Ringtone, then press

.

4. Rotate

 to select Mobile Phone or

Fixed, then press

.

If you get into the vehicle while you are on the phone, the call can be automatically
transferred to HFL.

1. Press the

 button or the

 button.

2. Rotate

 to select Phone Setup, then

press .

3. Rotate

 to select Auto Transfer, then

press .

4. Rotate

 to select On or Off, then press

.

■

Ring Tone

1

Ring Tone

Mobile Phone: For certain connected phones, the
ring tone stored in the phone sounds from the
speakers.
Fixed: The fixed ring tone sounds from the speakers.

■

Automatic Transferring
