Honda Accord (2019 year). Manual - part 24

368

uu

General Information on the Audio System

u

License Information

*

Features

Mpeg4 Visual
THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO
LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR
(i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUALA STANDARD
(“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED
BY A CONSUMER ENGAGED IN A PERSONAL AND NONCOMMERCIAL ACTIVITY
AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED BY MPEG LA TO
PROVIDE MPEG-4 VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY
OTHER USE. ADDITIONAL INFORMATION INCLUDING THAT RELATING TO
PROMOTIONAL, INTERNAL AND COMMERCIAL USES AND LICENSING MAY BE
OBTAINED FROM MPEG LA, LLC.
SEE HTTP://WWW.MPEGLA.COM.

VC-1
THIS PRODUCT IS LICENSED UNDER THE VC-1 PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO
IN COMPLIANCE WITH THE VC-1 STANDARD (“VC-1 VIDEO”) AND/OR (ii) DECODE
VC-1 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL
AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE VC-1 VIDEO. NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER USE.
ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM.

■

MPEG

369

uu

General Information on the Audio System

u

License Information

*

Features

AVC/H.264
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NONCOMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN
COMPLIANCE WITH THE AVC STANDARD (“AVC VIDEO”) AND/OR (ii) DECODE
AVC VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL
AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO
PROVIDER LICENSED TO PROVIDE AVC VIDEO. NO LICENSE IS GRANTED OR SHALL
BE IMPLIED FOR ANY OTHER USE.
ADDITIONAL INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE
HTTP://WWW.MPEGLA.COM.

microSDHC Logo is a trademark of SD-3C, LLC.

■

SDHC Memory Card

370

Features

Customized Features

Use the audio/information screen to customize certain features.

■

How to customize

While the vehicle is at a complete stop with the power mode in ON, press the
MENU/CLOCK button, then select Settings. To customize the phone settings,
press the

 button, then select Phone Setup.

1

Customized Features

When you customize settings:

•

Make sure that the vehicle is at a complete stop.

•

Shift to

(

P.

Models with color audio

1

How to customize

These indications are used to show how to operate
the selector knob.
Rotate

 to select.

Press

 to enter.

To customize other features, select Settings, rotate

, and press

.

2 List of customizable options P. 388

Audio/Information Screen

 (Phone) Button

371

uu

Customized Features

u

Continued

Features

■

Customization Flow

Press the MENU/CLOCK button.

Adjust Clock

Settings

Bluetooth Setup

Add New Device

Connect an Audio Device

Display Adjustment

Brightness

Contrast

Black Level

Rear Camera

Fixed Guideline

RDS Settings

*1

RDS Information

Radio Text

*1 : FM mode

Dynamic Guideline

Display Change

Audio

Current Drive

History of Trip A

Clock/Wallpaper

History of Trip A

Delete History

Clock/Wallpaper Type

Clock

Wallpaper

372

uu

Customized Features

u

Features

Color Theme

Blue

Red

Amber

Violet

Language

Clock Format

12h

24h

License

Bluegreen

Header Clock Display

On

Off

Vehicle Settings

TPMS Calibration

Driver Assist System Setup

Meter Setup

Default

Lighting Setup

Door/Window Setup

373

uu

Customized Features

u

Continued

Features

Press the

 button and rotate

 to select Phone Setup, then press

.

Ringtone

Mobile Phone

Fixed

Bluetooth Setup

Add New Device

Connect a Phone

Connect an Audio Device

Disconnect All Devices

Delete Device

Pass-Key

Speed Dial

System Clear

Auto Transfer

374

uu

Customized Features

u

Features

■

List of customizable options

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Adjust Clock

Adjust Clock.

2 Clock P. 164

—

Settings

RDS
Settings

RDS Information

Selects whether the RDS information comes
on.

On

*1

/Off

Radio Text

Displays the radio text information of the
selected RDS station.

—

Bluetooth
Setup

Add New Device

Pairs a new phone to HFL, edits and deletes a
paired phone, and create a code for a paired
phone.

2 Phone Setup P. 409

—

Connect an Audio
Device

Connects, disconnects or pairs a Bluetooth®
Audio device to HFL.

—

Display
Adjustment

Brightness

Changes the brightness of the audio/
information screen.

—

Contrast

Changes the contrast of the audio/
information screen.

—

Black Level

Changes the black level of the audio/
information screen.

—

Rear
Camera

Fixed Guideline

Selects whether the fixed guidelines come on
the audio/information screen.

On

*1

/Off

Dynamic Guideline

Selects whether the dynamic guidelines come
on the audio/information screen.

On

*1

/Off

FM mode

375

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Settings

Display Change

Changes the display type.

Audio

*1

/Clock/Wallpaper/

Current Drive/History of
Trip A

History of
Trip A

Delete History

Resets the trip meter.

Yes/No

Clock/
Wallpaper
Type

Clock

Changes the clock display type.

Analog

*1

/Off

Wallpaper

Select

Changes the wallpaper type.

Blank

*1

/Image 1/Image 2/

Image 3

Import

Imports an image file for a new wallpaper.

2 Wallpaper Setup P. 255

—

Delete

Deletes an image file for a wallpaper.

Image 1/Image 2/Image 3

Color Theme

Changes the background color of the audio/
information screen.

Blue

*1

/Red/Amber/Violet/

Bluegreen

Language

Changes the display language.

English

*1

/Français/Español

Header Clock Display

Selects whether the header clock display
comes on.

On

*1

/Off

Clock Format

Selects the digital clock display from 12H to
24H.

12h

*1

/24h

376

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Settings

Vehicle
Settings

TPMS
Calibration

Cancels/Calibrates the tire pressure
monitoring system (TPMS).

Cancel

*1

/Calibrate

Driver Assist
System
Setup

Forward
Collision
Warning
Distance

Changes CMBS

TM

 alert distance.

Long/Normal

*1

/Short

ACC
Forward
Vehicle
Detect Beep

Causes the system to beep when the system
detects a vehicle, or when the vehicle goes out
of the ACC with LSF range.

On/Off

*1

Road
Departure
Mitigation
Setting

Changes the setting for the road departure
mitigation system.

Normal

*1

/Wide/Warning

Only/Narrow

Lane
Keeping
Assist
Suspend
Beep

Causes the system to beep when LKAS is
suspended.

On/Off

*1

Traffic Sign
Recognition
System

Displays traffic sign icon on the driver
information interface.

Small Icon On

*1

/Small Icon

Off

Driver
Attention
Monitor

Changes the setting for the driver attention
monitor.

Tactile and Audible Alert

*1

/

Tactile Alert/Off

377

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Settings

Vehicle
Settings

Meter Setup

Language
Selection

Changes the displayed language.

English

*1

/Français/Español

Adjust
Outside
Temp.
Display

Adjusts the temperature reading by a few
degrees.

-5°F ~ ±0°F

*1

 ~ +5°F

“Trip A”
Reset
Timing

Changes the setting of how to reset trip meter
A and average fuel economy A.

When Fully Refueled/IGN
Off/Manually Reset

*1

“Trip B”
Reset
Timing

Changes the setting of how to reset trip meter
B and average fuel economy B.

When Fully Refueled/IGN
Off/Manually Reset

*1

Adjust
Alarm
Volume

Changes the alarm volume, such as buzzers,
warnings, turn signal sound, and so on.

High/Mid

*1

/Low

Fuel
Efficiency
Backlight

Turns the ambient meter feature on and off.

On

*1

/Off

Speed/
Distance
Units

Selects the trip computer units.

mph · miles

*1

/km/h · km

Tachometer

Selects whether the tachometer come on the
driver information interface.

On/Off

*1

378

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Settings

Vehicle
Settings

Lighting
Setup

Interior
Light
Dimming
Time

Changes the length of time the interior lights
stay on after you close the doors.

60seconds/30seconds

*1

/

15seconds

Headlight
Auto OFF
Timer

Changes the length of time the exterior lights
stay on after you close the driver’s door.

60seconds/30seconds/
15seconds

*1

/0seconds

Auto Light
Sensitivity

Changes the timing for the headlights to
come on.

Max/High/Mid

*1

/Low/Min

Auto
Interior
Illumination
Sensitivity

Changes the sensitivity of the brightness of
the instrument panel when the headlight
switch is in the AUTO position.

Min/Low/Mid

*1

/High/Max

Headlight
Integration
Wiper

Changes the settings for the wiper operation
when the headlights automatically come on
while the headlight switch is in the AUTO
position.

On

*1

/Off

379

uu

Customized Features

u

Continued

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Settings

Vehicle
Settings

Door/
Window
Setup

Auto Door
Lock

Used to change the setting for when the
doors automatically lock.

With Vehicle Speed

*1

/Shift

from P/Off

Auto Door
Unlock

Changes the setting for when the doors
unlock automatically.

All Doors When Driver’s
Door Opens

*1

/All Doors

When Shifted to Park/All
Doors When Ignition
Switched Off/Off

Key and
Remote
Unlock
Mode

Sets up the driver’s door or all the doors to
unlock on the first push of the remote.

Driver Door

*1

/All Doors

Keyless Lock
Answer
Back

LOCK/UNLOCK- The exterior lights flash.
LOCK (2nd push)- The beeper sounds.

On

*1

/Off

Security
Relock
Timer

Changes the time it takes for the doors to
relock and the security system to set after you
unlock the vehicle without opening any door.

90seconds/60seconds/
30seconds

*1

Default

Resets the vehicle settings to the factory
defaults.

Yes/No

License

Shows the legal information.

—

380

uu

Customized Features

u

Features

*1:Default Setting

Setup

Group

Customizable Features

Description

Selectable Settings

Phone
Setup

Bluetooth
Setup

Add New Device

Pairs a new phone to HFL.

2 Phone Setup P. 409

—

Connect a Phone

Pairs a new phone or connects a paired phone
to HFL.

2 Phone Setup P. 409

—

Connect an Audio
Device

Connects a Bluetooth® Audio device to HFL.

—

Disconnect All Devices

Disconnects a paired phone from HFL.

—

Delete Device

Deletes a paired phone.

—

Pass-Key

Inputs and changes a code for a paired phone.

—

Speed Dial

Edits, adds or deletes a speed dial entry.

2 Speed Dial P. 418

—

Ringtone

Selects the ring tone.

Mobile Phone

*1

/Fixed

Auto Transfer

Set calls to automatically transfer from your
phone to HFL when you enter the vehicle.

On

*1

/Off

System Clear

Cancels/Resets all customized items in the
Phone Setup group as default.

—

381

Continued

Features

Customized Features

Use the audio/information screen to customize certain features.

■

How to customize

With the power mode in ON, select Settings, then select a setting item.

1

Customized Features

When you customize settings:

•

Make sure that the vehicle is at a complete stop.

•

Shift to

(

P.

•

Set the parking brake.

To customize other features, select Settings.

2 List of customizable options P. 388

Automatic transmission/Continuously variable
transmission models

Manual transmission models

Models with Display Audio

Audio/Information Screen

382

uu

Customized Features

u

Features

■

Customization flow

Select Settings.

Automatic Date &

Time

Set Date
Set Time

System

Press the

 button.

Automatic Time

Zone

*

Time Format

Time Zone

Set Date & Time

Touch Panel

Sensitivity

System Volumes

Config. of

Instrument Panel

Security

Day & Time

(Select time zone)

Language

Auto Daylight Saving

Time

Date Format

Verbal Reminder

System Volumes

Reading/Warning

Unknown sources

Password

Select configuration

* Not available on all models

383

uu

Customized Features

u

Continued

Features

Caption

Language

Caption style

Detail

Information

Factory Data

Reset

About

Refuel

recommend

*

Accessibility

Status

Legal Information

App Manager

Recent Location

Requests Apps

Caption

Text-to-speech output

Text Size

* Not available on all models
